Name: BRAKE SYSTEM
Rating: 4.7 (1 reviews)

BRAKE SYSTEM of Ferrari Ferrari 458 Speciale Aperta

View All

Ferrari 458 Speciale Aperta - BRAKE SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	296431	HYDRAULIC UNIT	$4,672.57	To Order

Photo	Part No	Description	Price (each)	Stock
	276926	BRACKET	$208.58	To Order
	275573	BRACKET	$152.42	To Order

Photo	Part No	Description	Price (each)	Stock
	246864	GROMMET	$3.65	To Order

Photo	Part No	Description	Price (each)	Stock
	246917	SHIM	$6.37	To Order

Photo	Part No	Description	Price (each)	Stock
	12625224	WASHER	$0.06	To Order

Photo	Part No	Description	Price (each)	Stock
	13839224	SCREW	$2.82	To Order

Photo	Part No	Description	Price (each)	Stock
	317783	YAW SENSOR	$528.93	To Order
	307688	YAW SENSOR	$270.61	To Order

Photo	Part No	Description	Price (each)	Stock
	16286124	SCREW	$0.37	To Order

Photo	Part No	Description	Price (each)	Stock
	262438	FRONT RH BRAKE PIPE	$110.70	To Order
	263877	FRONT RH BRAKE PIPE	$188.53	To Order

Photo	Part No	Description	Price (each)	Stock
	267850	FRONT LH BRAKE PIPE	$77.00	To Order
	263876	FRONT LH BRAKE PIPE	$96.26	To Order

Photo	Part No	Description	Price (each)	Stock
	302066	REAR RH BRAKE PIPE	$57.75	To Order
	295939	REAR RH BRAKE PIPE	$59.35	To Order

Photo	Part No	Description	Price (each)	Stock
	302065	REAR LH BRAKE PIPE	$56.14	To Order
	295940	REAR LH BRAKE PIPE	$64.17	To Order

Photo	Part No	Description	Price (each)	Stock
	268086	PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT	$85.03	To Order
	279894	PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT	$83.42	To Order

Photo	Part No	Description	Price (each)	Stock
	268085	PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT	$81.82	To Order
	262401	PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT	$545.55	To Order

Photo	Part No	Description	Price (each)	Stock
	295938	UNDERFLOOR REAR RH BRAKE PIPE	$51.33	To Order

Photo	Part No	Description	Price (each)	Stock
	295937	UNDERFLOOR REAR LH BRAKE PIPE	$51.33	To Order

Photo	Part No	Description	Price (each)	Stock
	263892	REAR SUBFRAME RH BRAKE PIPE	$56.14	To Order

Photo	Part No	Description	Price (each)	Stock
	263893	REAR SUBFRAME LH BRAKE PIPE	$54.54	To Order

Photo	Part No	Description	Price (each)	Stock
	254195	CLIP	$1.47	To Order

Photo	Part No	Description	Price (each)	Stock
	262737	RUBBER RETAINER	$6.56	To Order

Photo	Part No	Description	Price (each)	Stock
	249650	CLIP	$0.41	To Order

Photo	Part No	Description	Price (each)	Stock
	249649	CLIP	$0.81	To Order

Photo	Part No	Description	Price (each)	Stock
	212645	CLIP	$2.97	To Order

Photo	Part No	Description	Price (each)	Stock
	279762	CLAMP	$0.47	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	278412	RETAINER BLOCK FOR 2 PIPES	$11.70	To Order

Photo	Part No	Description	Price (each)	Stock
	279844	RETAINER PLATE	$5.49	To Order

