Pedal Support

Lamborghini Murcielago LP640 Roadster

Find Your Part

Lamborghini Murcielago LP640 Roadster - Pedal Support

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Pedal Support of Lamborghini Lamborghini Murcielago LP640 Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
002 3D0611301B
RESERVOIR FOR BRAKE FLUID 		- 1 Enquire
003 N90179103
WASHER 18X8,4X2,5 		- 4 Enquire
004 N0111849
NUT 		- 4 Enquire
005 WHT002647
RETAINING RING 		- 4 Enquire
006 410721381
STOP 		- 2 Enquire
007 410721196
BEARING 		- 3 Enquire
008 WHT002632
WASHER 		- 1 Enquire
009 1K2945511
SWITCH (WARNING USE 410721633B) 		- 1 Enquire
010 413721663A
SPACER 		- 1 Enquire
011 410721633E
SUPPORT (WARNING USE 1K2945511) 		- 1 Enquire
012 N10650701
HEXAGON SOCKET HEAD BOLT 		- 3 Enquire
013 N01152427
WASHER 		- 2 Enquire
014 410721648
SPACER (MANUAL GEARBOX) 		- 1 Enquire
015 N0111849
NUT 		- 4 Enquire
016 N90179103
WASHER 18X8,4X2,5 		- 4 Enquire
017 413721117A
PEDALS SUPPORT 		- 1 Enquire
018 410721134A
BUSHING 		- 4 Enquire
019 N10650701
HEXAGON SOCKET HEAD BOLT 		- 2 Enquire
020 413864777
COVER 		- 1 Enquire
022 4A0611817A
BUNGS 		- 2 Enquire
023 N90533005
HEXAGON HEAD BOLT (COMBI) 		- 1 Enquire
024 N91051101
SCREW M6X30 		- 1 Enquire
025 400616807
CHECK VALVE 		- 1 Enquire
026 400612100B
POWER BRAKE (COMPLETE) 		- 1 Enquire
