Name: BODYWORK AND FRONT OUTER TRIM PANELS (Available with: "Spyder 90th Anniversary" Version)
Rating: 4.3 (1 reviews)

BODYWORK AND FRONT OUTER TRIM PANELS (Available with: "Spyder 90th Anniversary" Version) of Maserati Maserati 4200 Spyder (2005-2007) CC

View All

Maserati 4200 Spyder (2005-2007) CC - BODYWORK AND FRONT OUTER TRIM PANELS (Available with: "Spyder 90th Anniversary" Version)

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	980001042	WINDSCREEN FRAME LINING	$1,609.04	To Order

Photo	Part No	Description	Price (each)	Stock
	66736500	COMPLETE UNDERWINDSCREEN FRAME	$379.20	To Order

Photo	Part No	Description	Price (each)	Stock
	67956400	FRONT RH MUDGUARD ASSEMBLY	$1,072.80	To Order

Photo	Part No	Description	Price (each)	Stock
	67956500	FRONT LH MUDGUARD ASSEMBLY	$1,072.80	To Order

Photo	Part No	Description	Price (each)	Stock
	67236200	R.H. COMPLETE FRONT STRUT	$1,517.33	To Order

Photo	Part No	Description	Price (each)	Stock
	67236300	L.H. COMPLETE FRONT STRUT	$1,517.33	To Order

Photo	Part No	Description	Price (each)	Stock
	980001047	COMPLETE FRONT CROSS MEMBER	$803.80	To Order

Photo	Part No	Description	Price (each)	Stock
	67515900	R.H. OUTER LONGITUDINAL MEMBER REINCFORCEMENT	$649.05	To Order

Photo	Part No	Description	Price (each)	Stock
	67516000	L.H. OUTER LONGITUDINAL MEMBER REINFORCEMENT	$5,893.13	To Order

Photo	Part No	Description	Price (each)	Stock
	66055900	R.H. FRONT OUTER LONGITUDINAL MEMBER	$590.85	To Order

Photo	Part No	Description	Price (each)	Stock
	66056000	L.H. FRONT OUTER LONGITUDINAL MEMBER	$552.03	To Order

Photo	Part No	Description	Price (each)	Stock
	66055700	R.H. OUTER LONGITUDINAL MEMBER REAR PART	$124.60	To Order

Photo	Part No	Description	Price (each)	Stock
	66055800	L.H. OUTER LONGITUDINAL MEMBER REAR PART	$124.60	To Order

Photo	Part No	Description	Price (each)	Stock
	67236400	R.H. FRONT ROD	$236.64	To Order

Photo	Part No	Description	Price (each)	Stock
	67236500	L.H. FRONT ROD	$236.64	To Order

Photo	Part No	Description	Price (each)	Stock
	65825300	R.H. FRONT INNER ROD REINFORCEMENT	$279.53	To Order

Photo	Part No	Description	Price (each)	Stock
	65825400	L.H. FRONT INNER ROD REINFORCEMENT	$279.53	To Order

Photo	Part No	Description	Price (each)	Stock
	382500308	FRONT RH MUDGUARD CONNECTION	$251.89	To Order

Photo	Part No	Description	Price (each)	Stock
	382500307	FRONT LH MUDGUARD CONNECTION	$218.79	To Order

Photo	Part No	Description	Price (each)	Stock
	980001174	COMPLETE R.H. FRONT ROD REINFORCEMENT	$462.18	To Order

Photo	Part No	Description	Price (each)	Stock
	980001173	COMPLETE L.H. FRONT ROD REINFORCEMENT	$492.62	To Order

Photo	Part No	Description	Price (each)	Stock
	66247000	BRACKET FOR LONGITUDINAL MEMBER	$239.75	To Order

Photo	Part No	Description	Price (each)	Stock
	66414000	SHIELD FOR WATER FIXING PLATE	$32.45	To Order
	66726500	SHIELD FOR WATER FIXING PLATE	$32.45	To Order

