REAR SUSPENSION - SHOCK ABSORBER AND BRAKE DISC

Find Your Part

Ferrari 488 Spider - REAR SUSPENSION - SHOCK ABSORBER AND BRAKE DISC

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
325388 REAR SHOCK ABSORBER $1,877.36 To Order
317751 Rear Shock Absorber $1,909.46 ARRIVING SOON
Photo Part No Description Price (each) Stock
220351 RING NUT $57.75 To Order
Photo Part No Description Price (each) Stock
286402 CAP $176.49 To Order
Photo Part No Description Price (each) Stock
220383 BUSH $43.31 To Order
Photo Part No Description Price (each) Stock
220377 WASHER $8.09 To Order
Photo Part No Description Price (each) Stock
220378 NUT $4.80 To Order
Photo Part No Description Price (each) Stock
220325 PLATE $4.04 To Order
Photo Part No Description Price (each) Stock
237590 SCREW M10 X 1.25 X 50 $4.86 To Order
Photo Part No Description Price (each) Stock
281221 ENDSTOP BUSH, SHOCK ABSORBER $40.10 To Order
Photo Part No Description Price (each) Stock
250394 STOP CAP SHOCK ABSORBER $272.77 To Order
Photo Part No Description Price (each) Stock
212517 UPPER SPACER $11.86 To Order
Photo Part No Description Price (each) Stock
188996 LOWER SPACER $15.38 To Order
Photo Part No Description Price (each) Stock
157630 SHOCK ABSORBER BUSH $118.72 ARRIVING SOON
Photo Part No Description Price (each) Stock
309953 REAR SHOCK ABSORBER SPRING $186.33 To Order
Photo Part No Description Price (each) Stock
246962 SPECIAL SCREW $31.36 To Order
Photo Part No Description Price (each) Stock
14507987 PLUG $1.83 To Order
Photo Part No Description Price (each) Stock
237821 BUSH $4.86 To Order
Photo Part No Description Price (each) Stock
12646921 WASHER $0.53 To Order
Photo Part No Description Price (each) Stock
255271 NUT $1.41 To Order
Photo Part No Description Price (each) Stock
319166 REAR BRAKE DISC $4,450.44 To Order
Photo Part No Description Price (each) Stock
104370 SCREW $10.11 To Order
Photo Part No Description Price (each) Stock
228131 SCREW $0.83 To Order
Photo Part No Description Price (each) Stock
228132 SPRING WASHER $0.32 To Order
Photo Part No Description Price (each) Stock
825203 REAR AXLE SHAFT $1,251.57 To Order
Photo Part No Description Price (each) Stock
289880 STABILISER BAR $444.36 To Order
Photo Part No Description Price (each) Stock
240824 BUSH TORSION BAR $20.71 To Order
Photo Part No Description Price (each) Stock
244778 RETAINER BRACKET $24.05 To Order
Photo Part No Description Price (each) Stock
264117 SCREW $2.84 To Order
Photo Part No Description Price (each) Stock
250453 RH BALL-JOINT TIE-ROD $134.77 To Order
250452 LH BALL-JOINT TIE-ROD $134.77 To Order
Photo Part No Description Price (each) Stock
12601474 WASHER $0.03 To Order
Photo Part No Description Price (each) Stock
10791014 NUT $0.29 To Order
Photo Part No Description Price (each) Stock
248790 SCREW $4.04 To Order
Photo Part No Description Price (each) Stock
250657 SCREW $7.60 To Order
Photo Part No Description Price (each) Stock
257424 RH REAR DISC SHIELD $62.56 To Order
257423 LH REAR DISC SHIELD $62.56 To Order
Photo Part No Description Price (each) Stock
250811 SHIELD $27.26 To Order
Photo Part No Description Price (each) Stock
16286121 SCREW $0.70 To Order
Photo Part No Description Price (each) Stock
203780 HUB NUT HEX M28 $24.62 To Order
Photo Part No Description Price (each) Stock
70001387 GAITER REPLACEMENT KIT $141.19 To Order
70001388 GAITER REPLACEMENT KIT $176.49 To Order
View All
REAR SUSPENSION - SHOCK ABSORBER AND BRAKE DISC of Ferrari Ferrari 488 Spider Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 325388
REAR SHOCK ABSORBER
Applicable from Ass. No. 137582 		$1,877.36 2
1 317751
Rear Shock Absorber
Applicable up to Ass. No. 137581
ARRIVING SOON 		$1,909.46 2
2 220351
RING NUT 		$57.75 2
3 286402
CAP 		$176.49 2
4 220383
BUSH 		$43.31 2
5 220377
WASHER 		$8.09 2
6 220378
NUT 		$4.80 2
7 220325
PLATE 		$4.04 6
8 237590
SCREW M10 X 1.25 X 50 		$4.86 (2.6% off) 12
9 281221
ENDSTOP BUSH, SHOCK ABSORBER 		$40.10 2
10 250394
STOP CAP SHOCK ABSORBER 		$272.77 2
11 212517
UPPER SPACER 		$11.86 2
12 188996
LOWER SPACER 		$15.38 2
13 157630
SHOCK ABSORBER BUSH
ARRIVING SOON 		$118.72 (22% off) 2
14 309953
REAR SHOCK ABSORBER SPRING 		$186.33 2
15 246962
SPECIAL SCREW 		$31.36 2
16 14507987
PLUG 		$1.83 (25.3% off) 6
17 237821
BUSH 		$4.86 (11.6% off) 2
18 12646921
WASHER 		$0.53 2
19 255271
NUT 		$1.41 (2.8% off) 2
20 319166
REAR BRAKE DISC 		$4,450.44 2
21 104370
SCREW 		$10.11 2
22 228131
SCREW 		$0.83 2
23 228132
SPRING WASHER 		$0.32 4
24 825203
REAR AXLE SHAFT 		$1,251.57 2
25 289880
STABILISER BAR 		$444.36 1
26 240824
BUSH TORSION BAR 		$20.71 2
27 244778
RETAINER BRACKET 		$24.05 2
28 264117
SCREW 		$2.84 4
29 250453
RH BALL-JOINT TIE-ROD 		$134.77 (24.9% off) 1
29 250452
LH BALL-JOINT TIE-ROD 		$134.77 (24.9% off) 1
30 12601474
WASHER 		$0.03 4
31 10791014
NUT 		$0.29 2
32 248790
SCREW 		$4.04 4
33 250657
SCREW 		$7.60 6
34 257424
RH REAR DISC SHIELD 		$62.56 1
34 257423
LH REAR DISC SHIELD 		$62.56 (24.1% off) 1
35 250811
SHIELD 		$27.26 2
36 16286121
SCREW 		$0.70 (48.1% off) 6
37 203780
HUB NUT HEX M28 		$24.62 (4.6% off) 2
38 70001387
GAITER REPLACEMENT KIT
Gearbox side 		$141.19 (42.3% off) 1
38 70001388
GAITER REPLACEMENT KIT
Wheel/gearbox side 		$176.49 (41.6% off) 1
