FRONT SUSPENSION - SHOCK ABSORBER AND BRAKE DISC of Ferrari Ferrari 458 Speciale Aperta

View All

Ferrari 458 Speciale Aperta - FRONT SUSPENSION - SHOCK ABSORBER AND BRAKE DISC

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	302409	FRONT SHOCK ABSORBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	263196	RING NUT	Enquire	To Order
	220351	RING NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	263195	CAP	Enquire	To Order
	251483	SPRING RETAINER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	220383	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	220377	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	220378	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	280650	FRONT LH DISC SHIELD	Enquire	To Order
	280651	FRONT RH DISC SHIELD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	250657	SCREW M6 X 14	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	267936	SHOCK ABSORBER BUSH	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	250394	STOP CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	293621	UPPER SPRING SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	188996	LOWER SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157630	BALL JOINT	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	312841	FRONT SUSPENSION SPRING	Enquire	To Order
	302533	FRONT SUSPENSION SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	237297	SCREW M12 X 1.25 X 8	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	237821	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12646921	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	255271	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104370	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228131	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228132	SPRING WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	289876	STABILISER BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	233210	BUSH FOR BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	245822	BUSHING RETAINER PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10791014	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601474	WAVY WASHER 10MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	246119	BALL-JOINT TIE-ROD	Enquire	ARRIVING SOON
	246120	BALL-JOINT TIE-ROD	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	264117	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	248790	SCREW M12 X 1.25 X 50	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	300214	ACTUATOR	Enquire	ARRIVING SOON
	262384	ACTUATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	260409	HOSE FOR VEHICLE LIFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	261587	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	259638	GASKET 8.7 - 14	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	302409	FRONT SHOCK ABSORBER	302409 FRONT SHOCK ABSORBER	-	2	Enquire
2	263196	RING NUT	263196 RING NUT Vehicle lift system	-	2	Enquire
2	220351	RING NUT	220351 RING NUT	-	2	Enquire
3	263195	CAP	263195 CAP Vehicle lift system	-	2	Enquire
3	251483	SPRING RETAINER	251483 SPRING RETAINER	-	2	Enquire
4	220383	BUSH	220383 BUSH	-	2	Enquire
5	220377	WASHER	220377 WASHER	-	2	Enquire
6	220378	NUT	220378 NUT	-	2	Enquire
7	280650	FRONT LH DISC SHIELD	280650 FRONT LH DISC SHIELD	-	1	Enquire
7	280651	FRONT RH DISC SHIELD	280651 FRONT RH DISC SHIELD	-	1	Enquire
8	250657	SCREW M6 X 14	250657 SCREW M6 X 14	-	4	Enquire
9	267936	SHOCK ABSORBER BUSH ARRIVING SOON	267936 SHOCK ABSORBER BUSH ARRIVING SOON	-	2	Enquire
10	250394	STOP CAP	250394 STOP CAP	-	2	Enquire
11	293621	UPPER SPRING SPACER	293621 UPPER SPRING SPACER	-	2	Enquire
12	188996	LOWER SPACER	188996 LOWER SPACER	-	2	Enquire
13	157630	BALL JOINT ARRIVING SOON	157630 BALL JOINT ARRIVING SOON	-	2	Enquire
14	312841	FRONT SUSPENSION SPRING	312841 FRONT SUSPENSION SPRING Vehicle lift system	-	2	Enquire
14	302533	FRONT SUSPENSION SPRING	302533 FRONT SUSPENSION SPRING	-	2	Enquire
15	237297	SCREW M12 X 1.25 X 8	237297 SCREW M12 X 1.25 X 8	-	2	Enquire
16	237821	BUSH	237821 BUSH	-	2	Enquire
17	12646921	WASHER	12646921 WASHER	-	2	Enquire
18	255271	NUT	255271 NUT	-	2	Enquire
20	104370	SCREW	104370 SCREW	-	2	Enquire
21	228131	SCREW	228131 SCREW	-	2	Enquire
22	228132	SPRING WASHER	228132 SPRING WASHER	-	4	Enquire
23	289876	STABILISER BAR	289876 STABILISER BAR	-	1	Enquire
24	233210	BUSH FOR BAR	233210 BUSH FOR BAR	-	2	Enquire
25	245822	BUSHING RETAINER PLATE	245822 BUSHING RETAINER PLATE	-	2	Enquire
26	10791014	NUT	10791014 NUT	-	2	Enquire
27	12601474	WAVY WASHER 10MM	12601474 WAVY WASHER 10MM	-	4	Enquire
28	246119	BALL-JOINT TIE-ROD ARRIVING SOON	246119 BALL-JOINT TIE-ROD ARRIVING SOON	-	1	Enquire
28	246120	BALL-JOINT TIE-ROD ARRIVING SOON	246120 BALL-JOINT TIE-ROD ARRIVING SOON	-	1	Enquire
29	264117	SCREW	264117 SCREW	-	4	Enquire
30	248790	SCREW M12 X 1.25 X 50	248790 SCREW M12 X 1.25 X 50	-	4	Enquire
31	300214	ACTUATOR ARRIVING SOON	300214 ACTUATOR Version with lifter; Applicable for shock absorber 310994; Applicable from Ass. No. 124808 ARRIVING SOON	-	2	Enquire
31	262384	ACTUATOR	262384 ACTUATOR Version with lifter; Applicable for shock absorber 302263; Applicable up to Ass. No. 124807	-	2	Enquire
32	260409	HOSE FOR VEHICLE LIFT	260409 HOSE FOR VEHICLE LIFT Vehicle lift system	-	2	Enquire
33	261587	HOSE	261587 HOSE Vehicle lift system	-	2	Enquire
34	259638	GASKET 8.7 - 14	259638 GASKET 8.7 - 14 Vehicle lift system	-	4	Enquire
