Find Your Part

COOLING SYSTEM of Lamborghini Lamborghini Aventador LP770 SVJ Coupe

View All

Lamborghini Aventador LP770 SVJ Coupe - COOLING SYSTEM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	470121253G	COOLER FOR COOLANT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470959455E	RADIATOR FAN WITH CONTROL UNIT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121703D	SUPPORT FOR COOLANT RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121057F	COOLANT HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121061A	COOLANT HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121397B	VENT HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121107A	COOLANT HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121051B	COOLANT HOSE DA MOT.A FLEX.	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10533601	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001942	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT001189	PLASTIC WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400121277	DISTANCE PIECE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	400121268	RUBBER BUSH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470971850D	SPRING BAND CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91054101	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N0115478	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10558102	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90760301	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT003407	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10609201	HEXAGON COLLAR NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121113A	COOLANT REGULATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470821471	SUPPORT FOR COOLANT RADIATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90942301	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90688703	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470971850D	SPRING BAND CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	470121041	SEAL RING	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	R8340120	REPAIR SET	R8340120 REPAIR SET CAMPAIGN L83X-A.07. 14 & L83X-A. 08.14	-	1	Enquire
1	470121253G	COOLER FOR COOLANT	470121253G COOLER FOR COOLANT LEFT	-	1	Enquire
2	470959455E	RADIATOR FAN WITH CONTROL UNIT	470959455E RADIATOR FAN WITH CONTROL UNIT	-	1	Enquire
3	470121703D	SUPPORT FOR COOLANT RADIATOR	470121703D SUPPORT FOR COOLANT RADIATOR LEFT	-	1	Enquire
4	470121057F	COOLANT HOSE	470121057F COOLANT HOSE	-	1	Enquire
5	470121061A	COOLANT HOSE	470121061A COOLANT HOSE	-	1	Enquire
6	470121397B	VENT HOSE	470121397B VENT HOSE	-	1	Enquire
7	470121107A	COOLANT HOSE	470121107A COOLANT HOSE LEFT	-	1	Enquire
8	470121051B	COOLANT HOSE DA MOT.A FLEX.	470121051B COOLANT HOSE DA MOT.A FLEX. LEFT	-	1	Enquire
9	N10533601	SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD	N10533601 SOCKET HEAD BOLT WITH HEXAGON SOCKET HEAD M8X35	-	4	Enquire
10	WHT001942	WASHER	WHT001942 WASHER	-	4	Enquire
11	WHT001189	PLASTIC WASHER	WHT001189 PLASTIC WASHER	-	4	Enquire
12	400121277	DISTANCE PIECE	400121277 DISTANCE PIECE	-	4	Enquire
13	400121268	RUBBER BUSH	400121268 RUBBER BUSH	-	4	Enquire
14	470971850D	SPRING BAND CLAMP	470971850D SPRING BAND CLAMP ABA S40 INOX-47X12	-	5	Enquire
15	N91054101	OVAL HEXAGON SOCKET HEAD BOLT	N91054101 OVAL HEXAGON SOCKET HEAD BOLT M6X25	-	8	Enquire
16	N0115478	WASHER	N0115478 WASHER 6,5X14X1,6	-	4	Enquire
17	N10558102	SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD	N10558102 SOCKET HEAD BOLT WITH INNER MULTIPOINT HEAD M6X18	-	4	Enquire
18	N90760301	O-RING	N90760301 O-RING 39X3	-	1	Enquire
19	N10196103	OVAL SOCKET HEAD BOLT WITH HEX DRIVE	N10196103 OVAL SOCKET HEAD BOLT WITH HEX DRIVE M6X18	-	2	Enquire
20	WHT003407	WASHER	WHT003407 WASHER 6,4X16X2	-	2	Enquire
21	N10609201	HEXAGON COLLAR NUT	N10609201 HEXAGON COLLAR NUT M8	-	3	Enquire
22	470121113A	COOLANT REGULATOR	470121113A COOLANT REGULATOR	-	1	Enquire
23	470821471	SUPPORT FOR COOLANT RADIATOR	470821471 SUPPORT FOR COOLANT RADIATOR LEFT	-	1	Enquire
24	N90942301	CLAMP	N90942301 CLAMP 48X15	-	1	Enquire
25	N90688703	SPEED NUT	N90688703 SPEED NUT M6X24X16	-	1	Enquire
26	470971850D	SPRING BAND CLAMP	470971850D SPRING BAND CLAMP 47X12	-	5	Enquire
27	N91096701	OVAL HEXAGON SOCKET HEAD BOLT	N91096701 OVAL HEXAGON SOCKET HEAD BOLT M6X16	-	1	Enquire
28	470121041	SEAL RING	470121041 SEAL RING 14X2.62	-	1	Enquire
