Air Conditioning Compressor

Ferrari 348 TS (1993)

Find Your Part

Ferrari 348 TS (1993) - Air Conditioning Compressor

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
157355 COMPRESSOR (SANDEN SD7) Enquire To Order
Photo Part No Description Price (each) Stock
137768 ESTENDBLOCK Enquire To Order
Photo Part No Description Price (each) Stock
135108 ESTENDBLOCK Enquire To Order
Photo Part No Description Price (each) Stock
101632 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
12626224 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
14308121 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
13578324 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
102742 Nyloc Nut M10 x 1.25 x 10mm Enquire ARRIVING SOON
Photo Part No Description Price (each) Stock
62642800 RETURN TUBE Enquire To Order
Photo Part No Description Price (each) Stock
125668 SCREW Enquire To Order
Photo Part No Description Price (each) Stock
62642300 DELIVERY TUBE Enquire To Order
Photo Part No Description Price (each) Stock
147639 BRACKET Enquire To Order
Photo Part No Description Price (each) Stock
13525470 THREADED INSERT Enquire To Order
Photo Part No Description Price (each) Stock
139352 THREADED PIN Enquire To Order
Photo Part No Description Price (each) Stock
128944 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
102742 Nyloc Nut M10 x 1.25 x 10mm Enquire ARRIVING SOON
Photo Part No Description Price (each) Stock
199819 COMPRESSOR CONTROL BELT Enquire To Order
Photo Part No Description Price (each) Stock
14496501 WASHER Enquire To Order
Photo Part No Description Price (each) Stock
138331 ELECTRO MAGNETIC JOINT Enquire To Order
View All
Air Conditioning Compressor of Ferrari Ferrari 348 TS (1993) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
1 157355
COMPRESSOR (SANDEN SD7) 		- 1 Enquire
2 137768
ESTENDBLOCK 		- 1 Enquire
3 135108
ESTENDBLOCK 		- 1 Enquire
4 101632
SCREW 		- 1 Enquire
5 12626224
WASHER 		- 1 Enquire
6 14308121
SCREW 		- 1 Enquire
7 13578324
WASHER 		- 5 Enquire
8 102742
Nyloc Nut M10 x 1.25 x 10mm
ARRIVING SOON 		- 2 Enquire
9 62642800
RETURN TUBE 		- 1 Enquire
10 125668
SCREW 		- 1 Enquire
11 62642300
DELIVERY TUBE 		- 1 Enquire
12 147639
BRACKET 		- 1 Enquire
13 13525470
THREADED INSERT 		- 1 Enquire
14 139352
THREADED PIN 		- 1 Enquire
15 128944
WASHER 		- 1 Enquire
16 102742
Nyloc Nut M10 x 1.25 x 10mm
ARRIVING SOON 		- 1 Enquire
17 199819
COMPRESSOR CONTROL BELT
On Exhaustion use 199819 (1mm Shorter) 		- 1 Enquire
18 14496501
WASHER 		- 1 Enquire
19 138331
ELECTRO MAGNETIC JOINT 		- 1 Enquire
