TIMING - TAPPETS AND SHAFTS of Ferrari Ferrari F50

View All

Ferrari F50 - TIMING - TAPPETS AND SHAFTS

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	159349	PAD BOWL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	165207	VALVES ADJUSTMENT PAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157986	COTTER FOR VALVE SPRING CUP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157989	UPPER CUP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180192	OUTER SPRING FOR VALVE RETURN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	180208	INNER SPRING FOR VALVE RETURN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	221473	OIL SEAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	172466	LOWER CUP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159284	INTAKE VALVE GUIDE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159282	EXHAUST VALVE GUIDE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	162669	INTAKE VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	159347	EXHAUST VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6148234	INTAKE VALVE SEAT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	6140702	EXHAUST VALVE SEAT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	171400	COMPLETE R.H. INDUCTION DISTRIBUTION CAM SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	171399	COMPLETE L.H. INDUCTION DISTRIBUTION CAM SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149912	COMPLETE R.H. AND L.H. EXHAUST CAM SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	9162535	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	171395	COUPLING ON THE CAM SHAFT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149859	DOWEL BOLT	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	171395	COUPLING ON THE CAM SHAFT	171395 COUPLING ON THE CAM SHAFT Valid after stock exhaustion of 162645	-	2	Enquire
-	171399	COMPLETE L.H. INDUCTION DISTRIBUTION CAM SHAFT	171399 COMPLETE L.H. INDUCTION DISTRIBUTION CAM SHAFT DISTRIBUTION CAM SHAFT / Valid after stock exhaustion of 152688	-	1	Enquire
-	171400	COMPLETE R.H. INDUCTION DISTRIBUTION CAM SHAFT	171400 COMPLETE R.H. INDUCTION DISTRIBUTION CAM SHAFT DISTRIBUTION CAM SHAFT / Valid after stock exhaustion of 152473	-	1	Enquire
-	159285	INTAKE VALVE GUIDE	159285 INTAKE VALVE GUIDE Oversized	-	36	Enquire
-	159283	EXHAUST VALVE GUIDE	159283 EXHAUST VALVE GUIDE Oversized	-	24	Enquire
-	165230	VALVES ADJUSTMENT PAD	165230 VALVES ADJUSTMENT PAD Th. mm. 3,15	-	60	Enquire
-	163682	VALVES ADJUSTMENT PAD	163682 VALVES ADJUSTMENT PAD Th. mm. 3,00	-	60	Enquire
-	165228	VALVES ADJUSTMENT PAD	165228 VALVES ADJUSTMENT PAD Th. mm. 3,05	-	60	Enquire
-	165229	VALVES ADJUSTMENT PAD	165229 VALVES ADJUSTMENT PAD Th. mm. 3,10	-	60	Enquire
-	165225	VALVES ADJUSTMENT PAD	165225 VALVES ADJUSTMENT PAD Th. mm. 2,85	-	60	Enquire
-	165226	VALVES ADJUSTMENT PAD	165226 VALVES ADJUSTMENT PAD Th. mm. 2,90	-	60	Enquire
-	165227	VALVES ADJUSTMENT PAD	165227 VALVES ADJUSTMENT PAD Th. mm. 2,95	-	60	Enquire
-	165223	VALVES ADJUSTMENT PAD	165223 VALVES ADJUSTMENT PAD Th. mm. 2,70	-	60	Enquire
-	165224	VALVES ADJUSTMENT PAD	165224 VALVES ADJUSTMENT PAD Th. mm. 2,75	-	60	Enquire
-	159379	VALVES ADJUSTMENT PAD	159379 VALVES ADJUSTMENT PAD Th. mm. 2,80	-	60	Enquire
-	165221	VALVES ADJUSTMENT PAD	165221 VALVES ADJUSTMENT PAD Th. mm. 2,55	-	60	Enquire
-	159378	VALVES ADJUSTMENT PAD	159378 VALVES ADJUSTMENT PAD Th. mm. 2,60	-	60	Enquire
