CRANKSHAFT - CONNECTING RODS AND PISTONS of Ferrari Ferrari 612 Scaglietti

View All

Ferrari 612 Scaglietti - CRANKSHAFT - CONNECTING RODS AND PISTONS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	182735	CRANKSHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	176396	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194251	COMPLETE HALF-BEARING SET	Enquire	To Order
	173485	COMPLETE HALF-BEARING SET	Enquire	To Order
	173486	COMPLETE HALF-BEARING SET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190505	LOWER HALF-BEARING	Enquire	To Order
	173488	LOWER HALF-BEARING	Enquire	To Order
	173491	LOWER HALF-BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190504	UPPER HALF-BEARING	Enquire	To Order
	173487	UPPER HALF-BEARING	Enquire	To Order
	173490	UPPER HALF-BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190503	INTERMEDIATE HALF-BEARING	Enquire	To Order
	173489	INTERMEDIATE HALF-BEARING	Enquire	To Order
	173492	INTERMEDIATE HALF-BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103877	GROOVED BALL BEARING D.30-35	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164111	UPPER SHIM RING	Enquire	To Order
	164112	UPPER SHIM RING	Enquire	To Order
	164113	UPPER SHIM RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	164108	LOWER SHIM RING	Enquire	To Order
	164109	LOWER SHIM RING	Enquire	To Order
	164110	LOWER SHIM RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	144876	TAB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184426	COMPL. CONNECTING ROD AND CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177159	CON. ROD FASTENER SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184909	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	173550	CONNECTING ROD HALF-BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	223174	PISTON COMPLETE WITH PISTON RINGS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180445	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180446	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180447	OIL SCRAPER RING	Enquire	To Order
	217576	OIL SCRAPER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154717	GUDGEON PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	193051	Flywheel	Enquire	To Order
	246647	ENGINE FLYWHEEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201755	Bolt Hex Head M10 x 1.25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215963	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168565	Torsion Damper	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140925	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140922	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194252	COMPLETE PISTON RING SET	Enquire	To Order
	229101	COMPLETE PISTON RING SET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	182735	CRANKSHAFT	182735 CRANKSHAFT	-	1	Enquire
2	176396	THREADED PLUG	176396 THREADED PLUG	-	1	Enquire
3	194251	COMPLETE HALF-BEARING SET	194251 COMPLETE HALF-BEARING SET Red; Nominal; After depletion, order individual parts; Applicable until depletion	-	1	Enquire
3	173485	COMPLETE HALF-BEARING SET	173485 COMPLETE HALF-BEARING SET 1st reduction, 0.254 mm; After depletion, order individual parts; Applicable until depletion	-	1	Enquire
3	173486	COMPLETE HALF-BEARING SET	173486 COMPLETE HALF-BEARING SET 2nd reduction, 0.508 mm; After depletion, order individual parts; Applicable until depletion	-	1	Enquire
4	190505	LOWER HALF-BEARING	190505 LOWER HALF-BEARING Red; Nominal	-	2	Enquire
4	173488	LOWER HALF-BEARING	173488 LOWER HALF-BEARING 1st reduction, 0.254 mm	-	2	Enquire
4	173491	LOWER HALF-BEARING	173491 LOWER HALF-BEARING 2nd reduction, 0.508 mm	-	2	Enquire
5	190504	UPPER HALF-BEARING	190504 UPPER HALF-BEARING Red; Nominal	-	2	Enquire
5	173487	UPPER HALF-BEARING	173487 UPPER HALF-BEARING 1st reduction, 0.254 mm	-	2	Enquire
5	173490	UPPER HALF-BEARING	173490 UPPER HALF-BEARING 2nd reduction, 0.508 mm	-	2	Enquire
6	190503	INTERMEDIATE HALF-BEARING	190503 INTERMEDIATE HALF-BEARING Red; Nominal	-	10	Enquire
6	173489	INTERMEDIATE HALF-BEARING	173489 INTERMEDIATE HALF-BEARING 1st reduction, 0.254 mm	-	10	Enquire
6	173492	INTERMEDIATE HALF-BEARING	173492 INTERMEDIATE HALF-BEARING 2nd reduction, 0.508 mm	-	10	Enquire
7	103877	GROOVED BALL BEARING D.30-35	103877 GROOVED BALL BEARING D.30-35	-	1	Enquire
8	164111	UPPER SHIM RING	164111 UPPER SHIM RING Red; Nominal	-	2	Enquire
8	164112	UPPER SHIM RING	164112 UPPER SHIM RING 1st size increase, 0.127 mm	-	2	Enquire
8	164113	UPPER SHIM RING	164113 UPPER SHIM RING 2nd size increase, 0.254 mm	-	2	Enquire
9	164108	LOWER SHIM RING	164108 LOWER SHIM RING Red; Nominal	-	2	Enquire
9	164109	LOWER SHIM RING	164109 LOWER SHIM RING 1st size increase, 0.127 mm	-	2	Enquire
9	164110	LOWER SHIM RING	164110 LOWER SHIM RING 2nd size increase, 0.254 mm	-	2	Enquire
10	144876	TAB	144876 TAB	-	1	Enquire
11	184426	COMPL. CONNECTING ROD AND CAP	184426 COMPL. CONNECTING ROD AND CAP	-	12	Enquire
12	177159	CON. ROD FASTENER SCREW	177159 CON. ROD FASTENER SCREW	-	24	Enquire
13	184909	BUSHING	184909 BUSHING	-	12	Enquire
14	173550	CONNECTING ROD HALF-BEARING	173550 CONNECTING ROD HALF-BEARING Red	-	24	Enquire
15	223174	PISTON COMPLETE WITH PISTON RINGS	223174 PISTON COMPLETE WITH PISTON RINGS	-	12	Enquire
16	180445	SEAL RING	180445 SEAL RING 1st groove; With complete set 194252 and 229101	-	12	Enquire
17	180446	SEAL RING	180446 SEAL RING 2nd groove; With complete set 194252 and 229101	-	12	Enquire
18	180447	OIL SCRAPER RING	180447 OIL SCRAPER RING 3rd groove; With complete set 194252	-	12	Enquire
18	217576	OIL SCRAPER RING	217576 OIL SCRAPER RING 3rd groove; With complete set 229101	-	12	Enquire
19	154717	GUDGEON PIN	154717 GUDGEON PIN Applicable until depletion	-	12	Enquire
21	193051	Flywheel	193051 Flywheel	-	1	Enquire
21	246647	ENGINE FLYWHEEL	246647 ENGINE FLYWHEEL Applicable for "OTO"	-	1	Enquire
22	201755	Bolt Hex Head M10 x 1.25	201755 Bolt Hex Head M10 x 1.25	-	8	Enquire
23	215963	WASHER	215963 WASHER	-	1	Enquire
24	168565	Torsion Damper	168565 Torsion Damper	-	1	Enquire
25	140925	SCREW	140925 SCREW	-	1	Enquire
26	140922	WASHER	140922 WASHER	-	1	Enquire
27	194252	COMPLETE PISTON RING SET	194252 COMPLETE PISTON RING SET Applicable for compl. piston 189515 ref. 15; Applicable until depletion	-	12	Enquire
27	229101	COMPLETE PISTON RING SET	229101 COMPLETE PISTON RING SET Applicable for compl. piston 223174 ref. 15; Applicable until depletion	-	12	Enquire
