Pedal Support

Find Your Part

Lamborghini Murcielago LP640 - Pedal Support

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Pedal Support of Lamborghini Lamborghini Murcielago LP640 Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
002 3D0611301B
RESERVOIR FOR BRAKE FLUID 		$155.91 1
003 N90179103
WASHER 18X8,4X2,5 		$1.55 4
004 N0111849
NUT 		$2.15 (70.3% off) 4
005 WHT002647
RETAINING RING 		$3.30 (54.6% off) 4
006 410721381
STOP 		$84.95 2
007 410721196
BEARING 		$47.11 3
008 WHT002632
WASHER 		$34.96 1
009 1K2945511RDW
SWITCH (WARNING USE 410721633B) 		$75.03 1
010 413721663A
SPACER 		$35.02 1
011 410721633E
SUPPORT (WARNING USE 1K2945511) 		$58.67 1
012 N10650701
HEXAGON SOCKET HEAD BOLT 		$0.98 (86.5% off) 3
013 N01152427
WASHER 		$0.28 2
014 410721648
SPACER (MANUAL GEARBOX) 		$568.56 1
015 N0111849
NUT 		$2.15 (70.3% off) 4
016 N90179103
WASHER 18X8,4X2,5 		$1.55 4
017 413721117A
PEDALS SUPPORT 		$842.74 1
018 410721134A
BUSHING 		$223.81 4
019 N10650701
HEXAGON SOCKET HEAD BOLT 		$0.98 (86.5% off) 2
020 413864777
COVER 		$62.98 1
022 4A0611817A
BUNGS 		$4.84 (49.6% off) 2
023 N90533005
HEXAGON HEAD BOLT (COMBI) 		$1.96 (73% off) 1
024 N91051101
SCREW M6X30 		$1.47 (79.6% off) 1
025 400616807
CHECK VALVE 		$27.22 1
026 400612100B
POWER BRAKE (COMPLETE) 		$1,040.31 1
