Climate Control (Valid for June 1992 Version) 1 of Lamborghini Lamborghini Diablo (1990-1998)

View All

Lamborghini Diablo (1990-1998) - Climate Control (Valid for June 1992 Version) 1

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts ($0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	4529536	T. BELT (until 12042)	4529536 T. BELT (until 12042) (Valid for June 1992 version) CINGHIA	$181.14	1
001	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 (Valid for June 1992 version) DADO IN STOCK	$21.86	8
002	4530198	AIR COMPRESSOR	4530198 AIR COMPRESSOR (Valid for June 1992 version) COMPRESSORE	$1,592.24	1
002	410407127A	BOLT	410407127A BOLT (Valid for June 1992 version) ECCENTRICO	$2,318.56	8
003	410407295D	WASHER	410407295D WASHER (Valid for June 1992 version) SPESSORE Dl REGISTRO SP = 3 MM (dalla 12678)	$29.71	1
003	410407295B	2.0 MM ADJUSTMENT SHIM	410407295B 2.0 MM ADJUSTMENT SHIM (Valid for June 1992 version) SPESSORE Dl REGISTRO SP = 2 MM (dalla 12678)	$6.66	1
003	8700841	SCREW IN STOCK	8700841 SCREW (Valid for June 1992 version) VITE REGISTRO IN STOCK	$2.23 MSRP: ~~2.35~~ (5.1% off)	1
003	410407295C	2.5 MM ADJUSTMENT SHIM	410407295C 2.5 MM ADJUSTMENT SHIM (Valid for June 1992 version) SPESSORE Dl REGISTRO SP = 2,5 MM (dalla 12678)	$7.32	1
003	410407295	1.0 MM ADJUSTMENT SHIM	410407295 1.0 MM ADJUSTMENT SHIM (Valid for June 1992 version) SPESSORE Dl REGISTRO SP = 1 MM (dalla 12678)	$4.52	1
003	5133488	SHIM	5133488 SHIM (Valid for June 1992 version) SPESSORE Dl REGISTRO SP = 1,5 MM (dalla 12678)	$3.25	1
004	N01100845	HEXAGON NUT IN STOCK	N01100845 HEXAGON NUT (Valid for June 1992 version) DADO IN STOCK	$1.89	1
005	8921206	RESILIENT BUSHING	8921206 RESILIENT BUSHING (Valid for June 1992 version) BOCCOLA ELASTICA	$50.31	8
005	4529646	SPACER	4529646 SPACER (Valid for June 1992 version) DISTANZIALE	$24.78 MSRP: ~~25.05~~ (1.1% off)	4
006	8101035	SCREW	8101035 SCREW (Valid for June 1992 version) VITE	$10.37	1
006	410407127A	BOLT	410407127A BOLT (Valid for June 1992 version) PERNO CON ECCENTRICO	$2,318.56	8
007	8101022	bolt	8101022 bolt (Valid for June 1992 version) VITE	$4.23	1
007	5225908	RH UPPER SUSPENSION ARM	5225908 RH UPPER SUSPENSION ARM	$2,388.33	1
007	5225909	ARM	5225909 ARM (Valid for June 1992 version) BRACCIO SUPERIORE SINISTRO	$2,656.13	1
008	N0122115	WASHER IN STOCK	N0122115 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.80 MSRP: ~~7.27~~ (89% off)	2
008	5225204	PIN	5225204 PIN (Valid for June 1992 version) PERNO	$91.82	2
009	5225207	RESILIENT BUSHING	5225207 RESILIENT BUSHING (Valid for June 1992 version) BOCCOLA ELASTICA	$454.50	8
009	8201008	NUT IN STOCK	8201008 NUT (Valid for June 1992 version) DADO IN STOCK	$0.80 MSRP: ~~7.24~~ (89% off)	1
010	8201008	NUT IN STOCK	8201008 NUT (Valid for June 1992 version) DADO IN STOCK	$0.80 MSRP: ~~7.24~~ (89% off)	1
010	8401710	WASHER	8401710 WASHER (Valid for June 1992 version) SPESSORE Dl REGISTRO	$41.45	16
011	N0122115	WASHER IN STOCK	N0122115 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.80 MSRP: ~~7.27~~ (89% off)	1
011	8401708	WASHER	8401708 WASHER (Valid for June 1992 version) RONDELLA	$2.56	4
012	8251702	PLUG IN STOCK	8251702 PLUG (Valid for June 1992 version) GHIERA IN STOCK	$3.85 MSRP: ~~3.95~~ (2.5% off)	4
012	8101019	bolt	8101019 bolt (Valid for June 1992 version) VITE	$4.55	2
013	8201010	NUT IN STOCK	8201010 NUT (Valid for June 1992 version) DADO IN STOCK	$1.25	2
013	5225205	PIN	5225205 PIN (Valid for June 1992 version) PERNO	$91.82	2
014	N0122115	WASHER IN STOCK	N0122115 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.80 MSRP: ~~7.27~~ (89% off)	2
014	5225906	ARM	5225906 ARM (Valid for June 1992 version) BRACCIO INFERIORE DESTRO	$1,990.31	1
014	5225907	ARM	5225907 ARM (Valid for June 1992 version) BRACCIO INFERIORE SINISTRO	$1,968.56	1
