Rear suspension of Maserati Maserati GranTurismo MC Stradale

View All

Maserati GranTurismo MC Stradale - Rear suspension

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	980139890	Rear Suspension Bushing Kit	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15541334	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194444	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	198043	SPACER	Enquire	To Order
	198044	SPACER	Enquire	To Order
	198045	SPACER	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	12647678	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148020	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	245240	FLANGED NUT M14 X 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	260766	ECCENTRIC SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	194445	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	198038	SPACER 0.5MM	Enquire	To Order
	198039	SPACER 0.75MM	Enquire	To Order
	198040	SPACER	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	240877	Washer (Eccentric)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	203795	Nut M14 x 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	245240	FLANGED NUT M14 X 1.5	Enquire	To Order
	247308	NUT FOR SUSPENSION LEVER ADJUSTING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	276636	Tie Rod For Toe In Adjustment	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	12574521	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12626224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12574521	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12626224	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	216713	REAR STABILIZER BAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	200586	BAR BUFFER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	191221	PAD FASTENING PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NYLOC NUT M8 X 1.25 X 9.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14496524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	259573	Ball Tie Rod	Enquire	ARRIVING SOON
	259572	RH Front / LH Rear Roll Bar Link	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102742	Nyloc Nut M10x1.25x10	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12601474	Wavy Washer 10mm	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228958	TIE ROD FOR LIGHT ADJUSTING POTENTIOMETER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14498824	WASHERD.6.4-16.3X1	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16324034	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	204008	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	240877	Washer (Eccentric)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	203795	Nut M14 x 1.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	204010	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	160019	JOINT LOWER PROTECTION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	160019	JOINT LOWER PROTECTION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	222203	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150738	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231274	BRACKET	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	980145366	LH Rear Suspension Kit	980145366 LH Rear Suspension Kit	-	1	Enquire
-	980145365	RH Rear Suspension Kit	980145365 RH Rear Suspension Kit	-	1	Enquire
3	980139890	Rear Suspension Bushing Kit	980139890 Rear Suspension Bushing Kit	-	2	Enquire
4	15541334	SCREW	15541334 SCREW	-	4	Enquire
5	194444	WASHER	194444 WASHER	-	8	Enquire
6	198043	SPACER	198043 SPACER	-	8	Enquire
6	198044	SPACER	198044 SPACER	-	8	Enquire
6	198045	SPACER	198045 SPACER	-	8	Enquire
6	198046	SPACER	198046 SPACER	-	8	Enquire
6	198047	SPACER	198047 SPACER	-	8	Enquire
7	12647678	WASHER	12647678 WASHER	-	4	Enquire
8	148020	NUT	148020 NUT	-	4	Enquire
9	245240	FLANGED NUT M14 X 1.5	245240 FLANGED NUT M14 X 1.5	-	2	Enquire
12	260766	ECCENTRIC SCREW	260766 ECCENTRIC SCREW	-	4	Enquire
13	194445	WASHER	194445 WASHER	-	6	Enquire
14	198038	SPACER 0.5MM	198038 SPACER 0.5MM	-	8	Enquire
14	198039	SPACER 0.75MM	198039 SPACER 0.75MM	-	8	Enquire
14	198040	SPACER	198040 SPACER	-	8	Enquire
14	198041	SPACER 1.75MM	198041 SPACER 1.75MM	-	8	Enquire
14	198042	SPACER	198042 SPACER	-	8	Enquire
15	240877	Washer (Eccentric)	240877 Washer (Eccentric)	-	4	Enquire
16	203795	Nut M14 x 1.5	203795 Nut M14 x 1.5	-	4	Enquire
17	245240	FLANGED NUT M14 X 1.5	245240 FLANGED NUT M14 X 1.5	-	2	Enquire
17	247308	NUT FOR SUSPENSION LEVER ADJUSTING	247308 NUT FOR SUSPENSION LEVER ADJUSTING	-	1	Enquire
18	276636	Tie Rod For Toe In Adjustment ARRIVING SOON	276636 Tie Rod For Toe In Adjustment ARRIVING SOON	-	2	Enquire
19	12574521	NUT	12574521 NUT	-	2	Enquire
20	12626224	WASHER	12626224 WASHER	-	2	Enquire
21	12574521	NUT	12574521 NUT	-	2	Enquire
22	12626224	WASHER	12626224 WASHER	-	2	Enquire
23	216713	REAR STABILIZER BAR	216713 REAR STABILIZER BAR	-	1	Enquire
24	200586	BAR BUFFER	200586 BAR BUFFER	-	2	Enquire
25	191221	PAD FASTENING PLATE	191221 PAD FASTENING PLATE	-	2	Enquire
26	104030	NYLOC NUT M8 X 1.25 X 9.5	104030 NYLOC NUT M8 X 1.25 X 9.5	-	4	Enquire
27	14496524	WASHER	14496524 WASHER	-	4	Enquire
28	259573	Ball Tie Rod ARRIVING SOON	259573 Ball Tie Rod ARRIVING SOON	-	1	Enquire
28	259572	RH Front / LH Rear Roll Bar Link	259572 RH Front / LH Rear Roll Bar Link	-	1	Enquire
29	102742	Nyloc Nut M10x1.25x10	102742 Nyloc Nut M10x1.25x10	-	2	Enquire
30	12601474	Wavy Washer 10mm	12601474 Wavy Washer 10mm	-	2	Enquire
31	228958	TIE ROD FOR LIGHT ADJUSTING POTENTIOMETER	228958 TIE ROD FOR LIGHT ADJUSTING POTENTIOMETER	-	1	Enquire
32	14039614	NUT	14039614 NUT	-	2	Enquire
33	14498824	WASHERD.6.4-16.3X1	14498824 WASHERD.6.4-16.3X1	-	2	Enquire
34	16324034	SCREW	16324034 SCREW	-	2	Enquire
35	204008	STUD	204008 STUD	-	2	Enquire
36	240877	Washer (Eccentric)	240877 Washer (Eccentric)	-	4	Enquire
37	203795	Nut M14 x 1.5	203795 Nut M14 x 1.5	-	4	Enquire
38	204010	NUT	204010 NUT	-	2	Enquire
39	160019	JOINT LOWER PROTECTION	160019 JOINT LOWER PROTECTION	-	2	Enquire
40	160019	JOINT LOWER PROTECTION	160019 JOINT LOWER PROTECTION	-	2	Enquire
41	222203	SPACER	222203 SPACER	-	2	Enquire
42	150738	CLIP	150738 CLIP	-	2	Enquire
43	231274	BRACKET	231274 BRACKET	-	1	Enquire
