Clutch Release Control - Not for GD of Ferrari Ferrari 348 TS (1993)

View All

Ferrari 348 TS (1993) - Clutch Release Control - Not for GD

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	139391	CLUTCH PEDAL	Enquire	To Order
	149293	CLUTCH PEDAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	132818	Pedal protection	Enquire	To Order
	149295	PEDAL SLAB	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	103163	SELF-LUBRICATING BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	109407	BALL-JOINT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101305	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	187014	PEDAL ADJUSTER SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148260	COMPLETE PEDAL SUPPORT	Enquire	To Order
	147690	COMPLETE PEDAL SUPPORT	Enquire	To Order
	14059311	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
			Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	129615	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16043324	SCREW M8 X 18	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127496	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	66535800	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	129612	SPRING ANCHOR PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11500124	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	129613	PEDALS SUPPORT PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101314	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	112153	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	112125	SPACER WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	112131	DITTO THICKNESS mm. 1.3	Enquire	To Order
	112130	DITTO THICKNESS mm. 1.2	Enquire	To Order
	112128	DITTO THICKNESS mm. 1.0	Enquire	To Order

...and 2 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	11066676	FLEXIBLE RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13516824	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NYLOC NUT M8 X 1.25 X 9.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499421	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62097800	PEDAL SUPPORT PROTECTION	Enquire	To Order
	62877200	PEDAL SUPPORT PROTECTION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	62694400	GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12646604	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	15925601	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	104030	NYLOC NUT M8 X 1.25 X 9.5	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499421	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	175211	Clutch master cylinder	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059311	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13516824	STUD BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14040711	NUT M8 FLANGED	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12638524	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10248271	FORK FOR CLUTCH LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	130926	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	16104411	Selflocking nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151845	PIPE FROM CLUTCH PUMP TO	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157934	SCREW COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140669	HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	105369	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	232649	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	139375	2-WAY UNION	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499370	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140666	INTERMEDIATE TUBE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	141522	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	141521	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	240774	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14499370	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	143041	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13525770	THREADED INSERT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	139391	CLUTCH PEDAL	139391 CLUTCH PEDAL Valid till car Nr. 90916	-	1	Enquire
