BRAKING SYSTEM of Maserati Maserati 4200 Coupe (2002-2004) GT

View All

Maserati 4200 Coupe (2002-2004) GT - BRAKING SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	198983	HYDRAULIC GROUP	Enquire	To Order
	192444	HYDRAULIC GROUP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	195570	CONTROL UNIT FIXING BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	193877	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231617	SCREW M6 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12646604	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	207998	BRAKE PIPE FROM ABS CENTER UNITTO L.H. FRONTFLEXIBLE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208018	RH FRONT BRAKE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	196845	FRONT BRAKE PIPE FROM PUMP TO UNIT	Enquire	To Order
	208020	FRONT BRAKE PIPE FROM PUMP TO UNIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208019	REAR BRAKE PIPE FROM PUMP TO UNIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208011	L.H. REAR BRAKE PIPE	Enquire	To Order
	195581	L.H. REAR BRAKE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	195582	R.H. REAR BRAKE PIPE	Enquire	To Order
	208012	R.H. REAR BRAKE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	202776	LH FRONT CALIPER RIGID PIPE	Enquire	To Order
	185954	RH FRONT CALIPER RIGID PIPE	Enquire	To Order
	202777	RH FRONT CALIPER RIGID PIPE	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	181897	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185956	BRAKE FLEXIBLE PIPE TO FRONT CALIPERS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	228185	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232160	VERTICAL ACCELERATION SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14084111	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185792	R.H.BRAKE PIPE SUPPORT BRACKET	Enquire	To Order
	202763	R.H.BRAKE PIPE SUPPORT BRACKET	Enquire	To Order
	185793	L.H.BRAKE PIPE SUPPORT BRACKET	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	14305324	Allen Screw 6 x 20	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519424	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208016	L.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208017	R.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208013	LH REAR CALIPER RIGID PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	208015	RH REAR CALIPER RIGID PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	387401155	BRAKE FLEXIBLE PIPE TO REAR CALIPERS	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	181897	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	327456313	SPACER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	387400330	UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	162606	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155751	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10977687	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638178	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187464	PIPES PROTECTION BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	387400402	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10977824	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11181574	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14447025	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	379200408	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	188335	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	212645	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	377430340	BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	198641	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	377400341	BLOCK	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155781	CLIP ANCHOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190409	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	377430346	CLIP	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	198983	HYDRAULIC GROUP	198983 HYDRAULIC GROUP Valid for F1	-	1	Enquire
1	192444	HYDRAULIC GROUP	192444 HYDRAULIC GROUP Not for F1	-	1	Enquire
2	195570	CONTROL UNIT FIXING BRACKET	195570 CONTROL UNIT FIXING BRACKET	-	1	Enquire
