Lamborghini Aventador LP700 Roadster - WINDOWS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	470845099A	Windscreen (includes Ref.:- 19)	470845099A Windscreen (includes Ref.:- 19)	-	1	Enquire
002	475845201A	DOOR WINDOW	475845201A DOOR WINDOW	-	1	Enquire
002	475845202A	DOOR WINDOW	475845202A DOOR WINDOW	-	1	Enquire
003	475831707B	DOOR SEAL, INNER	475831707B DOOR SEAL, INNER	-	1	Enquire
003	475831708B	DOOR SEAL, INNER	475831708B DOOR SEAL, INNER	-	1	Enquire
004	475845300A	FIXED REAR RIGHT WINDOW GLASS	475845300A FIXED REAR RIGHT WINDOW GLASS	-	1	Enquire
004	475845299A	FIXED REAR LEFT WINDOW GLASS	475845299A FIXED REAR LEFT WINDOW GLASS	-	1	Enquire
005	475845695B	SEAL FOR REAR WINDOW	475845695B SEAL FOR REAR WINDOW	-	1	Enquire
006	470845115A	SIDE WINDOW (FIXED)	470845115A SIDE WINDOW (FIXED)	-	1	Enquire
006	470845116A	SIDE WINDOW (FIXED)	470845116A SIDE WINDOW (FIXED)	-	1	Enquire
007	475853797C	GASKET	475853797C GASKET	-	1	Enquire
008	470837911E	DOOR SEAL	470837911E DOOR SEAL	-	1	Enquire
008	470837912E	DOOR SEAL	470837912E DOOR SEAL	-	1	Enquire
010	476853645	Bracket	476853645 Bracket	-	6	Enquire
011	410806225	RIVET 3,5X11,5	410806225 RIVET 3,5X11,5	-	12	Enquire
012	475814581	COVER FOR WEATHER STRIP	475814581 COVER FOR WEATHER STRIP	-	2	Enquire
013	475813920A	WATER DRAIN PIPE	475813920A WATER DRAIN PIPE	-	2	Enquire
014	N9118301	SCREW M10X22	N9118301 SCREW M10X22	-	2	Enquire
015	475831731A	DOOR WEATHERSTRIP LH	475831731A DOOR WEATHERSTRIP LH	-	1	Enquire
015	475831732A	DOOR WEATHERSTRIP RH	475831732A DOOR WEATHERSTRIP RH	-	1	Enquire
016	475853701	LH ROOF MOLDING	475853701 LH ROOF MOLDING	-	1	Enquire
016	475853702	RH ROOF MOLDING	475853702 RH ROOF MOLDING	-	1	Enquire
