Transparent Engine Hood of Lamborghini Lamborghini Murcielago LP670

View All

Lamborghini Murcielago LP670 - Transparent Engine Hood

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
000	R1470195	KIT ENGINE HOOD GLASSES	R1470195 KIT ENGINE HOOD GLASSES	$5,265.71	1
001	429827023	TRANSPARENT ENGINE HOOD	429827023 TRANSPARENT ENGINE HOOD	$43,185.34	1
002	418827322A	REFERENCE	418827322A REFERENCE	$975.82	1
003	WHT003407	WASHER	WHT003407 WASHER	$0.53 MSRP: ~~7.31~~ (92.7% off)	3
004	N90319404	SCREW	N90319404 SCREW	$1.89	5
005	417807333	SUPPORT	417807333 SUPPORT	$34.96	2
006	410827501B	LOCK	410827501B LOCK	$759.41	1
007	410827654	CLAMP	410827654 CLAMP	$197.59	2
008	410827421	ADJUSTER SCREW	410827421 ADJUSTER SCREW	$6.11	1
009	418827909	BRACKET	418827909 BRACKET	$45.05	1
010	410827665	SPRING	410827665 SPRING	$25.82	1
011	410814333	DOUBLE CLAMP	410814333 DOUBLE CLAMP	$340.06	1
012	6X0827439A	JOURNAL	6X0827439A JOURNAL	$74.35	2
013	418827401A	GAS STRUT	418827401A GAS STRUT	$114.97	2
014	418827531	ENGINE HOOD OPENING CABLE ASSEMBLY	418827531 ENGINE HOOD OPENING CABLE ASSEMBLY	$90.64	1
015	418827532	ENGINE HOOD EMERGENCY OPENING CABLE ASSEMBLY	418827532 ENGINE HOOD EMERGENCY OPENING CABLE ASSEMBLY	$72.74	1
016	895827439D	BALL STUD	895827439D BALL STUD	$9.00	2
017	N90319404	SCREW	N90319404 SCREW	$1.89	4
018	WHT003407	WASHER	WHT003407 WASHER	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
019	410827602	RH BRACKET	410827602 RH BRACKET	$144.49	1
020	400827185	HANDLE	400827185 HANDLE	$1,868.29	1
021	WHT003068	COUNTERSUNK BOLT	WHT003068 COUNTERSUNK BOLT	$1.43 MSRP: ~~7.17~~ (80.1% off)	1
022	N90319404	SCREW	N90319404 SCREW	$1.89	4
023	WHT003407	WASHER	WHT003407 WASHER	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
024	418827152	ENGINE HOOD LEFT HINGE ASSEMBLY	418827152 ENGINE HOOD LEFT HINGE ASSEMBLY	$670.71	1
025	418827151	ENGINE HOOD RIGHT HINGE ASSEMBLY	418827151 ENGINE HOOD RIGHT HINGE ASSEMBLY	$326.61	1
026	429971170	WIRING HARNESS	429971170 WIRING HARNESS	$383.07	1
027	429827991	PAVIVION	429827991 PAVIVION	$7,506.70	1
028	410827454	BRACKET	410827454 BRACKET	$19.26	1
029	429827631C	ENGINE HOOD GLASS	429827631C ENGINE HOOD GLASS	$4,193.53	1
030	429827632C	ENGINE HOOD GLASS	429827632C ENGINE HOOD GLASS	$4,193.53	1
031	63705504	GASKET (QTY IN METERS)	63705504 GASKET (QTY IN METERS)	$90.87	6
034	N90319404	SCREW	N90319404 SCREW	$1.89	4
035	WHT003407	WASHER	WHT003407 WASHER	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
036	418827603	RH BRACKET	418827603 RH BRACKET	$40.26	1
037	N10073601	PIN 3X14	N10073601 PIN 3X14	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
038	N1111611	NUT M6	N1111611 NUT M6	-	2	Enquire
040	429827446C	ENGINE HOOD GLASS	429827446C ENGINE HOOD GLASS	$4,193.53	1
