Lights of Lamborghini Lamborghini Diablo VT Roadster (1998-2000)

View All

Lamborghini Diablo VT Roadster (1998-2000) - Lights

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	6332365	HEADLAMP	6332365 HEADLAMP (Valid for U.K.1998) PROIETTORE	-	2	Enquire
001	6331203	HEADLAMP	6331203 HEADLAMP (Valid for CANADA.1998) PROIETTORE	-	2	Enquire
001	6331203	HEADLAMP	6331203 HEADLAMP (Valid for U.S.A.1998) PROIETTORE	-	2	Enquire
001	6331753	HEADLAMP	6331753 HEADLAMP PROIETTORE	-	2	Enquire
001	6330898	HEADLAMP	6330898 HEADLAMP (Valid for JAPAN 1998) PROIETTORE	-	2	Enquire
002	6331631	FRAME	6331631 FRAME CORNICE	-	2	Enquire
003	6329694	BULB	6329694 BULB LAMPADA	-	2	Enquire
004	6337294	CEILING LAMP	6337294 CEILING LAMP PLAFONIERA	-	1	Enquire
005	6329698	BULB	6329698 BULB LAMPADA	-	1	Enquire
006	6338122	BULB	6338122 BULB LAMPADA	-	1	Enquire
007	6337066	LAMP	6337066 LAMP PLAFONIERA	-	1	Enquire
008	N0177522	LAMP 12V/3W	N0177522 LAMP 12V/3W LAMPADA	-	1	Enquire
009	WHT001187	WASHER	WHT001187 WASHER RONDELLA	-	4	Enquire
010	8700502	SCREW	8700502 SCREW VITE	-	4	Enquire
011	63001281	REVERSE LAMP	63001281 REVERSE LAMP FANALE RETROMARCIA	-	1	Enquire
011	63001282	Rear Fog Light	63001282 Rear Fog Light RETRONEBBIA	-	1	Enquire
012	6617094	LAMP BA 15S 21W	6617094 LAMP BA 15S 21W LAMPADA	-	4	Enquire
013	6617095	LAMP SV8,5-8 5W	6617095 LAMP SV8,5-8 5W LAMPADA	-	2	Enquire
014	WHT003424	CLIP	WHT003424 CLIP MOLLETTA	-	4	Enquire
015	8700445	SCREW	8700445 SCREW VITE	-	4	Enquire
016	6328344	LICENCE PLATE LAMP	6328344 LICENCE PLATE LAMP FANALE TARGA	-	2	Enquire
016	6331461	LICENCE PLATE LAMP	6331461 LICENCE PLATE LAMP (Valid for U.S.A.1998) FANALE TARGA	-	2	Enquire
016	6331461	LICENCE PLATE LAMP	6331461 LICENCE PLATE LAMP (Valid for CANADA.1998) FANALE TARGA	-	2	Enquire
017	9911300	RIGHT PANEL	9911300 RIGHT PANEL PANNELLO DX	-	1	Enquire
017	9911301	LEFT PANEL	9911301 LEFT PANEL PANNELLO SX	-	1	Enquire
018	9444006VS	LEFT FRAME	9444006VS LEFT FRAME CORNICE SX	-	1	Enquire
018	9444005VS	RIGHT FRAME	9444005VS RIGHT FRAME CORNICE DX	-	1	Enquire
019	6329828	TAIL LAMP / BRAKE L.	6329828 TAIL LAMP / BRAKE L. FANALE POST. (POSIZIONE E STOP)	-	2	Enquire
020	6329829	TURNING LIGHT	6329829 TURNING LIGHT INDICATORE Dl DIREZIONE	-	2	Enquire
021	6617091	LAMP 15D 32220 5/21W	6617091 LAMP 15D 32220 5/21W LAMPADA	-	2	Enquire
022	WHT002961	WASHER	WHT002961 WASHER RONDELLA	-	8	Enquire
023	8410611	WASHER	8410611 WASHER RONDELLA	-	8	Enquire
024	N01100632	NUT M6	N01100632 NUT M6 DADO	-	8	Enquire
025	6319022	REFLEX/REFLECTOR	6319022 REFLEX/REFLECTOR CATADIOTTRO	-	2	Enquire
026	410947413	DOOR LAMP	410947413 DOOR LAMP PLAFONIERA PORTA	-	2	Enquire
027	6338123	BULB	6338123 BULB LAMPADA	-	2	Enquire
028	6329897	BULB	6329897 BULB LAMPADA	-	2	Enquire
029	R1050004	KIT 2 DIRECTION INDICATORS	R1050004 KIT 2 DIRECTION INDICATORS use (0R1050004 - sets of 2 pieces)	-	2	Enquire