Photo	Part No	Description	Price (each)	Stock
	14507687	PLUG	$1.97	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
-	1002041	SOUNDPROOFING KIT	1002041 SOUNDPROOFING KIT Not for RHD	$901.30	1
-	1002042	SOUNDPROOFING KIT	1002042 SOUNDPROOFING KIT Valid for RHD	$825.81	1
1	980001042	WINDSCREEN FRAME LINING	980001042 WINDSCREEN FRAME LINING	$1,609.04	1
2	66736500	COMPLETE UNDERWINDSCREEN FRAME	66736500 COMPLETE UNDERWINDSCREEN FRAME	$379.20	1
3	67956400	FRONT RH MUDGUARD ASSEMBLY	67956400 FRONT RH MUDGUARD ASSEMBLY	$1,072.80	1
4	67956500	FRONT LH MUDGUARD ASSEMBLY	67956500 FRONT LH MUDGUARD ASSEMBLY	$1,072.80	1
5	67236200	R.H. COMPLETE FRONT STRUT	67236200 R.H. COMPLETE FRONT STRUT	$1,517.33	1
6	67236300	L.H. COMPLETE FRONT STRUT	67236300 L.H. COMPLETE FRONT STRUT	$1,517.33	1
7	980001047	COMPLETE FRONT CROSS MEMBER	980001047 COMPLETE FRONT CROSS MEMBER	$803.80	1
8	67515900	R.H. OUTER LONGITUDINAL MEMBER REINCFORCEMENT	67515900 R.H. OUTER LONGITUDINAL MEMBER REINCFORCEMENT	$649.05	1
9	67516000	L.H. OUTER LONGITUDINAL MEMBER REINFORCEMENT	67516000 L.H. OUTER LONGITUDINAL MEMBER REINFORCEMENT	$5,893.13	1
10	66055900	R.H. FRONT OUTER LONGITUDINAL MEMBER	66055900 R.H. FRONT OUTER LONGITUDINAL MEMBER	$590.85	1
11	66056000	L.H. FRONT OUTER LONGITUDINAL MEMBER	66056000 L.H. FRONT OUTER LONGITUDINAL MEMBER	$552.03	1
12	66055700	R.H. OUTER LONGITUDINAL MEMBER REAR PART	66055700 R.H. OUTER LONGITUDINAL MEMBER REAR PART	$124.60	1
13	66055800	L.H. OUTER LONGITUDINAL MEMBER REAR PART	66055800 L.H. OUTER LONGITUDINAL MEMBER REAR PART	$124.60	1
14	67236400	R.H. FRONT ROD	67236400 R.H. FRONT ROD	$236.64	1
15	67236500	L.H. FRONT ROD	67236500 L.H. FRONT ROD	$236.64	1
16	65825300	R.H. FRONT INNER ROD REINFORCEMENT	65825300 R.H. FRONT INNER ROD REINFORCEMENT	$279.53	1
17	65825400	L.H. FRONT INNER ROD REINFORCEMENT	65825400 L.H. FRONT INNER ROD REINFORCEMENT	$279.53	1
18	382500308	FRONT RH MUDGUARD CONNECTION	382500308 FRONT RH MUDGUARD CONNECTION	$251.89	1
19	382500307	FRONT LH MUDGUARD CONNECTION	382500307 FRONT LH MUDGUARD CONNECTION	$218.79	1
20	980001174	COMPLETE R.H. FRONT ROD REINFORCEMENT	980001174 COMPLETE R.H. FRONT ROD REINFORCEMENT	$462.18	1
21	980001173	COMPLETE L.H. FRONT ROD REINFORCEMENT	980001173 COMPLETE L.H. FRONT ROD REINFORCEMENT	$492.62	1
22	66247000	BRACKET FOR LONGITUDINAL MEMBER	66247000 BRACKET FOR LONGITUDINAL MEMBER	$239.75	2
23	66414000	SHIELD FOR WATER FIXING PLATE	66414000 SHIELD FOR WATER FIXING PLATE Not for RHD	$32.45	1
23	66726500	SHIELD FOR WATER FIXING PLATE	66726500 SHIELD FOR WATER FIXING PLATE Valid for RHD	$32.45	1
24	14507687	PLUG	14507687 PLUG	$1.97	2
