Ferrari F40 - Timing - Tappets

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	117562	TAPPET FOR VALVE CONTROL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117569	VALVE SETTING PLATE mm. 3,25	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123884	Intake valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	134770	Exhaust valve	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117563	SUCTION VALVE GUIDE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123886	Intake valve seat	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123887	Exhaust valve seat	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117558	INNER SPRING FOR VALVE RETURN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117559	OUTER SPRING FOR VALVE RETURN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117567	UPPER CUP FOR RETAINING SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	117568	LOWER CUP FOR RETAINING SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	141565	Oil retainer on valve guide	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	117283	Cotter for valve spring cup	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	124243	Exhaust valve guide	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	124244	Exhaust valve guide overized of 0,2 mm.	124244 Exhaust valve guide overized of 0,2 mm. oversized of 0,2 mm.	-	16	Enquire
-	117564	SUCTION VALVE GUIDE 0,2 mm. OVERSIZED	117564 SUCTION VALVE GUIDE 0,2 mm. OVERSIZED of 0,2 mm	-	16	Enquire
-	117595	DITTO, THICKNESS mm. 4,55	117595 DITTO, THICKNESS mm. 4,55	-	32	Enquire
-	117596	DITTO, THICKNESS mm. 4,60	117596 DITTO, THICKNESS mm. 4,60	-	32	Enquire
-	117590	DITTO, THICKNESS mm. 4,30	117590 DITTO, THICKNESS mm. 4,30	-	32	Enquire
-	117591	DITTO, THICKNESS mm. 4,35	117591 DITTO, THICKNESS mm. 4,35	-	32	Enquire
-	117592	DITTO, THICKNESS mm. 4,40	117592 DITTO, THICKNESS mm. 4,40	-	32	Enquire
-	117593	DITTO, THICKNESS mm. 4,45	117593 DITTO, THICKNESS mm. 4,45	-	32	Enquire
-	117594	DITTO, THICKNESS mm. 4,50	117594 DITTO, THICKNESS mm. 4,50	-	32	Enquire
-	117586	DITTO, THICKNESS mm. 4,10	117586 DITTO, THICKNESS mm. 4,10	-	32	Enquire
-	117587	DITTO, THICKNESS mm. 4,15	117587 DITTO, THICKNESS mm. 4,15	-	32	Enquire
-	117588	DITTO, THICKNESS mm. 4,20	117588 DITTO, THICKNESS mm. 4,20	-	32	Enquire
-	117589	DITTO, THICKNESS mm. 4,25	117589 DITTO, THICKNESS mm. 4,25	-	32	Enquire
-	117582	DITTO, THICKNESS mm. 3,90	117582 DITTO, THICKNESS mm. 3,90	-	32	Enquire
-	117583	DITTO, THICKNESS mm. 3,95	117583 DITTO, THICKNESS mm. 3,95	-	32	Enquire
-	117584	DITTO, THICKNESS mm. 4,00	117584 DITTO, THICKNESS mm. 4,00	-	32	Enquire
-	117585	DITTO, THICKNESS mm. 4,05	117585 DITTO, THICKNESS mm. 4,05	-	32	Enquire
-	117576	DITTO, THICKNESS mm. 3,60	117576 DITTO, THICKNESS mm. 3,60	-	32	Enquire
-	117577	DITTO, THICKNESS mm. 3,65	117577 DITTO, THICKNESS mm. 3,65	-	32	Enquire
-	117578	DITTO, THICKNESS mm. 3,70	117578 DITTO, THICKNESS mm. 3,70	-	32	Enquire
-	117579	DITTO, THICKNESS mm. 3,75	117579 DITTO, THICKNESS mm. 3,75	-	32	Enquire
-	117580	DITTO, THICKNESS mm. 3,80	117580 DITTO, THICKNESS mm. 3,80	-	32	Enquire
-	117581	DITTO, THICKNESS mm. 3,85	117581 DITTO, THICKNESS mm. 3,85	-	32	Enquire
-	117570	DITTO, THICKNESS mm. 3,30	117570 DITTO, THICKNESS mm. 3,30	-	32	Enquire
-	117571	DITTO, THICKNESS mm. 3,35	117571 DITTO, THICKNESS mm. 3,35	-	32	Enquire
-	117572	DITTO, THICKNESS mm. 3,40	117572 DITTO, THICKNESS mm. 3,40	-	32	Enquire
-	117573	DITTO, THICKNESS mm. 3,45	117573 DITTO, THICKNESS mm. 3,45	-	32	Enquire
-	117574	DITTO, THICKNESS mm. 3,50	117574 DITTO, THICKNESS mm. 3,50	-	32	Enquire
-	117575	DITTO, THICKNESS mm. 3,55	117575 DITTO, THICKNESS mm. 3,55	-	32	Enquire
1	117562	TAPPET FOR VALVE CONTROL	117562 TAPPET FOR VALVE CONTROL	-	32	Enquire
2	117569	VALVE SETTING PLATE mm. 3,25	117569 VALVE SETTING PLATE mm. 3,25 thickness 3,25 mm.	-	32	Enquire
3	123884	Intake valve	123884 Intake valve	-	16	Enquire
4	134770	Exhaust valve	134770 Exhaust valve	-	16	Enquire
5	117563	SUCTION VALVE GUIDE	117563 SUCTION VALVE GUIDE	-	16	Enquire
6	123886	Intake valve seat	123886 Intake valve seat	-	16	Enquire
7	123887	Exhaust valve seat	123887 Exhaust valve seat	-	16	Enquire
8	117558	INNER SPRING FOR VALVE RETURN	117558 INNER SPRING FOR VALVE RETURN	-	32	Enquire
9	117559	OUTER SPRING FOR VALVE RETURN	117559 OUTER SPRING FOR VALVE RETURN	-	32	Enquire
10	117567	UPPER CUP FOR RETAINING SPRING	117567 UPPER CUP FOR RETAINING SPRING	-	32	Enquire
11	117568	LOWER CUP FOR RETAINING SPRING	117568 LOWER CUP FOR RETAINING SPRING	-	32	Enquire
12	141565	Oil retainer on valve guide ARRIVING SOON	141565 Oil retainer on valve guide ARRIVING SOON	-	32	Enquire
13	117283	Cotter for valve spring cup	117283 Cotter for valve spring cup	-	64	Enquire
14	124243	Exhaust valve guide	124243 Exhaust valve guide	-	16	Enquire