1	149293	CLUTCH PEDAL	149293 CLUTCH PEDAL Valid from car Nr. 90917	-	1	Enquire
2	132818	Pedal protection	132818 Pedal protection Valid for pedal 139391	-	1	Enquire
2	149295	PEDAL SLAB	149295 PEDAL SLAB Valid for pedal 149293	-	1	Enquire
3	103163	SELF-LUBRICATING BUSHING	103163 SELF-LUBRICATING BUSHING	-	2	Enquire
4	109407	BALL-JOINT	109407 BALL-JOINT	-	1	Enquire
5	101305	SPRING	101305 SPRING	-	1	Enquire
6	187014	PEDAL ADJUSTER SCREW	187014 PEDAL ADJUSTER SCREW	-	2	Enquire
7	148260	COMPLETE PEDAL SUPPORT	148260 COMPLETE PEDAL SUPPORT Valid till car Ass. Nr. 1869	-	1	Enquire
7	147690	COMPLETE PEDAL SUPPORT	147690 COMPLETE PEDAL SUPPORT	-	1	Enquire
7	14059311	NUT	14059311 NUT	-	2	Enquire
8	-		Not as spare part With complete pedal support	-	1	Enquire
9	129615	GASKET	129615 GASKET	-	1	Enquire
10	16043324	SCREW M8 X 18	16043324 SCREW M8 X 18 Valid till car Ass. Nr. 1869	-	2	Enquire
11	127496	WASHER	127496 WASHER Valid till car Ass. Nr. 1869	-	4	Enquire
12	66535800	SCREW	66535800 SCREW Valid till car Ass. Nr. 1869	-	2	Enquire
13	84653800	WASHER	84653800 WASHER	-	2	Enquire
14	129612	SPRING ANCHOR PIN	129612 SPRING ANCHOR PIN	-	1	Enquire
15	11500124	STUD BOLT	11500124 STUD BOLT	-	4	Enquire
16	129613	PEDALS SUPPORT PIN	129613 PEDALS SUPPORT PIN	-	1	Enquire
17	101314	BUSHING	101314 BUSHING	-	1	Enquire
18	112153	BUSHING	112153 BUSHING	-	1	Enquire
19	112125	SPACER WASHER	112125 SPACER WASHER	-	1	Enquire
20	112131	DITTO THICKNESS mm. 1.3	112131 DITTO THICKNESS mm. 1.3 mm. 1,3 Possible fitting	-	1	Enquire
20	112130	DITTO THICKNESS mm. 1.2	112130 DITTO THICKNESS mm. 1.2 mm. 1,2 Possible fitting	-	1	Enquire
20	112128	DITTO THICKNESS mm. 1.0	112128 DITTO THICKNESS mm. 1.0 mm. 1,0 Possible fitting	-	1	Enquire
20	112127	DITTO THICKNESS mm. 0.9	112127 DITTO THICKNESS mm. 0.9 mm. 0,9 Possible fitting	-	1	Enquire
20	112129	DITTO THICKNESS mm. 1.1	112129 DITTO THICKNESS mm. 1.1 mm.1,1 Possible fitting	-	1	Enquire
21	11066676	FLEXIBLE RING	11066676 FLEXIBLE RING	-	1	Enquire
22	13516824	STUD BOLT	13516824 STUD BOLT Valid from car Ass. Nr. 1870	-	4	Enquire
23	104030	NYLOC NUT M8 X 1.25 X 9.5	104030 NYLOC NUT M8 X 1.25 X 9.5 Valid from car Ass. Nr. 1870	-	4	Enquire
24	14499421	WASHER	14499421 WASHER Valid from car Ass. Nr. 1870	-	4	Enquire
25	62097800	PEDAL SUPPORT PROTECTION	62097800 PEDAL SUPPORT PROTECTION Valid till car Ass. Nr. 1869	-	1	Enquire
25	62877200	PEDAL SUPPORT PROTECTION	62877200 PEDAL SUPPORT PROTECTION Valid from car Ass. Nr. 1870	-	1	Enquire
26	62694400	GASKET	62694400 GASKET	-	1	Enquire
27	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	2	Enquire
28	12646604	WASHER	12646604 WASHER	-	3	Enquire
29	15925601	SCREW	15925601 SCREW	-	1	Enquire
30	104030	NYLOC NUT M8 X 1.25 X 9.5	104030 NYLOC NUT M8 X 1.25 X 9.5	-	1	Enquire
31	14499421	WASHER	14499421 WASHER	-	1	Enquire
32	175211	Clutch master cylinder	175211 Clutch master cylinder	-	1	Enquire
33	14059311	NUT	14059311 NUT	-	1	Enquire
34	13516824	STUD BOLT	13516824 STUD BOLT	-	2	Enquire
35	14040711	NUT M8 FLANGED	14040711 NUT M8 FLANGED	-	2	Enquire
36	12638524	WASHER	12638524 WASHER	-	2	Enquire
37	10248271	FORK FOR CLUTCH LEVER	10248271 FORK FOR CLUTCH LEVER	-	1	Enquire
38	130926	SCREW	130926 SCREW	-	1	Enquire
39	16104411	Selflocking nut	16104411 Selflocking nut	-	1	Enquire
40	151845	PIPE FROM CLUTCH PUMP TO	151845 PIPE FROM CLUTCH PUMP TO	-	1	Enquire
41	157934	SCREW COLLAR	157934 SCREW COLLAR	-	2	Enquire
42	140669	HOSE	140669 HOSE	-	1	Enquire
43	105369	CABLE GROMMET	105369 CABLE GROMMET	-	1	Enquire
44	232649	CLIP	232649 CLIP	-	1	Enquire
45	139375	2-WAY UNION	139375 2-WAY UNION	-	1	Enquire
46	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
47	14499370	Washer	14499370 Washer	-	1	Enquire
48	140666	INTERMEDIATE TUBE	140666 INTERMEDIATE TUBE	-	1	Enquire
49	141522	CLIP	141522 CLIP	-	9	Enquire
50	141521	CLIP	141521 CLIP	-	2	Enquire
51	240774	CONNECTOR	240774 CONNECTOR	-	1	Enquire
52	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
53	14499370	Washer	14499370 Washer	-	1	Enquire
54	143041	SPACER	143041 SPACER	-	1	Enquire
55	13525770	THREADED INSERT	13525770 THREADED INSERT	-	2	Enquire
