LEFT HAND INJECTION SYSTEM - IGNITION of Ferrari Ferrari California (2012-2014)

View All

Ferrari California (2012-2014) - LEFT HAND INJECTION SYSTEM - IGNITION

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	247589	ELECTRO-INJECTOR	Enquire	To Order
	247588	ELECTRO-INJECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231926	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246615	Spark Plug	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	281449	Ignition Coil	Enquire	To Order
	281449	Ignition Coil	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	274645	LH INJECTION WIRING HARNESS	Enquire	To Order
	274645	LH INJECTION WIRING HARNESS	Enquire	To Order
	268673	LH INJECTION WIRING HARNESS	Enquire	To Order

...and 4 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	238263	IGNITION ECU	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228677	LH BRACKET	Enquire	To Order
	283210	LH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16296934	SCREW 6 X 14MM	Enquire	To Order
	16286124	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	191273	CLIP	Enquire	To Order
	320598	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	251812	L.H. FRONT BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248391	L.H. REAR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	67885100	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	236876	CONTROL UNIT FIXING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	251811	HEAT SHIELD	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	247589	ELECTRO-INJECTOR	247589 ELECTRO-INJECTOR Pressure sensor side; Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied	-	2	Enquire
1	247588	ELECTRO-INJECTOR	247588 ELECTRO-INJECTOR Opposite pressure sensor side; Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied	-	2	Enquire
2	231926	CLIP	231926 CLIP Supplied with COMPL. INJECTOR PIPE, Tab.7 pos.14; No longer supplied	-	4	Enquire
3	246615	Spark Plug ARRIVING SOON	246615 Spark Plug ARRIVING SOON	-	4	Enquire
4	281449	Ignition Coil	281449 Ignition Coil Applicable from Ass. No. 105502	-	4	Enquire
4	281449	Ignition Coil	281449 Ignition Coil Applicable up to Ass. No. 105501	-	4	Enquire
5	274645	LH INJECTION WIRING HARNESS	274645 LH INJECTION WIRING HARNESS Applicable for Soft Start; Applicable from MY 11; Applicable for USA, CDN, USA LIGHT	-	1	Enquire
5	274645	LH INJECTION WIRING HARNESS	274645 LH INJECTION WIRING HARNESS Applicable for Soft Start; Not for USA, CDN, GD, USA LIGHT; Applicable from Ass. No. 97352	-	1	Enquire
5	268673	LH INJECTION WIRING HARNESS	268673 LH INJECTION WIRING HARNESS Applicable for HELE; Applicable for Stop & Start; Applicable from Ass. No. 95558 up to Ass. No. 103178	-	1	Enquire
5	283503	LH INJECTION WIRING HARNESS	283503 LH INJECTION WIRING HARNESS Applicable for HELE; Applicable for Stop & Start; not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
5	264125	LH INJECTION WIRING HARNESS	264125 LH INJECTION WIRING HARNESS Not for Stop & Start; Applicable from Ass. No. 90971; Applicable from engine No. 159183	-	1	Enquire
5	264132	LH INJECTION WIRING HARNESS	264132 LH INJECTION WIRING HARNESS Applicable for Stop & Start; Applicable up to Ass. No. 95557	-	1	Enquire
5	251899	LH INJECTION WIRING HARNESS	251899 LH INJECTION WIRING HARNESS Not for Stop & Start; Applicable up to Ass. No. 90970; Applicable up to engine No. 159182	-	1	Enquire
6	238263	IGNITION ECU	238263 IGNITION ECU Unprogrammed	-	1	Enquire
7	228677	LH BRACKET	228677 LH BRACKET Applicable up to Ass. No. 103178	-	1	Enquire
7	283210	LH BRACKET	283210 LH BRACKET not affected by modification; Applicable from Ass. No. 103179	-	1	Enquire
8	16296934	SCREW 6 X 14MM	16296934 SCREW 6 X 14MM Applicable up to Ass. No. 103178	-	3	Enquire
8	16286124	SCREW	16286124 SCREW not affected by modification; Applicable from Ass. No. 103179	-	4	Enquire
9	191273	CLIP	191273 CLIP D. 16.5	-	1	Enquire
9	320598	CLIP	320598 CLIP D. 16	-	2	Enquire
10	251812	L.H. FRONT BRACKET	251812 L.H. FRONT BRACKET	-	1	Enquire
11	248391	L.H. REAR BRACKET	248391 L.H. REAR BRACKET	-	1	Enquire
12	67885100	CLIP	67885100 CLIP	-	1	Enquire
13	236876	CONTROL UNIT FIXING BRACKET	236876 CONTROL UNIT FIXING BRACKET	-	1	Enquire
14	251811	HEAT SHIELD	251811 HEAT SHIELD	-	1	Enquire
