CYLINDER HEAD of Lamborghini Lamborghini Urus (2018-2019)

View All

Lamborghini Urus (2018-2019) - CYLINDER HEAD

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	P2103061AY	COMPLETE CYLINDER HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	P2103062AY	COMPLETE CYLINDER HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	P2103383E	CYLINDER HEAD GASKET	Enquire	To Order
	P2103383D	CYLINDER HEAD GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6M103201D	VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	P2103113A	COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	P2103649E	GASKET FOR COVER	Enquire	To Order
	P2103650E	GASKET FOR COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10554005	ROUND HD. SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT008395	CYLINDER HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT008178	DOWEL SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91097202	ROUND HD. SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	7L109291	BUNGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91103401	SEAL BOLT WITH SEALING RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	58103139	DOWEL SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10124306	HEXAGON SOCKET FLAT HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91004802	DOUBLE STUD WITH HEXAGON DRIVE	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	P2103061AY	COMPLETE CYLINDER HEAD	P2103061AY COMPLETE CYLINDER HEAD CYLINDER 5-8	-	-	Enquire
2	P2103062AY	COMPLETE CYLINDER HEAD	P2103062AY COMPLETE CYLINDER HEAD CYLINDERS 1-4	-	-	Enquire
3	P2103383E	CYLINDER HEAD GASKET	P2103383E CYLINDER HEAD GASKET CYLINDER 5-8	-	-	Enquire
3	P2103383D	CYLINDER HEAD GASKET	P2103383D CYLINDER HEAD GASKET CYLINDERS 1-4	-	-	Enquire
4	6M103201D	VALVE	6M103201D VALVE	-	-	Enquire
5	P2103113A	COVER	P2103113A COVER	-	-	Enquire
6	P2103649E	GASKET FOR COVER	P2103649E GASKET FOR COVER CYLINDER 5-8	-	-	Enquire
6	P2103650E	GASKET FOR COVER	P2103650E GASKET FOR COVER CYLINDERS 1-4	-	-	Enquire
7	6M109285F	COVER	6M109285F COVER LEFT	-	-	Enquire
7	6M109286F	COVER	6M109286F COVER RIGHT	-	-	Enquire
8	N10554005	ROUND HD. SCREW	N10554005 ROUND HD. SCREW M6X35	-	60	Enquire
9	WHT008395	CYLINDER HEAD BOLT	WHT008395 CYLINDER HEAD BOLT M10X170X120	-	-	Enquire
10	WHT008178	DOWEL SLEEVE	WHT008178 DOWEL SLEEVE 8J6X14	-	-	Enquire
11	N91097202	ROUND HD. SCREW	N91097202 ROUND HD. SCREW M6X35	-	-	Enquire
12	7L109291	BUNGS	7L109291 BUNGS	-	8	Enquire
13	N91103401	SEAL BOLT WITH SEALING RING	N91103401 SEAL BOLT WITH SEALING RING M10X1X10	-	-	Enquire
14	58103139	DOWEL SLEEVE	58103139 DOWEL SLEEVE 8,2X6,5	-	-	Enquire
15	N10124306	HEXAGON SOCKET FLAT HEAD BOLT	N10124306 HEXAGON SOCKET FLAT HEAD BOLT M6X20	-	12	Enquire
16	N91004802	DOUBLE STUD WITH HEXAGON DRIVE	N91004802 DOUBLE STUD WITH HEXAGON DRIVE M6X22/M6X12	-	-	Enquire
