Front Hood of Lamborghini Lamborghini Diablo (1990-1998)

View All

Lamborghini Diablo (1990-1998) - Front Hood

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	6127985	ORNAMENT	6127985 ORNAMENT SCUDO LAMBORGHINI	$455.33	1
002	9459004	HOOD BONNET	9459004 HOOD BONNET COFANO ANTERIORE	-	1	Enquire
003	9459315	SHIM	9459315 SHIM SPESSORE Dl REGISTRO	$38.90	1
003	9459214	SHIM	9459214 SHIM SPESSORE Dl REGISTRO	$44.56	1
004	8700665	SCREW	8700665 SCREW VITE	$50.57 MSRP: ~~53.00~~ (4.6% off)	4
005	9459310	BRUSH	9459310 BRUSH SPAZZOLA	$75.68	2
006	9459320	LEFT HINGE	9459320 LEFT HINGE BRACCIO SINISTRO	-	1	Enquire
006	9459319	ARM	9459319 ARM BRACCIO DESTRO	-	1	Enquire
007	9459323	PIN	9459323 PIN PERNO	$54.44	2
008	9459311	BRUSH	9459311 BRUSH SPAZZOLA	$75.68	2
009	9459317	LEFT PLATE	9459317 LEFT PLATE PIASTRA DESTRA	$46.46	1
009	9459316	RIGHT PLATE	9459316 RIGHT PLATE PIASTRA SINISTRA	$189.83	1
010	9459321	RIGHT SUPPORT	9459321 RIGHT SUPPORT APPOGGIO DESTRO	$50.57 MSRP: ~~53.00~~ (4.6% off)	1
010	9459322	LEFT SUPPORT	9459322 LEFT SUPPORT BASE APPOGGIO SINISTRO	$50.57 MSRP: ~~53.00~~ (4.6% off)	1
011	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$21.42	2
012	79004387	SHOCK ABSORBER	79004387 SHOCK ABSORBER AMMORTIZZATORE A GAS	$139.99	2
013	9459305	BALL PIN IN STOCK	9459305 BALL PIN PERNO IN STOCK	$2.84	4
014	9459309	BRACKET	9459309 BRACKET STAFFA	$38.21 MSRP: ~~40.00~~ (4.5% off)	2
015	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$21.42	4
016	9459106	LEFT PAD	9459106 LEFT PAD TASSELLO APPOGGIO SINISTRO	$72.44	1
016	9459105	RIGHT PAD	9459105 RIGHT PAD TASSELLO APPOGGIO DESTRO	$72.44	1
017	9459228	SHIM	9459228 SHIM SPESSORE	$17.43	1
018	9459227	LOCK STRIKER	9459227 LOCK STRIKER GANCIO	$127.19	1
019	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$21.42	2
020	9459216	LOCK	9459216 LOCK SERRATURA	$191.07	1
021	9459213	SPACER	9459213 SPACER O	$22.27	1
022	9459217	CLAMP	9459217 CLAMP MORSETTO	-	1	Enquire
023	9460213	ADJ/SCREW	9460213 ADJ/SCREW TESTA REGISTRO	-	1	Enquire
024	WHT002961	WASHER IN STOCK	WHT002961 WASHER RONDELLA IN STOCK	$0.42	2
025	8100623	SCREW	8100623 SCREW VITE	$0.36	2
026	9459212	COVERING	9459212 COVERING PROTEZIONE	$176.82	1
027	8700325	SCREW	8700325 SCREW VITE	$5.82	2
028	9459208	HOOK	9459208 HOOK GANCIO	$115.04	1
029	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$21.42	1
030	9459226	PLATE	9459226 PLATE PIASTRINA	$30.21	1
031	8740685	SCREW IN STOCK	8740685 SCREW VITE IN STOCK	$21.42	2
032	9459224	LOCK STRIKER	9459224 LOCK STRIKER CAVALLOTTO	$170.80	1
033	9459225	SHIM	9459225 SHIM SPESSORE Dl REGISTRO	$15.88 MSRP: ~~16.50~~ (3.8% off)	1
034	9459001	CABLE	9459001 CABLE CAVOCONGUAINA	$22.75	1
035	9459003	CABLE	9459003 CABLE CAVO CON GUAINA (EMERGENZA)	-	1	Enquire
036	9459223	PLATE	9459223 PLATE PIASTRINA	$14.16 MSRP: ~~14.75~~ (4% off)	1
037	9459200	HANDLE	9459200 HANDLE MANIGLIA APERTURA COFANO	$518.63	1
038	8700544	SCREW	8700544 SCREW VITE	$1.68	2
