RH Cylinder Head of Maserati Maserati GranTurismo MC Stradale

View All

Maserati GranTurismo MC Stradale - RH Cylinder Head

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	271221	RH HEAD ASSEMBLY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	266262	RH Head Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	321187	CYLINDER HEAD NUT & WASHER KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151117	WASHER 11.25-22X2.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282756	THREADED PLUG subject to maserati technical service authorisation	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	282755	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	199760	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	243721	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	243719	SCREWM6X35	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	226414	DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13543424	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296016	Oil Pressure Check Valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304124	SCREW TCEI M5 x 12	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11181574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228962	Solenoid Valve Gasket	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	223982	Spark Plug Hole Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	980145469	RH HEAD COVER KIT	Enquire	To Order
	272790	RH CYLINDER HEAD COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	211219	RH Head Cover Gasket	Enquire	To Order
	264986	RH Head Cover Gasket	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	203102	RUBBER BUSHING	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	228598	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	213129	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13525970	THREADED INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	265569	R.H. AIR VALVE FIXING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	980145469	RH HEAD COVER KIT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	271221	RH HEAD ASSEMBLY	271221 RH HEAD ASSEMBLY	-	1	Enquire
2	266262	RH Head Gasket	266262 RH Head Gasket	-	1	Enquire
3	321187	CYLINDER HEAD NUT & WASHER KIT	321187 CYLINDER HEAD NUT & WASHER KIT	-	10	Enquire
4	151117	WASHER 11.25-22X2.5	151117 WASHER 11.25-22X2.5	-	10	Enquire
5	282756	THREADED PLUG subject to maserati technical service authorisation	282756 THREADED PLUG subject to maserati technical service authorisation	-	5	Enquire
6	282755	THREADED PLUG	282755 THREADED PLUG	-	4	Enquire
7	199760	THREADED PLUG	199760 THREADED PLUG	-	5	Enquire
8	102725	CENTERING DOWEL	102725 CENTERING DOWEL	-	2	Enquire
9	243721	SCREW	243721 SCREW	-	6	Enquire
10	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	6	Enquire
11	102725	CENTERING DOWEL	102725 CENTERING DOWEL	-	16	Enquire
12	243719	SCREWM6X35	243719 SCREWM6X35	-	16	Enquire
13	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	16	Enquire
14	226414	DOWEL	226414 DOWEL	-	1	Enquire
15	13543424	STUD	13543424 STUD	-	8	Enquire
16	296016	Oil Pressure Check Valve	296016 Oil Pressure Check Valve	-	1	Enquire
17	14304124	SCREW TCEI M5 x 12	14304124 SCREW TCEI M5 x 12	-	1	Enquire
18	11181574	WASHER	11181574 WASHER	-	1	Enquire
19	228962	Solenoid Valve Gasket ARRIVING SOON	228962 Solenoid Valve Gasket ARRIVING SOON	-	1	Enquire
20	223982	Spark Plug Hole Gasket	223982 Spark Plug Hole Gasket	-	4	Enquire
21	980145469	RH HEAD COVER KIT	980145469 RH HEAD COVER KIT	-	1	Enquire
21	272790	RH CYLINDER HEAD COVER	272790 RH CYLINDER HEAD COVER	-	1	Enquire
22	211219	RH Head Cover Gasket	211219 RH Head Cover Gasket	-	1	Enquire
22	264986	RH Head Cover Gasket ARRIVING SOON	264986 RH Head Cover Gasket ARRIVING SOON	-	1	Enquire
23	203102	RUBBER BUSHING ARRIVING SOON	203102 RUBBER BUSHING ARRIVING SOON	-	14	Enquire
24	228598	BUSHING	228598 BUSHING	-	14	Enquire
25	213129	SCREW	213129 SCREW	-	14	Enquire
26	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	14	Enquire
27	13525970	THREADED INSERT	13525970 THREADED INSERT	-	1	Enquire
28	265569	R.H. AIR VALVE FIXING BRACKET	265569 R.H. AIR VALVE FIXING BRACKET	-	1	Enquire
29	980145469	RH HEAD COVER KIT	980145469 RH HEAD COVER KIT	-	1	Enquire
