RACING SEAT

Find Your Part

Ferrari 488 Spider - RACING SEAT

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
87401600 RH RACING SEAT COMPLETE WITH GUIDE RAILS $33,144.57 To Order
87641500 LH RACING SEAT COMPLETE WITH GUIDE RAILS $13,167.32 To Order
87641600 LH RACING SEAT COMPLETE WITH GUIDE RAILS $13,842.85 To Order
...and 35 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
85635700 SCREW $1.77 To Order
Photo Part No Description Price (each) Stock
65806500 SPRING PLATE $0.81 To Order
Photo Part No Description Price (each) Stock
88836000 LH DRIVER SIDE RAIL ASSEMBLY $473.02 To Order
83455000 RH RAIL ASSEMBLY WITH SPACER $1,203.43 To Order
83455100 LH RAIL ASSEMBLY WITH SPACER $1,203.43 To Order
...and 1 more part variants. See table on right for more details.
Photo Part No Description Price (each) Stock
86771100 SCUFF GUARD $109.10 To Order
Photo Part No Description Price (each) Stock
82664200 BUCKLE SECTION $417.18 To Order
Photo Part No Description Price (each) Stock
88838300 RH SEAT CUSHION COVER PANEL $176.49 To Order
86772700 RH CUSHION SIDE PANEL $272.77 To Order
Photo Part No Description Price (each) Stock
88838200 LH SEAT CUSHION COVER PANEL $176.49 To Order
86769900 LH CUSHION SIDE PANEL $286.67 To Order
Photo Part No Description Price (each) Stock
86768800 SEAT ARCH $272.34 To Order
Photo Part No Description Price (each) Stock
88838600 RH COVER PANEL FOR LH SEAT BACKREST $157.66 To Order
86769300 RH COVER PANEL FOR LH SEAT BACKREST $126.75 To Order
Photo Part No Description Price (each) Stock
88838800 LH COVER PANEL FOR LH SEAT BACKREST $186.33 To Order
88838400 LH COVER PANEL FOR LH SEAT BACKREST $157.66 To Order
Photo Part No Description Price (each) Stock
86771700 LH COVER PANEL FOR RH SEAT BACKREST $172.00 To Order
88838700 LH COVER PANEL FOR RH SEAT BACKREST $172.00 To Order
Photo Part No Description Price (each) Stock
88838900 RH COVER PANEL FOR RH SEAT BACKREST $172.00 To Order
88838500 RH COVER PANEL FOR RH SEAT BACKREST $157.66 To Order
Photo Part No Description Price (each) Stock
83454900 WIRING HARNESS $433.23 To Order
Photo Part No Description Price (each) Stock
88835300 CONNECTOR $136.16 To Order
Photo Part No Description Price (each) Stock
88835900 RH SEAT TILE MECHANISM $3,990.73 To Order
88835800 LH SEAT TILT MECHANISM $4,125.41 To Order
Photo Part No Description Price (each) Stock
893996 LEVA DX. ALZASEDILE - GRIGIO BRUNITO $286.67 To Order
Photo Part No Description Price (each) Stock
88837900 BACKREST RELEASE HANDLE $143.33 To Order
Photo Part No Description Price (each) Stock
88838000 BACKREST RELEASE BACKING PANEL $64.49 To Order
Photo Part No Description Price (each) Stock
88838100 BACKREST ADJUSTER KNOB $143.33 To Order
Photo Part No Description Price (each) Stock
83455500 JOINT ROD WITH BRAKE $224.63 To Order
Photo Part No Description Price (each) Stock
87817912 BELT STALK COVER $146.00 To Order
View All
RACING SEAT of Ferrari Ferrari 488 Spider Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 87401600
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Large; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for GD 		$33,144.57 1
1 87641500
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,167.32 1
1 87641600
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Large; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,842.85 1
1 87641400
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 87469400
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$34,440.22 1
1 87469500
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 87469600
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 88001300
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Large; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,842.85 1
1 87401500
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for GD 		$12,410.06 1
1 87999400
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,842.85 1
1 87401900
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for GD 		$33,684.80 1
1 87401400
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for GD 		- 1 Enquire
1 87401800
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; With seat tilt mechanism; INTP; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for GD 		$33,684.80 1
1 87639412
LH RACING SEAT COMPLETE WITH GUIDE RAILS -Goldrake- -Large- -Without seat tilt mechanism- -INTP- -DUAL- -1CAV- -EMPH- -STC1- -STC2- -Not for USA
Goldrake; Large; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$26,201.47 1
1 87401700
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; With seat tilt mechanism; INTP; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for GD 		- 1 Enquire
1 87639200
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		- 1 Enquire
1 87639300
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$12,410.06 1
1 87400900
