EXTERNAL GEARBOX CONTROLS of Ferrari Ferrari 599 GTB Fiorano

View All

Ferrari 599 GTB Fiorano - EXTERNAL GEARBOX CONTROLS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	156712	GEAR LEVER KNOB	Enquire	To Order
	223131	KNOB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	108010	CHECKNUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232624	GEAR LEVER	Enquire	To Order
	233397	GEAR LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	146994	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	242564	GEAR SELECTOR	Enquire	To Order
	242565	GEAR SELECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	209152	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232983	GASKET	Enquire	To Order
	233413	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235980	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14303123	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235660	TURRET -Not for F1 - -Not for GD-	Enquire	To Order
	236305	TURRET -Not for F1 - -Valid for GD-	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147561	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154745	BALL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235982	ROD	Enquire	To Order
	236150	ROD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231338	SPRING	Enquire	To Order
	231465	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156101	SPRING RETAINER CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103326	SEEGER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	115980A	SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	212959	GASKET	Enquire	To Order
	212981	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127446	BALL SEAT FOR JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235671	ROCKER IN TOWER	Enquire	To Order
	233398	ROCKER IN TOWER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156128	BELLOW	Enquire	To Order
	157962	BELLOW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	156129	FRAME	Enquire	To Order
	157961	FRAME	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10444621	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601374	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149907	BUSHING	Enquire	To Order
	183982	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	234829	FRONT GEARBOX CONTROL BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231206	REAR GEARBOX CONTROL BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155473	TERMINAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043634	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127496	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246336	F1 GEARBOX CONTROL PANEL	Enquire	To Order
	246336	F1 GEARBOX CONTROL PANEL	Enquire	To Order
	246022	F1 GEARBOX CONTROL PANEL	Enquire	To Order

...and 5 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	66535800	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601374	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159762	SHIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15212724	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	163926	FASTENER BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	234828	FASTENER FOR BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14058519	FLANGED NUT M8 X 8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65200400	CENTRE CONSOLE TUNNEL COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	65200500	INSULATION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13839224	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	210280	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	237846	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	235063	SHIM	Enquire	To Order
	235064	SHIM	Enquire	To Order
	235065	SHIM	Enquire	To Order