015	WHT002952	SCREW M8X1,25X30 IN STOCK	WHT002952 SCREW M8X1,25X30 (Valid for June 1992 version) VITE IN STOCK	$4.98	2
015	N0111849	NUT IN STOCK	N0111849 NUT (Valid for June 1992 version) DADO (sostituisce II 008200809) IN STOCK	$2.15 MSRP: ~~7.25~~ (70.3% off)	4
016	N0152785	WASHER IN STOCK	N0152785 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.40	4
016	5227297	BUSHING	5227297 BUSHING (Valid for June 1992 version) BOCCOLA	$32.36	8
017	5227298	BUSHING	5227298 BUSHING (Valid for June 1992 version) BOCCOLA	$17.62	4
017	N01033520	SCREW M8X35 IN STOCK	N01033520 SCREW M8X35 (Valid for June 1992 version) VITE IN STOCK	$1.55 MSRP: ~~7.19~~ (78.4% off)	2
018	5109714	BOOT	5109714 BOOT (Valid for June 1992 version) CAPPUCCIO	$26.25	4
018	4529535	SUPPORT - SUPPORTO	4529535 SUPPORT - SUPPORTO (Valid for June 1992 version) O	$1,308.92	1
019	4529645	TIE ROD	4529645 TIE ROD (Valid for June 1992 version) TIRANTE	$395.79	1
019	8100810	SCREW	8100810 SCREW (Valid for June 1992 version) VITE (sostituisce il 0081 00807)	-	4	Enquire
020	N0152785	WASHER IN STOCK	N0152785 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.40	2
020	417801931A	BALL JOINT	417801931A BALL JOINT (Valid for June 1992 version) GIUNTO SFERICO	$264.79	2
021	8201014	NUT	8201014 NUT (Valid for June 1992 version) DADO	$6.15	1
021	N01100845	HEXAGON NUT IN STOCK	N01100845 HEXAGON NUT (Valid for June 1992 version) DADO IN STOCK	$1.89	2
022	5209770	TIE ROD	5209770 TIE ROD (Valid for June 1992 version) TIRANTE	$114.15	1
022	8100620	Bolt	8100620 Bolt (Valid for June 1992 version) VITE	$5.82 MSRP: ~~6.00~~ (3% off)	2
023	WHT003053	WASHER	WHT003053 WASHER (Valid for June 1992 version) RONDELLA	$3.24	2
023	8201016	NUT	8201016 NUT (Valid for June 1992 version) DADO	$22.76	2
024	N01152427	WASHER IN STOCK	N01152427 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$0.28	2
024	5227295	BALL JOINT	5227295 BALL JOINT (Valid for June 1992 version) GIUNTO SFERICO	$152.72	2
025	5230211	STABILIZER BAR	5230211 STABILIZER BAR (Valid for June 1992 version) BARRA STABILIZZATRICE	$1,419.97	1
025	4532221	SHIELD	4532221 SHIELD (Valid for June 1992 version) PARATIA ANTICALORE	$848.62	1
026	8700609	SCREW	8700609 SCREW (Valid for June 1992 version) VITE	$0.53 MSRP: ~~7.31~~ (92.7% off)	4
026	6132546	CONNECTION	6132546 CONNECTION (Valid for June 1992 version) CONNESSIONE	$18.05	1
027	6131992	KEY	6131992 KEY (Valid for June 1992 version) LINGUETTA	-	1	Enquire
027	8410602	WASHER IN STOCK	8410602 WASHER (Valid for June 1992 version) RONDELLA IN STOCK	$44.87	8
028	5230256	RETAINER	5230256 RETAINER (Valid for June 1992 version) CAVALLOTTO	-	2	Enquire
028	6132584	KEY	6132584 KEY (Valid for June 1992 version) E	$7.93	1
029	5238302	BUSHING IN STOCK	5238302 BUSHING (Valid for June 1992 version) BOCCOLA IN STOCK	$144.81	2
030	5230257	RETAINER	5230257 RETAINER (Valid for June 1992 version) CAVALLOTTO	-	2	Enquire
031	5233269	SHOCK ABSORBER	5233269 SHOCK ABSORBER (Valid for June 1992 version) AMMORTIZZATORE POSTERIORE (dalla 12679) (compatibili sulle vetture precedenti solo se abbinati alle molle 0052261 57 q.ta 4)	$758.07	4
031	5229803	SHOCK ABSORBER	5229803 SHOCK ABSORBER (Valid for June 1992 version) AMMORTIZZATORE POSTERIORE (fino 12678)	$1,327.34	4
032	5226157	SPRING	5226157 SPRING (Valid for June 1992 version) MOLLA (dalla 12679 compatibile solo con gli ammortizzatori 005233269)	$380.90 MSRP: ~~398.00~~ (4.3% off)	4
032	5226158	SPRING	5226158 SPRING (Valid for June 1992 version) MOLLA (fino 12678)	$681.14	4
033	WHT003355	NUT M12X1,25 IN STOCK	WHT003355 NUT M12X1,25 (Valid for June 1992 version) DADO (sostituisce il 008201206) IN STOCK	$21.86	8
034	410512383	FLEXIBLE BUSHING	410512383 FLEXIBLE BUSHING	$587.37	4
035	8101259	SCREW	8101259 SCREW (Valid for June 1992 version) VITE (sostituisce il 008101274)	$15.53	8
036	410512385	RUBBER RING IN STOCK	410512385 RUBBER RING IN STOCK	$53.43	8
