Name: Partition wall bottons section
Rating: 4.6 (1 reviews)

Partition wall bottons section of Rolls Royce Rolls Royce Phantom Extended RR12(2017-2023)

View All

Rolls Royce Phantom Extended RR12(2017-2023) - Partition wall bottons section

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	51337942283	Partition window	$32,550.84	To Order

Photo	Part No	Description	Price (each)	Stock
	51617942276	Frame separating screen	$2,517.59	To Order

Photo	Part No	Description	Price (each)	Stock
	51617942277	Mounting frame separating screen top	$669.77	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941367	Mounting frame separating disc left	$678.62	To Order
	51437941368	Mounting frame separating screen right	$678.62	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941362	Carrier support separating screen	$10,613.52	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941532	Rail support	$1,457.03	To Order

Photo	Part No	Description	Price (each)	Stock
	51617942281	Connection cross-member top left	$598.34	To Order
	51617942282	Connection cross-member top right	$598.34	To Order

Photo	Part No	Description	Price (each)	Stock
	51617942285	Connection cross-member centre left	$210.70	To Order
	51617942286	Connection cross-member centre right	$210.70	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941391	Connection centre console left	$343.15	To Order
	51437941392	Connection centre console right	$343.15	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941393	Connection part.wall centre console left	$348.68	To Order
	51437941394	Connection part.wall cent.console right	$348.68	To Order

Photo	Part No	Description	Price (each)	Stock
	51437941395	Cross-member bottom left	$1,315.27	To Order
	51437941396	Cross-member bottom right	$1,315.27	To Order

Photo	Part No	Description	Price (each)	Stock
	7129908591	Fillister head screw M6 x 12-8.8	$7.58	To Order

Photo	Part No	Description	Price (each)	Stock
	61139285769	Plug-in connection bracket	$6.61	To Order

Photo	Part No	Description	Price (each)	Stock
	7119904295	Self-locking collar nut	$0.97	To Order

Photo	Part No	Description	Price (each)	Stock
	7146953045	Blind rivet nut, countersunk head	$2.39	To Order

Photo	Part No	Description	Price (each)	Stock
	41007054489	Blind rivet, flat headed	$3.63	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	51337942283	Partition window	51337942283 Partition window	$32,550.84	1
2	51617942276	Frame separating screen	51617942276 Frame separating screen	$2,517.59	1
3	51617942277	Mounting frame separating screen top	51617942277 Mounting frame separating screen top	$669.77	1
4	51437941367	Mounting frame separating disc left	51437941367 Mounting frame separating disc left	$678.62	1
4	51437941368	Mounting frame separating screen right	51437941368 Mounting frame separating screen right	$678.62	1
5	51437941362	Carrier support separating screen	51437941362 Carrier support separating screen	$10,613.52	1
6	51437941532	Rail support	51437941532 Rail support	$1,457.03	1
7	51617942281	Connection cross-member top left	51617942281 Connection cross-member top left	$598.34	1
7	51617942282	Connection cross-member top right	51617942282 Connection cross-member top right	$598.34	1
8	51617942285	Connection cross-member centre left	51617942285 Connection cross-member centre left	$210.70	1
8	51617942286	Connection cross-member centre right	51617942286 Connection cross-member centre right	$210.70	1
9	51437941391	Connection centre console left	51437941391 Connection centre console left	$343.15	1
9	51437941392	Connection centre console right	51437941392 Connection centre console right	$343.15	1
10	51437941393	Connection part.wall centre console left	51437941393 Connection part.wall centre console left	$348.68	1
10	51437941394	Connection part.wall cent.console right	51437941394 Connection part.wall cent.console right	$348.68	1
11	51437941395	Cross-member bottom left	51437941395 Cross-member bottom left	$1,315.27	1
11	51437941396	Cross-member bottom right	51437941396 Cross-member bottom right	$1,315.27	1
12	7129908591	Fillister head screw M6 x 12-8.8	7129908591 Fillister head screw M6 x 12-8.8 M6X12-8.8	$7.58	-
13	61139285769	Plug-in connection bracket	61139285769 Plug-in connection bracket	$6.61	2
14	7119904295	Self-locking collar nut	7119904295 Self-locking collar nut M8-8-ZNS3	$0.97	4
15	7146953045	Blind rivet nut, countersunk head	7146953045 Blind rivet nut, countersunk head M6	$2.39	23
16	41007054489	Blind rivet, flat headed	41007054489 Blind rivet, flat headed 6,5X14,9	$3.63	4
