Pedal Support of Lamborghini Lamborghini Diablo VT 6.0 (2000-2001)

View All

Lamborghini Diablo VT 6.0 (2000-2001) - Pedal Support

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	42003430	BRAKE BOOSTER RESERVOIR	42003430 BRAKE BOOSTER RESERVOIR	$939.49	1
002	42002667	BRAKE BOOSTER	42002667 BRAKE BOOSTER	$668.02	1
003	N90179103	WASHER 18X8,4X2,5	N90179103 WASHER 18X8,4X2,5	$1.55	4
004	N0111849	NUT	N0111849 NUT	$2.15 MSRP: ~~7.25~~ (70.3% off)	4
005	8573701	RETAINING RING	8573701 RETAINING RING	$0.64 MSRP: ~~7.26~~ (91.2% off)	4
006	410721381	STOP	410721381 STOP	$84.95	2
007	8502513	BEARING	8502513 BEARING	$36.55 MSRP: ~~38.20~~ (4.3% off)	3
008	8402507	WASHER	8402507 WASHER	$27.99 MSRP: ~~29.15~~ (4% off)	1
009	417959727	SWITCH	417959727 SWITCH	$57.38	1
010	42001530	SPACER	42001530 SPACER	-	1	Enquire
011	42004496	SUPPORT - SUPPORTO	42004496 SUPPORT - SUPPORTO	$78.91	1
012	8700644	SCREW	8700644 SCREW	$0.37 MSRP: ~~7.34~~ (95% off)	2
013	N01152427	WASHER	N01152427 WASHER	$0.28	2
014	4230923	SPACER	4230923 SPACER	$28.54 MSRP: ~~29.85~~ (4.4% off)	1
015	N0111849	NUT	N0111849 NUT	$2.15 MSRP: ~~7.25~~ (70.3% off)	4
016	N90179103	WASHER 18X8,4X2,5	N90179103 WASHER 18X8,4X2,5	$1.55	4
017	4233483	PEDALS SUPPORT	4233483 PEDALS SUPPORT	$828.79 MSRP: ~~867.00~~ (4.4% off)	1
018	42000931	SPACER	42000931 SPACER	$35.51 MSRP: ~~37.05~~ (4.2% off)	4
019	4234610	SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO	4234610 SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO (Valid for GB - March 2001)	-	1	Enquire
019	4234610	SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO	4234610 SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO (Valid for AUSTRALIA - March 2001)	-	1	Enquire
020	4232996	PLATE	4232996 PLATE (Valid for GB - March 2001)	$45.54 MSRP: ~~47.55~~ (4.2% off)	1
020	4232996	PLATE	4232996 PLATE (Valid for AUSTRALIA - March 2001)	$45.54 MSRP: ~~47.55~~ (4.2% off)	1
021	4232777	SPACER	4232777 SPACER (Valid for AUSTRALIA - March 2001)	-	1	Enquire
021	4232777	SPACER	4232777 SPACER (Valid for GB - March 2001)	-	1	Enquire
022	4233485	PEDALS SUPPORT	4233485 PEDALS SUPPORT (Valid for AUSTRALIA - March 2001)	$1,120.37 MSRP: ~~1,175.00~~ (4.6% off)	1
022	4233485	PEDALS SUPPORT	4233485 PEDALS SUPPORT (Valid for GB - March 2001)	$1,120.37 MSRP: ~~1,175.00~~ (4.6% off)	1
023	8700644	SCREW	8700644 SCREW (Valid for GB - March 2001)	$0.37 MSRP: ~~7.34~~ (95% off)	2
023	8700644	SCREW	8700644 SCREW (Valid for AUSTRALIA - March 2001)	$0.37 MSRP: ~~7.34~~ (95% off)	2
024	4332774	SHIELD	4332774 SHIELD (Valid for GB - March 2001)	-	1	Enquire
024	4332774	SHIELD	4332774 SHIELD (Valid for AUSTRALIA - March 2001)	-	1	Enquire
