View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
001	7M109305M	EXHAUST CAMSHAFT (BANK 1-6)	7M109305M EXHAUST CAMSHAFT (BANK 1-6)	$5,598.10	1
002	7M109303P	INTAKE CAMSHAFT (BANK 1-6)	7M109303P INTAKE CAMSHAFT (BANK 1-6)	$11,962.33	1
003	7M109309C	TAPPETS IN STOCK	7M109309C TAPPETS IN STOCK	$94.42	48
004	7M109651G	COTTER, SPLIT	7M109651G COTTER, SPLIT	$36.16	96
005	7M109641G	TAPPET UPPER PLATE (FROM VIN DLA01686)	7M109641G TAPPET UPPER PLATE (FROM VIN DLA01686)	$32.81	48
006	7M109623J	Outer Spring & Outer Spring Kit	7M109623J Outer Spring & Outer Spring Kit	$291.68	48
008	7M109675B	VALVE STEM SEAL IN STOCK	7M109675B VALVE STEM SEAL IN STOCK	$11.59	48
009	7M109642F	TAPPET LOWER PLATE (FROM VIN DLA01686)	7M109642F TAPPET LOWER PLATE (FROM VIN DLA01686)	$28.17	48
010	7M109304P	INTAKE CAMSHAFT (BANK 7-12)	7M109304P INTAKE CAMSHAFT (BANK 7-12)	$11,962.33	1
011	7M109306M	EXHAUST CAMSHAFT (BANK 7-12)	7M109306M EXHAUST CAMSHAFT (BANK 7-12)	$5,598.10	1
012	7M109611E	EXHAUST VALVE IN STOCK	7M109611E EXHAUST VALVE IN STOCK	$130.25	24
013	7M109601E	INTAKE VALVE IN STOCK	7M109601E INTAKE VALVE IN STOCK	$196.92	24
014	7M109349	SEAL RING IN STOCK	7M109349 SEAL RING IN STOCK	$51.45	4
015	R8340121	VALVE SPRING AND TAPPET PLATE KIT	R8340121 VALVE SPRING AND TAPPET PLATE KIT	$1,948.93	2
