View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4M0131489B	VACUUM RESERVOIR	4M0131489B VACUUM RESERVOIR	-	-	Enquire
1	420131541	VACUUM RESERVOIR	420131541 VACUUM RESERVOIR	$60.01	1
2	N90994403	HEXAGON HEAD BOLT (COMBI)	N90994403 HEXAGON HEAD BOLT (COMBI) M8X30	$2.69	2
3	4M0131051D	VACUUM LINE	4M0131051D VACUUM LINE	$81.06	1
4	-	BRACKET FOR AKF VALVE	BRACKET FOR AKF VALVE SEE ILLUSTRATION : 133.07	-	-	Enquire
5	P2131055L	1 SET OF VACUUM PIPES	P2131055L 1 SET OF VACUUM PIPES	$368.30	1
6	P2130405C	BRACKET	P2130405C BRACKET SIDE, LEFT	$13.91	1
7	N10335206	HEXAGON SOCKET FLAT HEAD BOLT	N10335206 HEXAGON SOCKET FLAT HEAD BOLT M6X12	$1.43	3
8	P2130407	BRACKET	P2130407 BRACKET SIDE, RIGHT	$10.03	1
9	P2133169G	BRACKET	P2133169G BRACKET RIGHT FRONT	$13.85	1
10	N10124306	HEXAGON SOCKET FLAT HEAD BOLT	N10124306 HEXAGON SOCKET FLAT HEAD BOLT M6X20	$1.60	2
11	P2131179B	VACUUM HOSE	P2131179B VACUUM HOSE	$15.73	1
12	-	COOLANT PUMP WITH VACUUM CONNECTION	COOLANT PUMP WITH VACUUM CONNECTION SEE ILLUSTRATION : 121.01	-	-	Enquire
13	-	VACUUM PUMP	VACUUM PUMP SEE ILLUSTRATION : 145.01	-	-	Enquire
14	-	VACUUM HOSE	VACUUM HOSE SEE ILLUSTRATION : 145.05-SIDE, RIGHT	-	-	Enquire
15	-	VACUUM HOSE	VACUUM HOSE SEE ILLUSTRATION : 145.05-SIDE, LEFT	-	-	Enquire
16	4M0809163B	RETAINER FOR VACUUM CONTAINER	4M0809163B RETAINER FOR VACUUM CONTAINER	$9.67	1
17	N10757101	HEXAGON HEAD BOLT (COMBI)	N10757101 HEXAGON HEAD BOLT (COMBI)	$0.70	2
18	59131694AR	PIPE HOLDER	59131694AR PIPE HOLDER	$0.58	1