...and 1 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	156712	GEAR LEVER KNOB	156712 GEAR LEVER KNOB Standard; Not for F1 gearbox	-	1	Enquire
1	223131	KNOB	223131 KNOB Carbon version; Not for F1 gearbox	-	1	Enquire
2	108010	CHECKNUT	108010 CHECKNUT Not for F1 gearbox	-	1	Enquire
3	232624	GEAR LEVER	232624 GEAR LEVER Not for GD; Not for F1 gearbox	-	1	Enquire
3	233397	GEAR LEVER	233397 GEAR LEVER Applicable for GD; Not for F1 gearbox	-	1	Enquire
4	146994	PIN	146994 PIN Not for F1 gearbox	-	1	Enquire
5	242564	GEAR SELECTOR	242564 GEAR SELECTOR Standard; Applicable for GD; Not for F1 gearbox	-	1	Enquire
5	242565	GEAR SELECTOR	242565 GEAR SELECTOR For trim version with carbon knob; Applicable for GD; Not for F1 gearbox	-	1	Enquire
6	209152	SCREW	209152 SCREW Not for F1 gearbox	-	4	Enquire
7	232983	GASKET	232983 GASKET Not for GD; Not for F1 gearbox	-	1	Enquire
7	233413	GASKET	233413 GASKET Applicable for GD; Not for F1 gearbox	-	1	Enquire
8	235980	BUSHING	235980 BUSHING Not for F1 gearbox	-	1	Enquire
9	14303123	SCREW	14303123 SCREW Not for F1 gearbox	-	4	Enquire
10	235660	TURRET -Not for F1 - -Not for GD-	235660 TURRET -Not for F1 - -Not for GD- Not for GD; Not for F1 gearbox	-	1	Enquire
10	236305	TURRET -Not for F1 - -Valid for GD-	236305 TURRET -Not for F1 - -Valid for GD- Applicable for GD; Not for F1 gearbox	-	1	Enquire
11	147561	SPRING	147561 SPRING Not for F1 gearbox	-	1	Enquire
12	154745	BALL	154745 BALL Not for F1 gearbox	-	1	Enquire
13	235982	ROD	235982 ROD Not for GD; Not for F1 gearbox	-	1	Enquire
13	236150	ROD	236150 ROD Applicable for GD; Not for F1 gearbox	-	1	Enquire
14	231338	SPRING	231338 SPRING Not for GD; Not for F1 gearbox	-	1	Enquire
14	231465	SPRING	231465 SPRING Applicable for GD; Not for F1 gearbox	-	1	Enquire
15	156101	SPRING RETAINER CAP	156101 SPRING RETAINER CAP Not for F1 gearbox	-	1	Enquire
16	103326	SEEGER RING	103326 SEEGER RING Not for F1 gearbox	-	1	Enquire
17	84653800	WASHER	84653800 WASHER Not for F1 gearbox	-	1	Enquire
18	115980A	SWITCH	115980A SWITCH Not for F1 gearbox	-	1	Enquire
19	212959	GASKET	212959 GASKET Not for GD; Not for F1 gearbox	-	1	Enquire
19	212981	GASKET	212981 GASKET Applicable for GD; Not for F1 gearbox	-	1	Enquire
20	127446	BALL SEAT FOR JOINT	127446 BALL SEAT FOR JOINT Not for F1 gearbox	-	1	Enquire
21	235671	ROCKER IN TOWER	235671 ROCKER IN TOWER Not for GD; Not for F1 gearbox	-	1	Enquire
21	233398	ROCKER IN TOWER	233398 ROCKER IN TOWER Applicable for GD; Not for F1 gearbox	-	1	Enquire
22	156128	BELLOW	156128 BELLOW Not for GD; Not for F1 gearbox	-	1	Enquire
22	157962	BELLOW	157962 BELLOW Applicable for GD; Not for F1 gearbox	-	1	Enquire
23	156129	FRAME	156129 FRAME Not for GD; Not for F1 gearbox	-	1	Enquire
23	157961	FRAME	157961 FRAME Applicable for GD; Not for F1 gearbox	-	1	Enquire
24	10444621	SCREW	10444621 SCREW Not for F1 gearbox	-	6	Enquire
25	12601374	WASHER	12601374 WASHER Not for F1 gearbox	-	8	Enquire
26	149907	BUSHING	149907 BUSHING Not for F1 gearbox	-	2	Enquire
26	183982	BUSHING	183982 BUSHING 18 X 24 X 20; Alternative solution; Not for F1 gearbox	-	2	Enquire
27	234829	FRONT GEARBOX CONTROL BAR	234829 FRONT GEARBOX CONTROL BAR Not for F1 gearbox	-	1	Enquire
28	231206	REAR GEARBOX CONTROL BAR	231206 REAR GEARBOX CONTROL BAR Not for F1 gearbox	-	1	Enquire
29	155473	TERMINAL	155473 TERMINAL Not for F1 gearbox	-	1	Enquire
30	16043634	SCREW	16043634 SCREW Not for F1 gearbox	-	2	Enquire
31	127496	WASHER	127496 WASHER Not for F1 gearbox	-	2	Enquire
32	246336	F1 GEARBOX CONTROL PANEL	246336 F1 GEARBOX CONTROL PANEL Not for USA, CDN, GD; Applicable for F1 gearbox	-	1	Enquire
32	246336	F1 GEARBOX CONTROL PANEL	246336 F1 GEARBOX CONTROL PANEL Applicable for USA LIGHT; Applicable for F1 gearbox; Applicable from engine No. 138822	-	1	Enquire
32	246022	F1 GEARBOX CONTROL PANEL	246022 F1 GEARBOX CONTROL PANEL Carbon; Applicable for HGTE version; Not for USA, CDN, GD; Applicable for F1 gearbox	-	1	Enquire
32	246020	F1 GEARBOX CONTROL PANEL	246020 F1 GEARBOX CONTROL PANEL Carbon; Applicable for HGTE version; Applicable for GD; Applicable for F1 gearbox	-	1	Enquire
32	246024	F1 GEARBOX CONTROL PANEL	246024 F1 GEARBOX CONTROL PANEL Carbon; Applicable for HGTE version; Applicable for USA, CDN; Applicable for F1 gearbox	-	1	Enquire
32	285922	F1 GEARBOX CONTROL PANEL	285922 F1 GEARBOX CONTROL PANEL HGTE 60 F1 version; Not for USA, CDN, GD; Applicable for F1 gearbox	-	1	Enquire
32	285923	F1 GEARBOX CONTROL PANEL	285923 F1 GEARBOX CONTROL PANEL HGTE 60 F1 version; Applicable for GD; Applicable for F1 gearbox	-	1	Enquire
32	285924	F1 GEARBOX CONTROL PANEL	285924 F1 GEARBOX CONTROL PANEL HGTE 60 F1 version; Applicable for USA, CDN; Applicable for F1 gearbox	-	1	Enquire
33	66535800	SCREW	66535800 SCREW Not for F1 gearbox	-	4	Enquire
34	12601374	WASHER	12601374 WASHER Not for F1 gearbox	-	4	Enquire
35	159762	SHIM	159762 SHIM Installed if necessary; Not for F1 gearbox	-	1	Enquire
36	15212724	SCREW	15212724 SCREW Not for F1 gearbox	-	2	Enquire
37	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6 Not for F1 gearbox	-	2	Enquire
38	10519424	WASHER	10519424 WASHER Not for F1 gearbox	-	2	Enquire
39	163926	FASTENER BUSHING	163926 FASTENER BUSHING Not for F1 gearbox	-	2	Enquire
40	234828	FASTENER FOR BAR	234828 FASTENER FOR BAR Not for F1 gearbox	-	1	Enquire
41	14058519	FLANGED NUT M8 X 8	14058519 FLANGED NUT M8 X 8 Not for F1 gearbox	-	8	Enquire
42	65200400	CENTRE CONSOLE TUNNEL COVER	65200400 CENTRE CONSOLE TUNNEL COVER Applicable for F1 gearbox	-	1	Enquire
43	65200500	INSULATION	65200500 INSULATION Applicable for F1 gearbox	-	1	Enquire
44	13839224	SCREW	13839224 SCREW Applicable for F1 gearbox	-	4	Enquire
45	210280	GASKET	210280 GASKET Applicable for GD; Not for F1 gearbox	-	1	Enquire
46	237846	GASKET	237846 GASKET	-	1	Enquire
47	235063	SHIM	235063 SHIM 1.2 mm	-	1	Enquire
47	235064	SHIM	235064 SHIM 2 mm	-	1	Enquire
47	235065	SHIM	235065 SHIM 3 mm	-	1	Enquire
47	238627	SHIM	238627 SHIM 4 mm	-	1	Enquire
