CLUTCH DISCS AND HOUSING FOR MECHANICAL GEARBOX (Not for F1) of Maserati Maserati 4200 Coupe (2002-2004) GT

View All

Maserati 4200 Coupe (2002-2004) GT - CLUTCH DISCS AND HOUSING FOR MECHANICAL GEARBOX (Not for F1)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	196021	Complete Clutch	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	980001166	CLUTCH BALANCING KIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	230426	Engine Flywheel Assembly	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	215963	FLYWHEEL FASTENING WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	201755	Bolt Hex Head M10 x 1.25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	185206	Screw M6 x 60	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11194379	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182952	Bearing Support Flange	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	234953	Clutch Release Bearing	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	172970	SCRAPER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	170416	Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	172972	SEAL RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154508	SEALING RING 44MM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154507	RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	154551	SCRAPER RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155207	PRELOAD SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	155206	SPACER FOR SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184970	CLUTCH CONTROL FLANGE SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305334	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184763	CLUTCH HOUSING CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	144511	LOCK RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	198389	BEARING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182963	LOCK RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182587	CLUTCH SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182584	CLUTCH OIL BLEED PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182583	CLUTCH OIL DELIVERY PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14305434	SCREWM6X25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	240774	TWO-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184900	F1 SENSOR SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14304424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10519378	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	152954	BLEEDER SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231625	SCREWM6X50	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102725	CENTERING DOWEL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13546334	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059421	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187799	EXHAUST FRONT SUPPORT	Enquire	To Order
	191399	EXHAUST FRONT SUPPORT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11730624	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16288121	SCREW	Enquire	To Order
	16297721	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	182225	CABLE FOR ENGINE-FRAME EARTH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	191346	BALANCING MASS	Enquire	To Order
	191347	BALANCING MASS	Enquire	To Order
	191395	BALANCING MASS	Enquire	To Order

