Lamborghini Gallardo LP570 4 SL - Rear Tunnel

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	403863242B	CENTER TUNNEL ASSEMBLY	403863242B CENTER TUNNEL ASSEMBLY	$10,974.44	1
003	400863843	LID FIXING BRACKET	400863843 LID FIXING BRACKET	$17.28	1
004	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.15	2
005	400863615	TUNNEL FIXING BRACKET, REAR	400863615 TUNNEL FIXING BRACKET, REAR	$16.95	1
006	N90847903	Screw M6X15 IN STOCK	N90847903 Screw M6X15 IN STOCK	$1.16	2
007	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.15	2
008	400863345	TUNNEL FIXING BRACKET, CENTER	400863345 TUNNEL FIXING BRACKET, CENTER	$16.70	1
009	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.15	8
010	400863583	TUNNEL FIXING BRACKET, FRONT LH	400863583 TUNNEL FIXING BRACKET, FRONT LH	$10.70	1
011	400863584	TUNNEL FIXING BRACKET, FRONT RH	400863584 TUNNEL FIXING BRACKET, FRONT RH	$10.70	1
012	N10569501	ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	N10569501 ROUND-HEAD SCREW WITH INNER HEXAGON SOCKET HEAD IN STOCK	$2.15	8
013	N0902424	SCREW M6X18	N0902424 SCREW M6X18	$0.82 MSRP: ~~7.29~~ (88.8% off)	2
014	N90688101	CLAMP	N90688101 CLAMP	$0.85 MSRP: ~~7.26~~ (88.3% off)	3
021	8D0919343	LIGHTER RING	8D0919343 LIGHTER RING	$11.96	1
022	7M3919311	OUTLET 12V (NON SMOKING VERSION)	7M3919311 OUTLET 12V (NON SMOKING VERSION)	$7.27	1
023	403863300B	GLOVE BOX	403863300B GLOVE BOX	$3,998.66	1
024	400868563	CLIP	400868563 CLIP	$0.80 MSRP: ~~7.27~~ (89% off)	1
033	403711461	HAND BRAKE COVERING ASSY WITH MOLDING (ALCANTARA UPHOLSTERY - SUPPLY VIN)	403711461 HAND BRAKE COVERING ASSY WITH MOLDING (ALCANTARA UPHOLSTERY - SUPPLY VIN)	$513.44	1
034	400863343F	HAND BRAKE LOWER PORTION CLOSING (CARBON INTERIOR)	400863343F HAND BRAKE LOWER PORTION CLOSING (CARBON INTERIOR)	$3,206.51	1
034	403863343B	HAND BRAKE LOWER PORTION CLOSING	403863343B HAND BRAKE LOWER PORTION CLOSING	$84.00	1
035	N90485901	WASHER IN STOCK	N90485901 WASHER IN STOCK	$14.38	10
036	N90562401	SCREW IN STOCK	N90562401 SCREW IN STOCK	$1.74	10
037	N90632303	HEXAGON SOCKET HEAD PANEL BOLT IN STOCK	N90632303 HEXAGON SOCKET HEAD PANEL BOLT IN STOCK	$1.89 MSRP: ~~7.07~~ (73.3% off)	2
038	WHT003110	SCREW M4X10	WHT003110 SCREW M4X10	$5.66	1
