Lamborghini Diablo VT 6.0 (2000-2001) - Windows

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Windows of Lamborghini Lamborghini Diablo VT 6.0 (2000-2001) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 9415204
RIGHT FRAME 		$415.44 1
002 9415107
FRONT GLASS 		$8,062.44 1
003 9415200
TOP FRAME 		$529.77 1
004 410845235
WINDSHIELD SPACER 		$45.12 5
005 70005535
REAR GLASS 		$636.92 1
006 400845633
QUARTER WINDOW GLASS SHIM 		$16.86 2
007 70008089
LH GLASS 		$3,032.48 1
007 70008088
RH GLASS 		$3,032.48 1
008 9417107
LEFT FRAME 		$367.66 1
008 9417106
RIGHT FRAME 		$719.42 1
009 9417102
RIGHT FRAME 		$277.92 1
009 9417103
LEFT FRAME 		$209.09 (4.1% off) 1
010 410845626
SPACER 		$11.83 2
011 9417105
LEFT FRAME 		$466.09 1
011 9417104
RIGHT FRAME 		$622.42 1
012 WHT003065
SCREW (2,9X16) 		$1.32 (81.6% off) 6
013 9921508
BRACKET 		$122.84 4
014 9921509
BRACKET 		$244.43 4
015 72010205
RHS GASKET 		$713.41 1
015 72010206
LHS GASKET 		$879.65 1
016 72005558
RH GLASS 		$1,941.70 1
016 7205559
LH GLASS 		- 1 Enquire
017 72005557
GASKET 		$67.01 2
018 72001470
PLATE 		$123.46 2
019 9421708
RIGHT SUPPORT 		$385.88 1
019 9421709
LEFT SUPPORT 		$374.90 1
020 9415205
LEFT FRAME 		$525.45 1
021 9415201
BOTTOM FRAME 		$473.31 1
022 410845235
WINDSHIELD SPACER 		$45.12 3
023 600941501
WINDSCREEN ASSEMBLY KIT 		$1,469.17 1