-	165222	VALVES ADJUSTMENT PAD	165222 VALVES ADJUSTMENT PAD Th. mm. 2,65	-	60	Enquire
-	165218	VALVES ADJUSTMENT PAD	165218 VALVES ADJUSTMENT PAD Th. mm. 2,35	-	60	Enquire
-	163681	VALVES ADJUSTMENT PAD	163681 VALVES ADJUSTMENT PAD Th. mm. 2,40	-	60	Enquire
-	165219	VALVES ADJUSTMENT PAD	165219 VALVES ADJUSTMENT PAD Th. mm. 2,45	-	60	Enquire
-	165220	VALVES ADJUSTMENT PAD	165220 VALVES ADJUSTMENT PAD Th. mm. 2,50	-	60	Enquire
-	159377	VALVES ADJUSTMENT PAD	159377 VALVES ADJUSTMENT PAD Th. mm. 2,20	-	60	Enquire
-	165216	VALVES ADJUSTMENT PAD	165216 VALVES ADJUSTMENT PAD Th. mm. 2,25	-	60	Enquire
-	165217	VALVES ADJUSTMENT PAD	165217 VALVES ADJUSTMENT PAD Th. mm. 2,30	-	60	Enquire
-	165213	VALVES ADJUSTMENT PAD	165213 VALVES ADJUSTMENT PAD Th. mm. 2,05	-	60	Enquire
-	165214	VALVES ADJUSTMENT PAD	165214 VALVES ADJUSTMENT PAD Th. mm. 2,10	-	60	Enquire
-	165215	VALVES ADJUSTMENT PAD	165215 VALVES ADJUSTMENT PAD Th. mm. 2,15	-	60	Enquire
-	163680	VALVES ADJUSTMENT PAD	163680 VALVES ADJUSTMENT PAD Th. mm. 1,90	-	60	Enquire
-	165212	VALVES ADJUSTMENT PAD	165212 VALVES ADJUSTMENT PAD Th. mm. 1,95	-	60	Enquire
-	159358	VALVES ADJUSTMENT PAD	159358 VALVES ADJUSTMENT PAD Th. mm. 2,00	-	60	Enquire
-	165210	VALVES ADJUSTMENT PAD	165210 VALVES ADJUSTMENT PAD Th. mm. 1,75	-	60	Enquire
-	163679	VALVES ADJUSTMENT PAD	163679 VALVES ADJUSTMENT PAD Th. mm. 1,80	-	60	Enquire
-	165211	VALVES ADJUSTMENT PAD	165211 VALVES ADJUSTMENT PAD Th. mm. 1,85	-	60	Enquire
-	165208	VALVES ADJUSTMENT PAD	165208 VALVES ADJUSTMENT PAD Th. mm. 1,55	-	60	Enquire
-	163677	VALVES ADJUSTMENT PAD	163677 VALVES ADJUSTMENT PAD Th. mm. 1,60	-	60	Enquire
-	165209	VALVES ADJUSTMENT PAD	165209 VALVES ADJUSTMENT PAD Th. mm. 1,65	-	60	Enquire
-	163678	VALVES ADJUSTMENT PAD	163678 VALVES ADJUSTMENT PAD Th. mm. 1,70	-	60	Enquire
1	159349	PAD BOWL	159349 PAD BOWL	-	60	Enquire
2	165207	VALVES ADJUSTMENT PAD	165207 VALVES ADJUSTMENT PAD Th. mm. 1,50	-	60	Enquire
3	157986	COTTER FOR VALVE SPRING CUP	157986 COTTER FOR VALVE SPRING CUP	-	120	Enquire
4	157989	UPPER CUP	157989 UPPER CUP	-	60	Enquire
5	180192	OUTER SPRING FOR VALVE RETURN	180192 OUTER SPRING FOR VALVE RETURN	-	60	Enquire
6	180208	INNER SPRING FOR VALVE RETURN	180208 INNER SPRING FOR VALVE RETURN	-	60	Enquire
7	221473	OIL SEAL	221473 OIL SEAL	-	60	Enquire
8	172466	LOWER CUP	172466 LOWER CUP	-	60	Enquire
9	159284	INTAKE VALVE GUIDE	159284 INTAKE VALVE GUIDE	-	36	Enquire
10	159282	EXHAUST VALVE GUIDE	159282 EXHAUST VALVE GUIDE	-	24	Enquire
11	162669	INTAKE VALVE	162669 INTAKE VALVE	-	36	Enquire
12	159347	EXHAUST VALVE	159347 EXHAUST VALVE	-	24	Enquire
13	6148234	INTAKE VALVE SEAT	6148234 INTAKE VALVE SEAT	-	36	Enquire
14	6140702	EXHAUST VALVE SEAT	6140702 EXHAUST VALVE SEAT	-	24	Enquire
15	171400	COMPLETE R.H. INDUCTION DISTRIBUTION CAM SHAFT	171400 COMPLETE R.H. INDUCTION DISTRIBUTION CAM SHAFT DISTRIBUTION CAM SHAFT / Valid till stock exhaustion	-	1	Enquire
16	171399	COMPLETE L.H. INDUCTION DISTRIBUTION CAM SHAFT	171399 COMPLETE L.H. INDUCTION DISTRIBUTION CAM SHAFT DISTRIBUTION CAM SHAFT / Valid till stock exhaustion	-	1	Enquire
17	149912	COMPLETE R.H. AND L.H. EXHAUST CAM SHAFT	149912 COMPLETE R.H. AND L.H. EXHAUST CAM SHAFT EXHAUST CAM SHAFT	-	2	Enquire
18	9162535	THREADED PLUG	9162535 THREADED PLUG	-	2	Enquire
19	171395	COUPLING ON THE CAM SHAFT	171395 COUPLING ON THE CAM SHAFT	-	2	Enquire
20	149859	DOWEL BOLT	149859 DOWEL BOLT	-	2	Enquire
