Rear Frame Elements 1

Lamborghini Aventador LP700 Roadster

Find Your Part

Lamborghini Aventador LP700 Roadster - REAR FRAME ELEMENTS 1

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
REAR FRAME ELEMENTS 1 of Lamborghini Lamborghini Aventador LP700 Roadster Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 470813031B
REAR END ASSEMBLY (CONTACT YOUR AREA MANAGER) 		$24,966.32 1
002 470813249B
CROSS MEMBER 		$346.79 2
003 470814519D
CROSS MEMBER
IN STOCK 		$344.08 1
004 475814587
CROSS MEMBER 		$2,755.38 1
005 470814657B
ARM 		$58.46 1
005 470814658B
ARM 		$58.46 1
006 470814942B
Bracket (rear) 		$111.31 1
008 470814185B
Arm (left Rear) 		$42.61 1
008 470814186B
Arm (right Rear) 		$42.61 1
009 N0195306
BOLT, HEX. HD. WITH SHOULDER, SELF-LOCKING
IN STOCK 		$3.05 (57.3% off) 14
010 N90900401
HEX SOCKET OVAL HEAD COLLARED
IN STOCK 		$1.25 4
011 N90900401
HEX SOCKET OVAL HEAD COLLARED
IN STOCK 		$1.25 2
012 WHT001237
HEX SOCKET HEAD COLLARED BOLT
IN STOCK 		$1.43 (80% off) 2
013 N90798805
HEXAGON COLLAR NUT
IN STOCK 		$2.08 (71.5% off) 2
014 N90863802
HEXAGON HEAD BOLT (COMBI)
IN STOCK 		$1.47 (79.6% off) 6
015 470813465B
SIDE REINFORCEMENT 		$56.25 1
016 470813466B
SIDE REINFORCEMENT 		$56.25 1
017 N10761201
TOOTHED LOCK WASHER 		$6.20 2
