Pedals (Valid For June 1992 Version)

Lamborghini Diablo (1990-1998)

Find Your Part

Lamborghini Diablo (1990-1998) - Pedals (Valid for June 1992 Version)

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

View All
Pedals (Valid for June 1992 Version) of Lamborghini Lamborghini Diablo (1990-1998) Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
001 1321270
SPRING
(Valid for June 1992 version) MOLLA 		- 2 Enquire
002 8802501
BUSHING
(Valid for June 1992 version) BOCCOLA 		- 2 Enquire
003 N01100637
NUT M6
(Valid for June 1992 version) DADO 		- 2 Enquire
004 4210834
ADJUSTING SLEEVE
(Valid for June 1992 version) REGISTRO 		- 2 Enquire
005 8900803
PIN
(Valid for June 1992 version) SA 		- 2 Enquire
006 4227889
SPRING
(Valid for June 1992 version) MOLLA 		- 1 Enquire
007 4225066
ROCKER
(Valid for June 1992 version) BILANCIERE 		- 1 Enquire
008 WHT002962
WASHER 14X8.4X1.5
(Valid for June 1992 version) RONDELLA 		- 3 Enquire
009 4225225
COUPLING
(Valid for June 1992 version) TESTA A SNODO 		- 2 Enquire
010 8200809
NUT
(Valid for June 1992 version) DADO 		- 1 Enquire
011 8100841
SCREW
(Valid for June 1992 version) VITE 		- 1 Enquire
012 8400819
WASHER 8X12X1
(Valid for June 1992 version) RONDELLA 		- 2 Enquire
013 4225064
SHAFT
(Valid for June 1992 version) ALBERO CON LEVA 		- 1 Enquire
014 4230089
GAS CABLE
(Valid for June 1992 version) CAVO ACCELERATORE 		- 1 Enquire
015 4230143
GAS PEDAL
(Valid for June 1992 version) PEDALE ACCELERATORE 		- 1 Enquire
016 4231965
CLUTCH PEDAL
(Valid for June 1992 version) PEDALE FRIZIONE 		- 1 Enquire
017 4228349
PEDAL PAD
(Valid for June 1992 version) COPRIPEDALE GOMMA 		- 1 Enquire
018 4230144
BRAKE PEDAL
(Valid for June 1992 version) PEDALE FRENO 		- 1 Enquire
019 4228351
PEDAL PAD
(Valid for June 1992 version) COPRIPEDALE GOMMA 		- 1 Enquire
020 N01100845
HEXAGON NUT
(Valid for June 1992 version) DADO 		- 2 Enquire
021 8100828
SCREW
(Valid for June 1992 version) VITE 		- 1 Enquire
022 8200809
NUT
(Valid for June 1992 version) DADO 		- 2 Enquire
023 8581101
RETAINER RING
(Valid for June 1992 version) ANELLO RITEGNO 		- 1 Enquire
024 8401220
WASHER
(Valid for June 1992 version) RONDELLA 		- 2 Enquire
025 8521205
BEARING
(Valid for June 1992 version) GABBIAARULLI 		- 2 Enquire
026 4231811
SUPPORT - SUPPORTO
(Valid for June 1992 version) O 		- 1 Enquire
027 4230149
LEVER
(Valid for June 1992 version) LEVA 		- 1 Enquire
028 N90179103
WASHER 18X8,4X2,5
(Valid for June 1992 version) RONDELLA 		- 1 Enquire
029 8410819
WASHER
(Valid for June 1992 version) RONDELLA 		- 1 Enquire
030 8900305
PIN - SPINA
(Valid for June 1992 version) SA 		- 2 Enquire
031 4225062
TIE ROD
(Valid for June 1992 version) TIRANTE 		- 1 Enquire
032 4225074
PIN
(Valid for June 1992 version) PERNO 		- 1 Enquire
033 8401007
WASHER
(Valid for June 1992 version) RONDELLA 		- 6 Enquire
034 4232621
PIN
(Valid for June 1992 version) PERNO (sostituisce 004225072) 		- 2 Enquire
035 8581004
CLIP
(Valid for June 1992 version) MOLLETTA (sostituisce 008820304) 		- 3 Enquire
036 4225060
ROCKER
(Valid for June 1992 version) BILANCIERE 		- 1 Enquire
037 8801209
BUSHING
(Valid for June 1992 version) BOCCOLA 		- 1 Enquire
038 4225061
COUPLING
(Valid for June 1992 version) TESTA A SNODO 		- 1 Enquire
039 4232622
PIN
(Valid for June 1992 version) PERNO (sostituisce 004225071) 		- 1 Enquire
040 N10155210
NUT
(Valid for June 1992 version) DADO 		- 1 Enquire
041 4233379
SHIELD
(Valid for June 1992 version) RIPARO IN GOMMA (Particolare utilizzabile su tutte le vetture) 		- 1 Enquire
