23 - Engine - 23.5 - System - Fuel

McLaren McLaren Artura

Find Your Part

McLaren McLaren Artura - 23 - ENGINE - 23.5 - SYSTEM - FUEL

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
16FB241CP PUMP-FUEL GDI HDP6 $434.42 To Order
Photo Part No Description Price (each) Stock
16F0157CP ROLLER FOLLOWER-DIA.31MM-GD - PUMP $68.90 To Order
Photo Part No Description Price (each) Stock
16FC486CP PIPE-FUEL-GDI PUMP TO RAIL LH Enquire To Order
Photo Part No Description Price (each) Stock
16FC485CP PIPE-FUEL-GDI PUMP TO RAIL RH Enquire To Order
Photo Part No Description Price (each) Stock
16FB271CP FUEL STUB PIPE-GDI PUMP $83.78 To Order
Photo Part No Description Price (each) Stock
16FB603CP ASSY-FUEL RAIL GDI-RH $927.06 To Order
16FB606CP FUEL RAIL GDI - RH Enquire To Order
Photo Part No Description Price (each) Stock
16FB604CP ASSY-FUEL RAIL GDI-LH $927.06 To Order
16FB605CP FUEL RAIL GDI - LH Enquire To Order
Photo Part No Description Price (each) Stock
16FB392CP BRKT - LP FUEL PIPE + HARNESS $37.52 To Order
Photo Part No Description Price (each) Stock
16FB953CP BOLT-CAP HD-TORX-M6X1X65-8.8 $7.13 To Order
Photo Part No Description Price (each) Stock
16FC310CP CLIP - DOUBLE SUPPORT Enquire To Order
Photo Part No Description Price (each) Stock
16FB515CP BLT-TORX HD-FL-M6X10TX30-8.8 $8.85 To Order
Photo Part No Description Price (each) Stock
16FA015CP BOLT - FUEL PUMP TO CAM COVER $7.13 To Order
Photo Part No Description Price (each) Stock
16F0161CP CLAMP-FUEL INJECTOR $9.16 To Order
Photo Part No Description Price (each) Stock
16FB778CP INJECTOR-FUEL GDI $220.94 To Order
Photo Part No Description Price (each) Stock
16FC239CP BOLT-CLAMP TO FUEL RAIL Enquire To Order
Photo Part No Description Price (each) Stock
16FB520CP ARAYMOND - C-CLIP AND LOCKING 256031-1 $7.46 To Order
Photo Part No Description Price (each) Stock
16FB519CP ARAYMOND - C-CLIP AND LOCKING 256030-1 $7.46 To Order
Photo Part No Description Price (each) Stock
16FB518CP ARAYMOND - C-CLIP AND TIE 256029-1 $7.46 To Order
Photo Part No Description Price (each) Stock
16FC205CP CLIP-DOUBLE PIPE 13-16 - ROTATING Enquire To Order
Photo Part No Description Price (each) Stock
16FB275CP SEAL INTERFACE INJECTOR $18.10 To Order
Photo Part No Description Price (each) Stock
16FC135CP BOLT- M6X12- FL HX HD $8.43 To Order
Photo Part No Description Price (each) Stock
16FB660CP BLT-M5X8-CH-TX25-8.8 $6.90 To Order
Photo Part No Description Price (each) Stock
16FC016CP SLEEVE INJECTOR-FUEL GDI Enquire To Order
View All
23 - ENGINE - 23.5 - SYSTEM - FUEL of McLaren McLaren McLaren Artura Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
010 16FB241CP
PUMP-FUEL GDI HDP6