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		$13,842.85 1
1 88086800
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,167.32 1
1 88086600
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 87400800
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		- 1 Enquire
1 88086700
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 88087400
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Large; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$14,218.44 1
1 87400700
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; With seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		- 1 Enquire
1 87400500
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		$13,842.85 1
1 88087300
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		$13,167.32 1
1 87400612
LH RACING SEAT COMPLETE WITH GUIDE RAILS -Goldrake- -Large- -With seat tilt mechanism- -INTP- -DUAL- -1CAV- -EMPH- -STC1- -STC2- -Not for USA
Goldrake; Large; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		$13,842.85 1
1 87400400
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, GD, USA LIGHT 		$13,842.85 1
1 88087200
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; With seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Applicable for USA, CDN, USA LIGHT 		- 1 Enquire
1 87397500
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$28,617.53 1
1 87397300
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		- 1 Enquire
1 87397400
LH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$13,842.85 1
1 87638812
RH RACING SEAT COMPLETE WITH GUIDE RAILS -Goldrake- -Large- -Without seat tilt mechanism- -INTP- -DUAL- -1CAV- -EMPH- -STC1- -STC2- -Not for USA
Goldrake; Large; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$26,410.07 1
1 87396900
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Large; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$13,842.85 1
1 87638600
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Small; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$12,410.06 1
1 87638700
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Goldrake; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$25,052.51 1
1 87396800
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Medium; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$13,842.85 1
1 87396700
RH RACING SEAT COMPLETE WITH GUIDE RAILS
Daytona; Small; Without seat tilt mechanism; INTP; INTA; DUAL; STP1; STP2; 1CAV; EMPH; STC1; STC2; Not for USA, CDN, USA LIGHT 		$13,842.85 1
2 85635700
SCREW
M8 X 40 		$1.77 8
3 65806500
SPRING PLATE 		$0.81 (30.8% off) 8
4 88836000
LH DRIVER SIDE RAIL ASSEMBLY
Applicable for USA 		$473.02 1
4 83455000
RH RAIL ASSEMBLY WITH SPACER
Not for USA 		$1,203.43 1
4 83455100
LH RAIL ASSEMBLY WITH SPACER
Not for USA 		$1,203.43 1
4 88836100
RH DRIVER SIDE RAIL ASSEMBLY
Applicable for USA 		$473.02 1
5 86771100
SCUFF GUARD 		$109.10 2
6 82664200
BUCKLE SECTION 		$417.18 1
7 88838300
RH SEAT CUSHION COVER PANEL
Burnished grey; Without seat tilt mechanism 		$176.49 1
7 86772700
RH CUSHION SIDE PANEL
Burnished grey; With seat tilt mechanism 		$272.77 1
8 88838200
LH SEAT CUSHION COVER PANEL
Burnished grey; Without seat tilt mechanism 		$176.49 1
8 86769900
LH CUSHION SIDE PANEL
Burnished grey; With seat tilt mechanism 		$286.67 1
9 86768800
SEAT ARCH 		$272.34 1
10 88838600
RH COVER PANEL FOR LH SEAT BACKREST
Burnished grey; Without seat tilt mechanism; Applicable for GD 		$157.66 1
10 86769300
RH COVER PANEL FOR LH SEAT BACKREST
Burnished grey; With seat tilt mechanism; Not for GD 		$126.75 1
11 88838800
LH COVER PANEL FOR LH SEAT BACKREST
Burnished grey; With seat tilt mechanism; Not for GD 		$186.33 1
11 88838400
LH COVER PANEL FOR LH SEAT BACKREST
Burnished grey; Without seat tilt mechanism; Applicable for GD 		$157.66 1
12 86771700
LH COVER PANEL FOR RH SEAT BACKREST
Burnished grey; With seat tilt mechanism; Applicable for GD 		$172.00 1
12 88838700
LH COVER PANEL FOR RH SEAT BACKREST
Burnished grey; Without seat tilt mechanism; Not for GD 		$172.00 1
13 88838900
RH COVER PANEL FOR RH SEAT BACKREST
Burnished grey; With seat tilt mechanism; Applicable for GD 		$172.00 1
13 88838500
RH COVER PANEL FOR RH SEAT BACKREST
Burnished grey; Without seat tilt mechanism; Not for GD 		$157.66 1
14 83454900
WIRING HARNESS 		$433.23 1
15 88835300
CONNECTOR 		$136.16 1
16 88835900
RH SEAT TILE MECHANISM
With seat tilt mechanism 		$3,990.73 1
16 88835800
LH SEAT TILT MECHANISM
With seat tilt mechanism 		$4,125.41 1
17 893996
LEVA DX. ALZASEDILE - GRIGIO BRUNITO
Burnished grey; With seat tilt mechanism 		$286.67 1
18 88837900
BACKREST RELEASE HANDLE
Burnished grey 		$143.33 1
19 88838000
BACKREST RELEASE BACKING PANEL
Burnished grey 		$64.49 1
20 88838100
BACKREST ADJUSTER KNOB
Burnished grey 		$143.33 1
21 83455500
JOINT ROD WITH BRAKE 		$224.63 1
22 87817912
BELT STALK COVER
INTP; STC1; STC2 		$146.00 2