Photo	Part No	Description	Price (each)	Stock
	67315400	WASHER	$0.44	IN STOCK

Photo	Part No	Description	Price (each)	Stock
	232869	BUSH	$40.10	To Order

Photo	Part No	Description	Price (each)	Stock
	235682	PIPE CLIP	$0.68	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	296431	HYDRAULIC UNIT	296431 HYDRAULIC UNIT	$4,672.57	1
2	276926	BRACKET	276926 BRACKET Applicable for GD	$208.58	1
2	275573	BRACKET	275573 BRACKET Not for GD	$152.42	1
3	246864	GROMMET	246864 GROMMET	$3.65	3
4	246917	SHIM	246917 SHIM	$6.37	3
5	12625224	WASHER	12625224 WASHER	$0.06 MSRP: ~~0.25~~ (76% off)	3
6	13839224	SCREW	13839224 SCREW M8 X 25	$2.82	3
7	317783	YAW SENSOR	317783 YAW SENSOR Applicable after depletion of 206070	$528.93	1
7	307688	YAW SENSOR	307688 YAW SENSOR Applicable until depletion	$270.61	1
8	16286124	SCREW	16286124 SCREW	$0.37	2
9	262438	FRONT RH BRAKE PIPE	262438 FRONT RH BRAKE PIPE Applicable for GD	$110.70	1
9	263877	FRONT RH BRAKE PIPE	263877 FRONT RH BRAKE PIPE Not for GD	$188.53	1
10	267850	FRONT LH BRAKE PIPE	267850 FRONT LH BRAKE PIPE Applicable for GD	$77.00	1
10	263876	FRONT LH BRAKE PIPE	263876 FRONT LH BRAKE PIPE Not for GD	$96.26	1
11	302066	REAR RH BRAKE PIPE	302066 REAR RH BRAKE PIPE Applicable for GD	$57.75	1
11	295939	REAR RH BRAKE PIPE	295939 REAR RH BRAKE PIPE Not for GD	$59.35	1
12	302065	REAR LH BRAKE PIPE	302065 REAR LH BRAKE PIPE Applicable for GD	$56.14	1
12	295940	REAR LH BRAKE PIPE	295940 REAR LH BRAKE PIPE Not for GD	$64.17	1
13	268086	PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT	268086 PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT Applicable for GD	$85.03	1
13	279894	PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT	279894 PIPE FROM FRONT BRAKE PUMP TO HYDRAULIC UNIT Not for GD	$83.42	1
14	268085	PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT	268085 PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT Applicable for GD	$81.82	1
14	262401	PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT	262401 PIPE FROM REAR BRAKE PUMP TO HYDRAULIC UNIT Not for GD	$545.55	1
15	295938	UNDERFLOOR REAR RH BRAKE PIPE	295938 UNDERFLOOR REAR RH BRAKE PIPE	$51.33	1
16	295937	UNDERFLOOR REAR LH BRAKE PIPE	295937 UNDERFLOOR REAR LH BRAKE PIPE	$51.33	1
17	263892	REAR SUBFRAME RH BRAKE PIPE	263892 REAR SUBFRAME RH BRAKE PIPE	$56.14	1
18	263893	REAR SUBFRAME LH BRAKE PIPE	263893 REAR SUBFRAME LH BRAKE PIPE	$54.54	1
19	254195	CLIP	254195 CLIP	$1.47	1
20	262737	RUBBER RETAINER	262737 RUBBER RETAINER	$6.56	7
21	249650	CLIP	249650 CLIP	$0.41	7
22	249649	CLIP	249649 CLIP	$0.81	2
23	212645	CLIP	212645 CLIP	$2.97	2
24	279762	CLAMP IN STOCK	279762 CLAMP IN STOCK	$0.47	2
25	278412	RETAINER BLOCK FOR 2 PIPES	278412 RETAINER BLOCK FOR 2 PIPES	$11.70	3
26	279844	RETAINER PLATE	279844 RETAINER PLATE	$5.49	3
27	67315400	WASHER IN STOCK	67315400 WASHER IN STOCK	$0.44	3
28	232869	BUSH	232869 BUSH	$40.10	3
29	235682	PIPE CLIP	235682 PIPE CLIP Applicable for GD	$0.68	1

Brake System

Ferrari 458 Speciale Aperta

Ferrari 458 Speciale Aperta - BRAKE SYSTEM
