View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	68001342	PANEL	68001342 PANEL PANNELLO	$363.55	1
002	68007749	FRAME	68007749 FRAME CORNICE	$220.23	1
003	65001332	COVERING	65001332 COVERING RIVESTIMENTO	$223.96	1
004	65001325	GASKET	65001325 GASKET GUARNIZIONE	$24.20 MSRP: ~~24.50~~ (1.2% off)	1
005	9404215	GASKET	9404215 GASKET GUARNIZIONE	-	1	Enquire
006	65001624	PANEL	65001624 PANEL PANNELLO CENTINA	-	1	Enquire
007	6337066	LAMP	6337066 LAMP PLAFONIERA	$17.00 MSRP: ~~20.40~~ (16.7% off)	1
008	8700691	SCREW	8700691 SCREW VITE	$3.12	2
009	6501365	FLANGE	6501365 FLANGE FLANGIA	-	1	Enquire
010	68001158	RIGHT SHELF PANEL	68001158 RIGHT SHELF PANEL PIANALE DX	-	1	Enquire
011	68001159	LEFT SHELF PANEL	68001159 LEFT SHELF PANEL PIANALE SX	-	1	Enquire
012	9453133	PIPE	9453133 PIPE TUBO FLESSIBILE	$244.43	2
013	8837501	STRAP	8837501 STRAP FASCETTA	$17.09	4
014	9411101	LEFT PANEL	9411101 LEFT PANEL PANNELLO SX	$289.69	1
015	9453144	CONVEYOR	9453144 CONVEYOR CONVOGLIATORE SX	$722.08 MSRP: ~~755.00~~ (4.4% off)	1
016	68001343	PANEL	68001343 PANEL PANNELLO	$493.59	1
017	9411106	PANEL	9411106 PANEL PANNELLO	$204.82	1
018	9411115	RIGHT PANEL	9411115 RIGHT PANEL PANNELLO DX	$332.51	1
019	9453143	CONVEYOR	9453143 CONVEYOR CONVOGLIATORE DX	$842.44	1
