UNDERBODY TRIM of Lamborghini Lamborghini Urus (2018-2019)

View All

Lamborghini Urus (2018-2019) - UNDERBODY TRIM

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	4M0825206J	UNDERBODY TRIM	Enquire	To Order
	4M0825205L	UNDERBODY TRIM	Enquire	To Order
	4M0825205S	UNDERBODY TRIM	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	4M8825211	UNDERBODY TRIM	Enquire	To Order
	4M8825212	UNDERBODY TRIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		SPEED NUT	Enquire	To Order
	N90708803	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		CLIP	Enquire	To Order
	8K0863203	CLIP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4H0804535	SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order
	4M0825641E	HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT003207	HEXAGON PLASTIC COLLAR NUT	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	4M0825725D	HEAT SHELF FOR CENTRE SILENCER	Enquire	To Order
	N90775001	HEXAGON SOCKET HEAD PANEL BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90335004	CLAMPING WASHER	Enquire	To Order
	1K0825951	HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
		HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order
	4M0825642F	HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order
	4M8825211	UNDERBODY TRIM	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	N10433701	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N0385494	SPREADER RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10015101	HEXAGON NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT005453	EXPANDING NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825213J	UNDERBODY TRIM	Enquire	To Order
	4M0825214J	UNDERBODY TRIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825343B	BRACKET	Enquire	To Order
	4M0825343C	BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N01508210	HEXAGON COLLAR NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0804033F	COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90714303	HEX. NUT WITH WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825912	GUARD PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10609201	HEXAGON COLLAR NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	WHT004907	RIVETTED CAP NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N10642101	HEX COLLARED BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825219E	UNDERBODY TRIM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	8K0501329	SPREADER RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825725D	HEAT SHELF FOR CENTRE SILENCER	Enquire	To Order
	N90775001	HEXAGON SOCKET HEAD PANEL BOLT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	N90335004	CLAMPING WASHER	Enquire	To Order
	1K0825951	HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1825643F	HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order
	4M0825642F	HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M1825644E	HEAT SHIELD FOR SIDE MEMBER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825691F	HEAT SHIELD FOR TUNNEL	Enquire	To Order
	4M0825692D	HEAT SHIELD FOR TUNNEL	Enquire	To Order
	N90708803	SPEED NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	4M0825661N	HEAT SHIELD FOR TUNNEL	Enquire	To Order
	4M0825662J	HEAT SHIELD FOR TUNNEL	Enquire	To Order
		CLIP	Enquire	To Order

...and 1 more part variants. See table on right for more details.

