Name: FUEL PUMPS AND CONNECTION LINES
Rating: 5.0 (1 reviews)

View All

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	214369	Fuel Pump With Sender	$575.33	To Order

Photo	Part No	Description	Price (each)	Stock
	181682	FUEL PUMP RETAINER RING NUT	$38.27	To Order

Photo	Part No	Description	Price (each)	Stock
	181681	Fuel Pump Gasket	$34.92	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	219391	FUEL DELIVERY PIPE	$40.98	To Order

Photo	Part No	Description	Price (each)	Stock
	218483	FUEL PIPE FROM PUMP TO CONNECTION	$135.69	To Order

Photo	Part No	Description	Price (each)	Stock
	225024	FUEL PIPE FROM CONNECTION TO ENGINE	$78.01	To Order

Photo	Part No	Description	Price (each)	Stock
	209820	R.H. FUEL DELIVERY TUBE	$81.86	To Order

Photo	Part No	Description	Price (each)	Stock
	209821	L.H. FUEL DELIVERY TUBE	$103.85	To Order

Photo	Part No	Description	Price (each)	Stock
	179087	INERTIA SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13355424	SCREW	$31.70	To Order

Photo	Part No	Description	Price (each)	Stock
	198253	CLIP	$10.86	To Order

Photo	Part No	Description	Price (each)	Stock
	198271	CLIP	$3.53	To Order

Photo	Part No	Description	Price (each)	Stock
	215338	RH FUEL PIPE WITH INJECTORS	$1,546.76	To Order

Photo	Part No	Description	Price (each)	Stock
	215337	LH FUEL PIPE WITH INJECTORS	$1,416.71	To Order

Photo	Part No	Description	Price (each)	Stock
	13516824	STUD	$13.13	To Order

Photo	Part No	Description	Price (each)	Stock
	16102314	NUTM8	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	11198074	WASHER D.8.5-15 X 1.8	$1.62	To Order

View All

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	214369	Fuel Pump With Sender	214369 Fuel Pump With Sender	$575.33	1
2	181682	FUEL PUMP RETAINER RING NUT	181682 FUEL PUMP RETAINER RING NUT	$38.27	1
3	181681	Fuel Pump Gasket ARRIVING SOON	181681 Fuel Pump Gasket ARRIVING SOON	$34.92	1
4	219391	FUEL DELIVERY PIPE	219391 FUEL DELIVERY PIPE	$40.98	1
5	218483	FUEL PIPE FROM PUMP TO CONNECTION	218483 FUEL PIPE FROM PUMP TO CONNECTION	$135.69	1
6	225024	FUEL PIPE FROM CONNECTION TO ENGINE	225024 FUEL PIPE FROM CONNECTION TO ENGINE	$78.01	1
7	209820	R.H. FUEL DELIVERY TUBE	209820 R.H. FUEL DELIVERY TUBE	$81.86	1
8	209821	L.H. FUEL DELIVERY TUBE	209821 L.H. FUEL DELIVERY TUBE	$103.85	1
9	179087	INERTIA SWITCH	179087 INERTIA SWITCH	-	1	Enquire
10	13355424	SCREW	13355424 SCREW M5X18	$31.70	2
12	198253	CLIP	198253 CLIP	$10.86	1
13	198271	CLIP	198271 CLIP	$3.53	2
14	215338	RH FUEL PIPE WITH INJECTORS	215338 RH FUEL PIPE WITH INJECTORS	$1,546.76	1
15	215337	LH FUEL PIPE WITH INJECTORS	215337 LH FUEL PIPE WITH INJECTORS	$1,416.71	1
16	13516824	STUD	13516824 STUD	$13.13	4
17	16102314	NUTM8	16102314 NUTM8 M8	$1.97	4
18	11198074	WASHER D.8.5-15 X 1.8	11198074 WASHER D.8.5-15 X 1.8 D.8.5-15X1.8	$1.62	4
19	233484	CLIP	233484 CLIP	$12.40	14
19	213603	CLIP	213603 CLIP	$2.83	1
