Rear Arms of Lamborghini Lamborghini Gallardo (2003-2005)

View All

Lamborghini Gallardo (2003-2005) - Rear Arms

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	400505311B	LOWER ARM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400511409	REAR STABILIZER BAR (UNTIL THE VIN 4LA01398)	Enquire	To Order
	400511409B	REAR STABILIZER BAR (FROM VIN 4LA01399)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400511324C	BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400411031H	STABILIZER BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)	Enquire	To Order
	400411031D	U-BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT000923	SCREW M6X52	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001197A	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400505465A	CONNECTING ROD (UNTIL THE VIN 6LA03288)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10286102	NUT (UNTIL THE VIN 6LA03288)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90323704	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10314503	SCREW (UNTIL THE VIN 6LA63288)	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10268602	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400505119	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400407749	0.5 MM SHIM	Enquire	To Order
	400407739	1.0 MM SHIM	Enquire	To Order
	400407740	1.5 MM SHIM	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	400411175A	SPACER	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
01	400505183	SCREW	400505183 SCREW	-	2	Enquire
02	400407171B	BUSHING	400407171B BUSHING	-	2	Enquire
03	400505179B	SPACER	400505179B SPACER	-	2	Enquire
04	N90323704	NUT	N90323704 NUT	-	2	Enquire
05	400505323B	UPPER ARM	400505323B UPPER ARM	-	2	Enquire
06	N91062101	STUD BOLT	N91062101 STUD BOLT	-	8	Enquire
07	N91062001	STUD BOLT	N91062001 STUD BOLT	-	8	Enquire
08	N90226404	HEXAGON COLLAR NUT SELF-LOCKING	N90226404 HEXAGON COLLAR NUT SELF-LOCKING	-	16	Enquire
09	400407379C	2 MM SHIM	400407379C 2 MM SHIM	-	16	Enquire
09	400407379A	1 MM SHIM	400407379A 1 MM SHIM	-	16	Enquire
09	400407379F	0.3 MM SHIM	400407379F 0.3 MM SHIM	-	16	Enquire
09	400407379E	3 MM SHIM	400407379E 3 MM SHIM	-	16	Enquire
09	400407379B	1.5 MM SHIM	400407379B 1.5 MM SHIM	-	16	Enquire
09	400407379D	2.5 MM SHIM	400407379D 2.5 MM SHIM	-	16	Enquire
09	400407379	0.5 MM SHIM	400407379 0.5 MM SHIM	-	16	Enquire
10	400505311B	LOWER ARM	400505311B LOWER ARM	-	2	Enquire
11	400511409	REAR STABILIZER BAR (UNTIL THE VIN 4LA01398)	400511409 REAR STABILIZER BAR (UNTIL THE VIN 4LA01398)	-	1	Enquire
11	400511409B	REAR STABILIZER BAR (FROM VIN 4LA01399)	400511409B REAR STABILIZER BAR (FROM VIN 4LA01399)	-	1	Enquire
12	400511324C	BUSH	400511324C BUSH	-	2	Enquire
13	400411031H	STABILIZER BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)	400411031H STABILIZER BAR BRACKET (UP TO VIN 4LA01398 - ALSO USE 400411324C)	-	2	Enquire
13	400411031D	U-BOLT	400411031D U-BOLT	-	2	Enquire
14	WHT000923	SCREW M6X52	WHT000923 SCREW M6X52	-	4	Enquire
15	WHT001197A	WASHER	WHT001197A WASHER	-	4	Enquire
16	400505465A	CONNECTING ROD (UNTIL THE VIN 6LA03288)	400505465A CONNECTING ROD (UNTIL THE VIN 6LA03288)	-	2	Enquire
18	N10286102	NUT (UNTIL THE VIN 6LA03288)	N10286102 NUT (UNTIL THE VIN 6LA03288)	-	2	Enquire
20	N90323704	NUT	N90323704 NUT	-	2	Enquire
22	N10314503	SCREW (UNTIL THE VIN 6LA63288)	N10314503 SCREW (UNTIL THE VIN 6LA63288)	-	2	Enquire
23	N10268602	NUT	N10268602 NUT	-	2	Enquire
24	400505119	SCREW	400505119 SCREW	-	2	Enquire
25	400407749	0.5 MM SHIM	400407749 0.5 MM SHIM	-	1	Enquire
25	400407739	1.0 MM SHIM	400407739 1.0 MM SHIM	-	1	Enquire
25	400407740	1.5 MM SHIM	400407740 1.5 MM SHIM	-	1	Enquire
25	400407742	2.0 MM SHIM	400407742 2.0 MM SHIM	-	1	Enquire
26	400411175A	SPACER	400411175A SPACER	-	2	Enquire