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	4M0825206J	UNDERBODY TRIM	4M0825206J UNDERBODY TRIM RIGHT	-	1	Enquire
1	4M0825205L	UNDERBODY TRIM	4M0825205L UNDERBODY TRIM LEFT	-	1	Enquire
1	4M0825205S	UNDERBODY TRIM	4M0825205S UNDERBODY TRIM DUNE PACK-LEFT	-	1	Enquire
1	4M0825206M	UNDERBODY TRIM	4M0825206M UNDERBODY TRIM DUNE PACK-RIGHT	-	1	Enquire
2	4M8825211	UNDERBODY TRIM	4M8825211 UNDERBODY TRIM LEFT	-	1	Enquire
2	4M8825212	UNDERBODY TRIM	4M8825212 UNDERBODY TRIM RIGHT	-	1	Enquire
3	-	SPEED NUT	SPEED NUT NOT USED FROM VIN 03664	-	-	Enquire
3	N90708803	SPEED NUT	N90708803 SPEED NUT UNTIL VIN ZPBUA1ZL1KLA 03663-5	-	1	Enquire
4	-	CLIP	CLIP NOT USED FROM VIN 03664	-	-	Enquire
4	8K0863203	CLIP	8K0863203 CLIP UNTIL VIN ZPBUA1ZL1KLA 03663	-	1	Enquire
5	4H0804535	SEAL	4H0804535 SEAL	-	2	Enquire
6	-	HEAT SHIELD FOR SIDE MEMBER	HEAT SHIELD FOR SIDE MEMBER NOT USED FROM VIN 03664	-	-	Enquire
6	4M0825641E	HEAT SHIELD FOR SIDE MEMBER	4M0825641E HEAT SHIELD FOR SIDE MEMBER UNTIL VIN ZPBUA1ZL1KLA 03663-LEFT	-	1	Enquire
7	WHT003207	HEXAGON PLASTIC COLLAR NUT ARRIVING SOON	WHT003207 HEXAGON PLASTIC COLLAR NUT T5 ARRIVING SOON	-	23	Enquire
8	4M0825725D	HEAT SHELF FOR CENTRE SILENCER	4M0825725D HEAT SHELF FOR CENTRE SILENCER 0E20K01A2	-	1	Enquire
8	N90775001	HEXAGON SOCKET HEAD PANEL BOLT	N90775001 HEXAGON SOCKET HEAD PANEL BOLT 4,8X16	-	36	Enquire
9	N90335004	CLAMPING WASHER	N90335004 CLAMPING WASHER 5X30	-	1	Enquire
9	1K0825951	HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING	1K0825951 HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING M6X20	-	4	Enquire
10	-	HEAT SHIELD FOR SIDE MEMBER	HEAT SHIELD FOR SIDE MEMBER NOT USED FROM VIN 03664	-	-	Enquire
10	4M0825642F	HEAT SHIELD FOR SIDE MEMBER	4M0825642F HEAT SHIELD FOR SIDE MEMBER UNTIL VIN ZPBUA1ZL1KLA 03663-RIGHT	-	1	Enquire
10	4M8825211	UNDERBODY TRIM	4M8825211 UNDERBODY TRIM LEFT	-	1	Enquire
10	4M8825212	UNDERBODY TRIM	4M8825212 UNDERBODY TRIM RIGHT	-	1	Enquire
11	N10433701	SPEED NUT	N10433701 SPEED NUT 4,8X18,6X16	-	17	Enquire
12	N0385494	SPREADER RIVET	N0385494 SPREADER RIVET 8X12-8X12	-	4	Enquire
13	N10015101	HEXAGON NUT	N10015101 HEXAGON NUT	-	6	Enquire
14	WHT005453	EXPANDING NUT	WHT005453 EXPANDING NUT 5X15,3	-	10	Enquire
15	4M0825213J	UNDERBODY TRIM	4M0825213J UNDERBODY TRIM LEFT-LEFT	-	1	Enquire
15	4M0825214J	UNDERBODY TRIM	4M0825214J UNDERBODY TRIM RIGHT-RIGHT	-	1	Enquire
16	4M0825343B	BRACKET	4M0825343B BRACKET FROM VIN ZPBUA1ZL5KLA 02579-LEFT	-	1	Enquire
16	4M0825343C	BRACKET	4M0825343C BRACKET UNTIL VIN ZPBUA1ZL5KLA 02578-LEFT	-	1	Enquire
17	N01508210	HEXAGON COLLAR NUT	N01508210 HEXAGON COLLAR NUT M6	-	1	Enquire
18	4M0804033F	COVER	4M0804033F COVER	-	1	Enquire
19	N90714303	HEX. NUT WITH WASHER	N90714303 HEX. NUT WITH WASHER M6	-	1	Enquire
20	4M0825912	GUARD PLATE	4M0825912 GUARD PLATE	-	-	Enquire
21	N10609201	HEXAGON COLLAR NUT	N10609201 HEXAGON COLLAR NUT M8	-	4	Enquire
22	WHT004907	RIVETTED CAP NUT	WHT004907 RIVETTED CAP NUT M8	-	2	Enquire
23	N10642101	HEX COLLARED BOLT	N10642101 HEX COLLARED BOLT M8X25	-	4	Enquire
24	4M0825219E	UNDERBODY TRIM	4M0825219E UNDERBODY TRIM RIGHT REAR	-	1	Enquire
25	8K0501329	SPREADER RIVET	8K0501329 SPREADER RIVET	-	1	Enquire
26	4M0825725D	HEAT SHELF FOR CENTRE SILENCER	4M0825725D HEAT SHELF FOR CENTRE SILENCER	-	1	Enquire
26	N90775001	HEXAGON SOCKET HEAD PANEL BOLT	N90775001 HEXAGON SOCKET HEAD PANEL BOLT 4,8X16	-	36	Enquire
27	N90335004	CLAMPING WASHER	N90335004 CLAMPING WASHER 5X30	-	1	Enquire
27	1K0825951	HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING	1K0825951 HEXAGON SOCKET FLAT HEAD BOLT, SELF-LOCKING M6X20	-	4	Enquire
28	4M1825643F	HEAT SHIELD FOR SIDE MEMBER	4M1825643F HEAT SHIELD FOR SIDE MEMBER LHD	-	1	Enquire
28	4M0825642F	HEAT SHIELD FOR SIDE MEMBER	4M0825642F HEAT SHIELD FOR SIDE MEMBER UNTIL VIN ZPBUA1ZL1KLA 03663-RIGHT	-	1	Enquire
29	4M1825644E	HEAT SHIELD FOR SIDE MEMBER	4M1825644E HEAT SHIELD FOR SIDE MEMBER LHD	-	1	Enquire
30	4M0825691F	HEAT SHIELD FOR TUNNEL	4M0825691F HEAT SHIELD FOR TUNNEL LEFT REAR	-	1	Enquire
30	4M0825692D	HEAT SHIELD FOR TUNNEL	4M0825692D HEAT SHIELD FOR TUNNEL RIGHT REAR	-	1	Enquire
30	N90708803	SPEED NUT	N90708803 SPEED NUT UNTIL VIN ZPBUA1ZL1KLA 03663-5	-	3	Enquire
31	4M0825661N	HEAT SHIELD FOR TUNNEL	4M0825661N HEAT SHIELD FOR TUNNEL LEFT	-	1	Enquire
31	4M0825662J	HEAT SHIELD FOR TUNNEL	4M0825662J HEAT SHIELD FOR TUNNEL RIGHT	-	1	Enquire
31	-	CLIP	CLIP NOT USED FROM VIN 03664	-	-	Enquire
31	8K0863203	CLIP	8K0863203 CLIP UNTIL VIN ZPBUA1ZL1KLA 03663	-	1	Enquire
