Find Your Part

Climate Control (Valid for June 1992 Version) 3 of Lamborghini Lamborghini Diablo (1990-1998)

View All

Lamborghini Diablo (1990-1998) - Climate Control (Valid for June 1992 Version) 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	4526662	TEMPERATURE SENS.	4526662 TEMPERATURE SENS. (Valid for June 1992 version) SENSORE TEMPERATURA ESTERNA	-	1	Enquire
002	9453112	CONVEYOR	9453112 CONVEYOR (Valid for June 1992 version) CONVOGLIATORE	-	1	Enquire
003	4729405	ELECTROFAN	4729405 ELECTROFAN (Valid for June 1992 version) ELETTROVENTILATORE	-	1	Enquire
004	1619328	RESISTANCE	1619328 RESISTANCE (Valid for June 1992 version) RESISTENZA	-	1	Enquire
005	9014529	CONTROL	9014529 CONTROL (Valid for June 1992 version) ATTUATORE	-	1	Enquire
006	9414003	CONVEYOR	9414003 CONVEYOR (Valid for June 1992 version) CONVOGLIATORE	-	1	Enquire
007	4526663	TEMPERATURE SENS.	4526663 TEMPERATURE SENS. (Valid for June 1992 version) SENSORE TEMP. PACCO RADIANTE	-	1	Enquire
008	4530210	RADIATOR	4530210 RADIATOR (Valid for June 1992 version) PACCO RADIANTE	-	1	Enquire
009	9414505	CONVEYOR	9414505 CONVEYOR (Valid for June 1992 version) CONVOGLIATORE	-	1	Enquire
010	4526664	TEMPERATURE SENS.	4526664 TEMPERATURE SENS. (Valid for June 1992 version) SENSORE ARIA IN ENTRATA	-	1	Enquire
011	7014137	CONTROL	7014137 CONTROL (Valid for June 1992 version) ATTUATORE	-	5	Enquire
012	9414530	PIPE	9414530 PIPE (Valid for June 1992 version) TUBO	-	1	Enquire
013	6130619	ELECT CABLE	6130619 ELECT CABLE (Valid for June 1992 version) CABLAGGIO SENSORE ARIA	-	1	Enquire
014	4526665	ELECTROFAN	4526665 ELECTROFAN (Valid for June 1992 version) ELETTROVENTOLA	-	1	Enquire
015	6032223	PIPE	6032223 PIPE (Valid for June 1992 version) TUBO	-	1	Enquire
016	4526666	CONNECTION	4526666 CONNECTION (Valid for June 1992 version) CUFFIA	-	1	Enquire
017	4526661	TEMPERATURE SENS.	4526661 TEMPERATURE SENS. (Valid for June 1992 version) SENSORE TEMPERATURA ABITAGOLO	-	1	Enquire
018	9490202	GASKET	9490202 GASKET (Valid for June 1992 version) GUARNIZIONE	-	1	Enquire
019	4731661	GASKET	4731661 GASKET (Valid for June 1992 version) GUARNIZIONE	-	1	Enquire
020	9490203	GASKET	9490203 GASKET (Valid for June 1992 version) GUARNIZIONE	-	1	Enquire
021	9490201	GASKET	9490201 GASKET (Valid for June 1992 version) GUARNIZIONE	-	1	Enquire
022	9414532	PIPE	9414532 PIPE (Valid for June 1992 version) TUBO	-	1	Enquire
023	9458336	UNION	9458336 UNION (Valid for June 1992 version) BOCCHETTONE	-	1	Enquire
024	9414533	PIPE	9414533 PIPE (Valid for June 1992 version) TUBO (fino 12405)	-	1	Enquire
024	9414536	PIPE	9414536 PIPE (Valid for June 1992 version) TUBO (dalla 12406)	-	1	Enquire
025	9414531	PIPE	9414531 PIPE (Valid for June 1992 version) TUBO	-	1	Enquire
026	4532839	PIPE	4532839 PIPE (Valid for June 1992 version) BOCCOLA Dl GUIDA PER SONDA	-	1	Enquire