3	193877	CLIP	193877 CLIP	-	2	Enquire
4	231617	SCREW M6 X 18	231617 SCREW M6 X 18	-	2	Enquire
5	12646604	WASHER	12646604 WASHER	-	2	Enquire
6	14039614	NUT	14039614 NUT	-	1	Enquire
7	207998	BRAKE PIPE FROM ABS CENTER UNITTO L.H. FRONTFLEXIBLE PIPE	207998 BRAKE PIPE FROM ABS CENTER UNITTO L.H. FRONTFLEXIBLE PIPE	-	1	Enquire
8	208018	RH FRONT BRAKE PIPE	208018 RH FRONT BRAKE PIPE	-	1	Enquire
9	196845	FRONT BRAKE PIPE FROM PUMP TO UNIT	196845 FRONT BRAKE PIPE FROM PUMP TO UNIT	-	1	Enquire
9	208020	FRONT BRAKE PIPE FROM PUMP TO UNIT	208020 FRONT BRAKE PIPE FROM PUMP TO UNIT Valid after stock exhaustion of 196845	-	1	Enquire
10	208019	REAR BRAKE PIPE FROM PUMP TO UNIT	208019 REAR BRAKE PIPE FROM PUMP TO UNIT	-	1	Enquire
11	208011	L.H. REAR BRAKE PIPE	208011 L.H. REAR BRAKE PIPE Valid after stock exhaustion of 195581	-	1	Enquire
11	195581	L.H. REAR BRAKE PIPE	195581 L.H. REAR BRAKE PIPE	-	1	Enquire
12	195582	R.H. REAR BRAKE PIPE	195582 R.H. REAR BRAKE PIPE	-	1	Enquire
12	208012	R.H. REAR BRAKE PIPE	208012 R.H. REAR BRAKE PIPE Valid after stock exhaustion of 195582	-	1	Enquire
13	202776	LH FRONT CALIPER RIGID PIPE	202776 LH FRONT CALIPER RIGID PIPE Valid from car Ass. Nr. 13412	-	1	Enquire
13	185954	RH FRONT CALIPER RIGID PIPE	185954 RH FRONT CALIPER RIGID PIPE Valid till car Ass. Nr. 13411	-	1	Enquire
13	202777	RH FRONT CALIPER RIGID PIPE	202777 RH FRONT CALIPER RIGID PIPE Valid from car Ass. Nr. 13412	-	1	Enquire
13	185955	LH FRONT CALIPER RIGID PIPE	185955 LH FRONT CALIPER RIGID PIPE Valid till car Ass. Nr. 13411	-	1	Enquire
14	181897	CLIP	181897 CLIP	-	2	Enquire
15	185956	BRAKE FLEXIBLE PIPE TO FRONT CALIPERS	185956 BRAKE FLEXIBLE PIPE TO FRONT CALIPERS	-	2	Enquire
16	228185	CLIP	228185 CLIP	-	2	Enquire
17	232160	VERTICAL ACCELERATION SENSOR	232160 VERTICAL ACCELERATION SENSOR Optional- -Sport version	-	2	Enquire
18	14084111	NUT	14084111 NUT	-	2	Enquire
19	185792	R.H.BRAKE PIPE SUPPORT BRACKET	185792 R.H.BRAKE PIPE SUPPORT BRACKET Valid till car Ass. Nr. 13411	-	1	Enquire
19	202763	R.H.BRAKE PIPE SUPPORT BRACKET	202763 R.H.BRAKE PIPE SUPPORT BRACKET Valid from car Ass. Nr. 13412	-	1	Enquire
19	185793	L.H.BRAKE PIPE SUPPORT BRACKET	185793 L.H.BRAKE PIPE SUPPORT BRACKET Valid till car Ass. Nr. 13411	-	1	Enquire
19	202762	L.H.BRAKE PIPE SUPPORT BRACKET	202762 L.H.BRAKE PIPE SUPPORT BRACKET Valid from car Ass. Nr. 13412	-	1	Enquire
20	14305324	Allen Screw 6 x 20	14305324 Allen Screw 6 x 20	-	4	Enquire
21	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	4	Enquire
22	10519424	WASHER	10519424 WASHER	-	4	Enquire
23	208016	L.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	208016 L.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	-	1	Enquire
24	208017	R.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	208017 R.H. REAR CALIPER INTERMEDIATE BRAKE PIPE	-	1	Enquire
25	208013	LH REAR CALIPER RIGID PIPE	208013 LH REAR CALIPER RIGID PIPE	-	1	Enquire
26	208015	RH REAR CALIPER RIGID PIPE	208015 RH REAR CALIPER RIGID PIPE	-	1	Enquire
27	387401155	BRAKE FLEXIBLE PIPE TO REAR CALIPERS	387401155 BRAKE FLEXIBLE PIPE TO REAR CALIPERS	-	2	Enquire
28	181897	CLIP	181897 CLIP	-	2	Enquire
29	327456313	SPACER RING	327456313 SPACER RING	-	2	Enquire
30	387400330	UNION	387400330 UNION	-	2	Enquire
31	162606	CLIP	162606 CLIP	-	4	Enquire
32	155751	CLIP	155751 CLIP	-	2	Enquire
33	10977687	SCREW	10977687 SCREW	-	2	Enquire
34	12638178	Washer	12638178 Washer	-	2	Enquire
35	187464	PIPES PROTECTION BRACKET	187464 PIPES PROTECTION BRACKET	-	1	Enquire
36	387400402	GASKET	387400402 GASKET	-	1	Enquire
37	10977824	SCREW	10977824 SCREW	-	2	Enquire
38	11181574	WASHER	11181574 WASHER D.5.3-11X0.9	-	2	Enquire
39	14447025	WASHER	14447025 WASHER	-	2	Enquire
40	379200408	CLIP	379200408 CLIP	-	1	Enquire
41	188335	CLIP	188335 CLIP	-	1	Enquire
42	212645	CLIP	212645 CLIP	-	-	Enquire
43	377430340	BLOCK	377430340 BLOCK	-	-	Enquire
44	198641	CLIP	198641 CLIP	-	1	Enquire
45	377400341	BLOCK	377400341 BLOCK	-	1	Enquire
46	155781	CLIP ANCHOR	155781 CLIP ANCHOR	-	1	Enquire
47	190409	CLIP	190409 CLIP	-	-	Enquire
48	377430346	CLIP	377430346 CLIP	-	3	Enquire
