CHASSIS of Lamborghini Lamborghini Huracan Evo Coupe

View All

Lamborghini Huracan Evo Coupe - CHASSIS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4T8813031K	FRAME	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0813441F	REINFORCEMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T8817361D	SUPPORT	Enquire	To Order
	4T8817362D	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T8810244F	RH TIE ROD (CONTACT YOUR AREA MANAGER)	Enquire	To Order
	4T8810243F	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0813499B	ADAPTER	Enquire	To Order
	4T0813500B	ADAPTER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T8814201E	SUPPORT	Enquire	To Order
	4T8814202D	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CROSS MEMBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CROSS MEMBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0813254B	REINFORCEMENT	Enquire	To Order
	4S0813253D	REINFORCEMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0810251B	CARRIER	Enquire	To Order
	4T0810252B	RH BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0810439B	BRACKET	Enquire	To Order
	4T0810440B	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91097301	HEXAGON SOCKET FLAT HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0813857B	REINFORCEMENT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0813483C	SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N01508210	HEXAGON COLLAR NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91128001	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10683301	HEXAGON COLLARED BOLT WITH MULTI-POINT SOCKET HEAD (DUO)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0813239C	BRACE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4S0813945K	SLEEVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4T0813541E	ARM	Enquire	To Order
	4T0813542E	ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		ADJUSTING PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CAP CLOSURE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10664801	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4T8813031K	FRAME	4T8813031K FRAME CONTACT YOUR AREA MANAGER-REAR ENGINE BAY	-	1	Enquire
2	4S0813441F	REINFORCEMENT	4S0813441F REINFORCEMENT	-	1	Enquire
3	4T8817361D	SUPPORT	4T8817361D SUPPORT LEFT REAR	-	1	Enquire
3	4T8817362D	SUPPORT	4T8817362D SUPPORT RIGHT REAR	-	1	Enquire
4	4T8810244F	RH TIE ROD (CONTACT YOUR AREA MANAGER)	4T8810244F RH TIE ROD (CONTACT YOUR AREA MANAGER) CONTACT YOUR AREA MANAGER-RIGHT UPPER	-	1	Enquire
4	4T8810243F	SUPPORT	4T8810243F SUPPORT LEFT UPPER	-	1	Enquire
5	4T0813499B	ADAPTER	4T0813499B ADAPTER LEFT	-	1	Enquire
5	4T0813500B	ADAPTER	4T0813500B ADAPTER RIGHT	-	1	Enquire
6	4T8814201E	SUPPORT	4T8814201E SUPPORT CONTACT YOUR AREA MANAGER-LEFT LOWER	-	1	Enquire
6	4T8814202D	SUPPORT	4T8814202D SUPPORT CONTACT YOUR AREA MANAGER-RIGHT LOWER	-	1	Enquire
7	-	CROSS MEMBER	CROSS MEMBER CANNOT BE SOLD SEPARATELY	-	-	Enquire
8	-	CROSS MEMBER	CROSS MEMBER CANNOT BE SOLD SEPARATELY	-	-	Enquire
9	4S0813254B	REINFORCEMENT	4S0813254B REINFORCEMENT CONTACT YOUR AREA MANAGER-RIGHT	-	1	Enquire
9	4S0813253D	REINFORCEMENT	4S0813253D REINFORCEMENT CONTACT YOUR AREA MANAGER-LEFT	-	-	Enquire
10	4T0810251B	CARRIER	4T0810251B CARRIER LEFT	-	1	Enquire
10	4T0810252B	RH BRACKET	4T0810252B RH BRACKET RIGHT	-	1	Enquire
11	4T0810439B	BRACKET	4T0810439B BRACKET LEFT	-	1	Enquire
11	4T0810440B	BRACKET	4T0810440B BRACKET RIGHT	-	1	Enquire
12	N91097301	HEXAGON SOCKET FLAT HEAD BOLT	N91097301 HEXAGON SOCKET FLAT HEAD BOLT M6X45	-	8	Enquire
13	4S0813857B	REINFORCEMENT	4S0813857B REINFORCEMENT	-	1	Enquire
14	4T0813483C	SUPPORT	4T0813483C SUPPORT	-	1	Enquire
15	N01508210	HEXAGON COLLAR NUT	N01508210 HEXAGON COLLAR NUT M6	-	4	Enquire
16	N91128001	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N91128001 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M8X25	-	4	Enquire
17	N10683301	HEXAGON COLLARED BOLT WITH MULTI-POINT SOCKET HEAD (DUO)	N10683301 HEXAGON COLLARED BOLT WITH MULTI-POINT SOCKET HEAD (DUO) M10X115	-	2	Enquire
18	4S0813239C	BRACE	4S0813239C BRACE	-	1	Enquire
19	4S0813945K	SLEEVE	4S0813945K SLEEVE TO BE USED FOR REF. 9 - CONTACT YOUR AREA MANAGER-LEFT	-	2	Enquire
20	-	BRACKET	BRACKET ONLY FOR 2WD VERSION	-	-	Enquire
21	-	BRACKET	BRACKET ONLY FOR SPYDER VERSION	-	-	Enquire
22	4T0813541E	ARM	4T0813541E ARM LEFT	-	1	Enquire
22	4T0813542E	ARM	4T0813542E ARM RIGHT	-	1	Enquire
23	N91042302	OVAL HEXAGON SOCKET HEAD BOLT	N91042302 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	12	Enquire
24	-	BRACKET	BRACKET ONLY FOR PERFORMANTE MODEL	-	-	Enquire
25	-	ADJUSTING PIN	ADJUSTING PIN FOR SPYDER MODEL	-	-	Enquire
26	-	CAP CLOSURE	CAP CLOSURE SEE ILLUSTRATION :- 827-020,11	-	-	Enquire
27	N10664801	SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD	N10664801 SOCKET HEAD COLLARED BOLT WITH INNER MULTIPOINT HEAD M8X20	-	2	Enquire