030	6338269	FOG LAMP	6338269 FOG LAMP FENDINEBBIA	-	2	Enquire
031	6329695	BULB	6329695 BULB LAMPADA	-	4	Enquire
032	2403369	SPRING	2403369 SPRING MOLLA	-	4	Enquire
033	6336821	RIGHT FLASH LIGHT	6336821 RIGHT FLASH LIGHT FLASH DIURNO DX	-	1	Enquire
033	6336822	LEFT FLASH LIGHT	6336822 LEFT FLASH LIGHT FLASH DIURNO SX	-	1	Enquire
034	6329695	BULB	6329695 BULB LAMPADA	-	4	Enquire
035	N0211963	NUT	N0211963 NUT DADO	-	6	Enquire
036	WHT003040	WASHER 5.3X1.5X15 (For Becker Radio System)	WHT003040 WASHER 5.3X1.5X15 (For Becker Radio System) RONDELLA	-	8	Enquire
037	8100508	SCREW	8100508 SCREW RONDELLA	-	6	Enquire
038	6337296	STUD	6337296 STUD COLONNETTA	-	6	Enquire
039	6337297	STUD	6337297 STUD COLONNETTA	-	6	Enquire
040	6617094	LAMP BA 15S 21W	6617094 LAMP BA 15S 21W LAMPADA	-	2	Enquire
041	6329696	BULB	6329696 BULB LAMPADA	-	2	Enquire
042	6331779	LEFT FRONT LAMP	6331779 LEFT FRONT LAMP LUCE POSIZIONE - INDIC. DIREZ. SX	-	1	Enquire
042	6331780	RIGHT FRONT LAMP	6331780 RIGHT FRONT LAMP LUCE POSIZIONE - INDIC. DIREZ. DX	-	1	Enquire
043	8700304	SCREW	8700304 SCREW VITE	-	8	Enquire
044	410945249A	High Mount Brake Light	410945249A High Mount Brake Light	-	1	Enquire
044	410945249A	High Mount Brake Light	410945249A High Mount Brake Light use part number: 0R1470010	-	1	Enquire
045	6132280	CONNECTOR	6132280 CONNECTOR CONNESSIONE	-	1	Enquire
046	9944100	STOP LAMP FRAME	9944100 STOP LAMP FRAME CORNICE STOP LAMP	-	1	Enquire
047	6336823	SCREW KIT	6336823 SCREW KIT KIT VITI REG. FARI PROFONDITA	-	1	Enquire
048	6337298	SCREW KIT	6337298 SCREW KIT KITVITI REG. FARI FENDINEBBIA	-	1	Enquire
049	1627472	DIM-DIP E.C.U.	1627472 DIM-DIP E.C.U. (Valid for U.K.1998) CENTRALINA DIM-DIP	-	1	Enquire
050	6132696	SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO	6132696 SUPPORT - (Valid for R.H.D. version - April 1994) SUPPORTO (Valid for U.K.1998) O	-	1	Enquire
051	N0211963	NUT	N0211963 NUT (Valid for U.S.A. 1998) DADO	-	8	Enquire
051	N0211963	NUT	N0211963 NUT (Valid for CANADA.1998) DADO	-	8	Enquire
052	8400501	WASHER	8400501 WASHER (Valid for CANADA.1998)RONDELLA	-	8	Enquire
052	8400501	WASHER	8400501 WASHER (Valid for U.S.A. 1998) RONDELLA	-	8	Enquire
053	N0177522	LAMP 12V/3W	N0177522 LAMP 12V/3W (Valid for U.S.A. 1998) LAMPADA	-	4	Enquire
053	N0177522	LAMP 12V/3W	N0177522 LAMP 12V/3W (Valid for CANADA.1998) LAMPADA	-	4	Enquire
054	6331782	SIDE MARKER IN RED	6331782 SIDE MARKER IN RED (Valid for U.S.A. 1998) SIDEMARKER POST. (ROSSO)	-	2	Enquire
054	6331782	SIDE MARKER IN RED	6331782 SIDE MARKER IN RED (Valid for CANADA.1998)SIDEMARKER POST. (ROSSO)	-	2	Enquire
055	6331781	F. SIDEMAR. (ORANGE)	6331781 F. SIDEMAR. (ORANGE) (Valid for U.S.A. 1998) SIDEMARKER ANT. (ARANCIO)	-	2	Enquire
055	6331781	F. SIDEMAR. (ORANGE)	6331781 F. SIDEMAR. (ORANGE) (Valid for CANADA.1998) SIDEMARKER ANT. (ARANCIO)	-	2	Enquire