...and 16 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	190876	STUD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10441290	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10979414	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	196021	Complete Clutch	196021 Complete Clutch	-	1	Enquire
2	980001166	CLUTCH BALANCING KIT	980001166 CLUTCH BALANCING KIT	-	1	Enquire
3	230426	Engine Flywheel Assembly	230426 Engine Flywheel Assembly	-	1	Enquire
4	215963	FLYWHEEL FASTENING WASHER	215963 FLYWHEEL FASTENING WASHER	-	1	Enquire
5	201755	Bolt Hex Head M10 x 1.25	201755 Bolt Hex Head M10 x 1.25	-	8	Enquire
6	185206	Screw M6 x 60	185206 Screw M6 x 60	-	9	Enquire
7	11194379	WASHER	11194379 WASHER	-	9	Enquire
8	182952	Bearing Support Flange	182952 Bearing Support Flange	-	1	Enquire
9	234953	Clutch Release Bearing	234953 Clutch Release Bearing	-	1	Enquire
10	172970	SCRAPER RING	172970 SCRAPER RING	-	1	Enquire
11	170416	Ring	170416 Ring	-	1	Enquire
12	172972	SEAL RING	172972 SEAL RING	-	1	Enquire
13	154508	SEALING RING 44MM	154508 SEALING RING 44MM	-	1	Enquire
14	154507	RING	154507 RING	-	1	Enquire
15	154551	SCRAPER RING	154551 SCRAPER RING	-	1	Enquire
16	155207	PRELOAD SPRING	155207 PRELOAD SPRING	-	2	Enquire
17	155206	SPACER FOR SPRING	155206 SPACER FOR SPRING	-	2	Enquire
18	184970	CLUTCH CONTROL FLANGE SUPPORT	184970 CLUTCH CONTROL FLANGE SUPPORT	-	1	Enquire
19	14305334	SCREW	14305334 SCREW	-	5	Enquire
20	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	5	Enquire
21	184763	CLUTCH HOUSING CAP	184763 CLUTCH HOUSING CAP	-	1	Enquire
22	144511	LOCK RING	144511 LOCK RING	-	1	Enquire
23	198389	BEARING	198389 BEARING	-	1	Enquire
24	182963	LOCK RING	182963 LOCK RING	-	1	Enquire
25	182587	CLUTCH SHAFT	182587 CLUTCH SHAFT	-	1	Enquire
26	182584	CLUTCH OIL BLEED PIPE	182584 CLUTCH OIL BLEED PIPE	-	1	Enquire
27	182583	CLUTCH OIL DELIVERY PIPE	182583 CLUTCH OIL DELIVERY PIPE	-	1	Enquire
28	14305434	SCREWM6X25	14305434 SCREWM6X25 M6X25	-	2	Enquire
29	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	2	Enquire
30	240774	TWO-WAY UNION	240774 TWO-WAY UNION	-	2	Enquire
31	184900	F1 SENSOR SUPPORT	184900 F1 SENSOR SUPPORT	-	1	Enquire
32	14304424	SCREW	14304424 SCREW	-	2	Enquire
33	10519378	WASHER	10519378 WASHER	-	2	Enquire
34	152954	BLEEDER SCREW	152954 BLEEDER SCREW	-	1	Enquire
35	231625	SCREWM6X50	231625 SCREWM6X50	-	4	Enquire
36	102725	CENTERING DOWEL	102725 CENTERING DOWEL	-	2	Enquire
37	13546334	STUD	13546334 STUD	-	8	Enquire
38	14059421	NUT	14059421 NUT	-	7	Enquire
39	187799	EXHAUST FRONT SUPPORT	187799 EXHAUST FRONT SUPPORT Not for USA, CDN, J, AUS and cars GB opt. japan version	-	1	Enquire
39	191399	EXHAUST FRONT SUPPORT	191399 EXHAUST FRONT SUPPORT Valid for USA, CDN, J, AUS and cars GB opt. japan version	-	1	Enquire
40	11730624	SCREW	11730624 SCREW	-	4	Enquire
41	16288121	SCREW	16288121 SCREW	-	1	Enquire
41	16297721	SCREW	16297721 SCREW	-	2	Enquire
42	182225	CABLE FOR ENGINE-FRAME EARTH	182225 CABLE FOR ENGINE-FRAME EARTH	-	1	Enquire
43	191346	BALANCING MASS	191346 BALANCING MASS Grams 18- -As necessary	-	-	Enquire
43	191347	BALANCING MASS	191347 BALANCING MASS Grams 19- -As necessary	-	-	Enquire
43	191395	BALANCING MASS	191395 BALANCING MASS Grams 20- -As necessary	-	-	Enquire
43	191342	BALANCING MASS	191342 BALANCING MASS Grams 14- -As necessary	-	-	Enquire
43	191343	BALANCING MASS	191343 BALANCING MASS Grams 15- -As necessary	-	-	Enquire
43	191344	BALANCING MASS	191344 BALANCING MASS Grams 16- -As necessary	-	-	Enquire
43	191345	BALANCING MASS	191345 BALANCING MASS Grams 17- -As necessary	-	-	Enquire
43	191338	BALANCING MASS	191338 BALANCING MASS Grams 10- -As necessary	-	-	Enquire
43	191339	BALANCING MASS	191339 BALANCING MASS Grams 11- -As necessary	-	-	Enquire
43	191340	BALANCING MASS	191340 BALANCING MASS Grams 12- -As necessary	-	-	Enquire
43	191341	BALANCING MASS	191341 BALANCING MASS Grams 13- -As necessary	-	-	Enquire
43	191334	BALANCING MASS	191334 BALANCING MASS Grams 6- -As necessary	-	-	Enquire
43	191335	BALANCING MASS	191335 BALANCING MASS Grams 7- -As necessary	-	-	Enquire
43	191336	BALANCING MASS	191336 BALANCING MASS Grams 8- -As necessary	-	-	Enquire
43	191337	BALANCING MASS	191337 BALANCING MASS Grams 9- -As necessary	-	-	Enquire
43	191329	BALANCING MASS	191329 BALANCING MASS Grams 1- -As necessary	-	-	Enquire
43	191330	BALANCING MASS	191330 BALANCING MASS Grams 2- -As necessary	-	-	Enquire
43	191331	BALANCING MASS	191331 BALANCING MASS Grams 4- -As necessary	-	-	Enquire
43	191333	BALANCING MASS	191333 BALANCING MASS Grams 5- -As necessary	-	-	Enquire
44	190876	STUD	190876 STUD	-	1	Enquire
45	10441290	BRACKET WITH SHEATH	10441290 BRACKET WITH SHEATH	-	1	Enquire
46	127494	WASHER	127494 WASHER	-	1	Enquire
47	10979414	SCREW	10979414 SCREW	-	1	Enquire