Row ID: ID__16FB241CP_ContPgHS; Resolution: Available; 		$434.42 2
011 16F0157CP
ROLLER FOLLOWER-DIA.31MM-GD - PUMP
Row ID: ID__16F0157CP_ContPgHS; Resolution: Available; 		$68.90 2
012 16FC486CP
PIPE-FUEL-GDI PUMP TO RAIL LH
Row ID: ID__16FC486CP_ContPgHS; Resolution: Available; 		- 1 Enquire
013 16FC485CP
PIPE-FUEL-GDI PUMP TO RAIL RH
Row ID: ID__16FC485CP_ContPgHS; Resolution: Available; 		- 1 Enquire
014 16FB271CP
FUEL STUB PIPE-GDI PUMP
Row ID: ID__16FB271CP_ContPgHS; Resolution: Available; 		$83.78 2
015 16FB603CP
ASSY-FUEL RAIL GDI-RH
Row ID: ID__16FB603CP_ContPgHS; Resolution: Available; 		$927.06 1
015 16FB606CP
FUEL RAIL GDI - RH
Row ID: ID__16FB606CP_ContPgHS; Resolution: Available; 		- 1 Enquire
016 16FB604CP
ASSY-FUEL RAIL GDI-LH
Row ID: ID__16FB604CP_ContPgHS; Resolution: Available; 		$927.06 1
016 16FB605CP
FUEL RAIL GDI - LH
Row ID: ID__16FB605CP_ContPgHS; Resolution: Available; 		- 1 Enquire
017 16FB392CP
BRKT - LP FUEL PIPE + HARNESS
Row ID: ID__16FB392CP_ContPgHS; Resolution: Available; 		$37.52 1
018 16FB953CP
BOLT-CAP HD-TORX-M6X1X65-8.8
Row ID: ID__16FB953CP_ContPgHS; Resolution: Available; 		$7.13 8
019 16FC310CP
CLIP - DOUBLE SUPPORT
Row ID: ID__16FC310CP_ContPgHS; Resolution: Available; 		- 1 Enquire
020 16FB515CP
BLT-TORX HD-FL-M6X10TX30-8.8
Row ID: ID__16FB515CP_ContPgHS; Resolution: Available; 		$8.85 1
021 16FA015CP
BOLT - FUEL PUMP TO CAM COVER
Row ID: ID__16FA015CP_ContPgHS; Resolution: Available; 		$7.13 4
022 16F0161CP
CLAMP-FUEL INJECTOR
Row ID: ID__16F0161CP_ContPgHS; Resolution: Available; 		$9.16 6
023 16FB778CP
INJECTOR-FUEL GDI
Row ID: ID__16FB778CP_ContPgHS; Resolution: Available; 		$220.94 6
024 16FC239CP
BOLT-CLAMP TO FUEL RAIL
Row ID: ID__16FC239CP_ContPgHS; Resolution: Available; 		- 12 Enquire
025 16FB520CP
ARAYMOND - C-CLIP AND LOCKING 256031-1
Row ID: ID__16FB520CP_ContPgHS; Resolution: Available; 		$7.46 1
026 16FB519CP
ARAYMOND - C-CLIP AND LOCKING 256030-1
Row ID: ID__16FB519CP_ContPgHS; Resolution: Available; 		$7.46 1
027 16FB518CP
ARAYMOND - C-CLIP AND TIE 256029-1
Row ID: ID__16FB518CP_ContPgHS; Resolution: Available; 		$7.46 1
028 16FC205CP
CLIP-DOUBLE PIPE 13-16 - ROTATING
Row ID: ID__16FC205CP_ContPgHS; Resolution: Available; 		- 1 Enquire
029 16FB275CP
SEAL INTERFACE INJECTOR
Row ID: ID__16FB275CP_ContPgHS; Resolution: Available; 		$18.10 6
030 16FC135CP
BOLT- M6X12- FL HX HD
Row ID: ID__16FC135CP_ContPgHS; Resolution: Available; 		$8.43 1
031 16FB660CP
BLT-M5X8-CH-TX25-8.8
Row ID: ID__16FB660CP_ContPgHS; Resolution: Available; 		$6.90 2
032 16FC016CP
SLEEVE INJECTOR-FUEL GDI
Row ID: ID__16FC016CP_ContPgHS; Resolution: Available; 		- 2 Enquire
