Rear Window Glass - Folding Top 1

Lamborghini Gallardo Spyder

Find Your Part

Lamborghini Gallardo Spyder - Rear Window Glass - Folding Top 1

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Rear Window Glass - Folding Top 1 of Lamborghini Lamborghini Gallardo Spyder Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 407813613F
FOLDING-TOP (INCLUDES REF. 2 - 3) 		- 1 Enquire
002 407863405A
LINING CONTAINER 		- 1 Enquire
003 407864401E
LINING FRONT,TOP BOX 		- 1 Enquire
004 4D0803583B
PLUG 		- 2 Enquire
005 407825402
SEAL,TOP BOX 		- 1 Enquire
006 N0103917
SCREW M8X100X41 		- 4 Enquire
007 N91000203
OVAL HEXAGON SOCKET HEAD BOLT 		- 4 Enquire
008 407827991
COVER 		- 1 Enquire
009 407871353
WATER DRAIN 		- 2 Enquire
010 407827460C
GASKET 		- 1 Enquire
011 407813953B
WATER DRIP TRAY LEFT 		- 1 Enquire
012 407813954B
WATER DRIP TRAY RIGHT 		- 1 Enquire
013 407880079A
ROLLOVER 		- 2 Enquire
014 407813921A
WATER DRAIN PIPE 		- 2 Enquire
016 407845051C
REAR WINDOW GLASS 		- 1 Enquire
017 407845535
WINDOW LIFTER 		- 1 Enquire
018 407813477
LH BRACKET 		- 1 Enquire
019 407813478
RH BRACKET 		- 1 Enquire
020 N10553801
SCREW M6X45 		- 4 Enquire
021 N90917201
SCREW 		- 8 Enquire
022 400863119
BUNGS 		- 17 Enquire
023 WHT001673
SCREW M8X100 		- 8 Enquire
024 407813919A
WATER DRAIN 		- 1 Enquire
025 407813920A
WATER DRAIN 		- 1 Enquire
026 N91048802
SCREW WITH INT. SERRATIONS 		- 4 Enquire
027 N90848003
HEX COLLARED BOLT 		- 4 Enquire
028 N90847903
Screw M6X15 		- 2 Enquire
