Cooling system of Ferrari Ferrari 512 TR

View All

Ferrari 512 TR - Cooling system

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	150212	R.H. radiator -Valid after	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	150213	L.H. radiator -Valid after	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147710	Electro fan set complete	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148620	Electric fan motor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137299	Fan	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140618	Conveyor	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	126883	Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	123298	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140149	THREADED PLUG	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147708	Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231620	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148059	Nut	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11944111	Screw	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12646604	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	102947	VIBRATION DAMPER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148777	Bracket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149045	Rubber pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148649	Rubber pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296781	COLLAR 30-45MM	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	291225	P clip Bracket With Sheath	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127494	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10902424	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	60758600	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137624	Vibration-damping buffer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147846	Screw -Valid for radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	147882	Washer	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148514	Tank for radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	137644	Plug for tank	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	812273	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149707	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	151348	Pipe from tank to return pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13000490	Screw Collar	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101239	CAP NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12643724	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	162347	Pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13423379	ELASTIC COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	157385	PILOT SIDE SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	122219	NOURICE ENGINE EXHAUST PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	262111	JUBILEE CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148647	Pipe on thermostat body	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148648	Rubber pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13525470	THREADED INSERT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148649	Rubber pipe	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148780	Return pipe from R.H. radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148781	Return pipe from L.H. radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148778	Pipe from thermostat body to RH radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	148779	Pipe from thermostat body to LH radiator	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	127557	Breather union	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	106195	BRACKET WITH SHEATH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	158655	TEMPERATURE SWITCH	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101508	Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	140150	O.R. GASKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	126293	Pipe from tank to breather union	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	13432070	HOSE COLLAR	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	158655	TEMPERATURE SWITCH	158655 TEMPERATURE SWITCH Valid after stock exhaustion / of 140314	-	1	Enquire
-	155187	Breather union	155187 Breather union Valid from engine / Nr. 34889	-	2	Enquire
-	155027	Tank for radiator	155027 Tank for radiator Valid from engine / Nr. 34889	-	1	Enquire
-	152315	Screw -Valid for radiator	152315 Screw -Valid for radiator 150212 and 150213	-	4	Enquire
-	150212	R.H. radiator -Valid after	150212 R.H. radiator -Valid after depletion of 148775	-	1	Enquire
-	150213	L.H. radiator -Valid after	150213 L.H. radiator -Valid after depletion of 148776	-	1	Enquire
1	150212	R.H. radiator -Valid after	150212 R.H. radiator -Valid after Valid till depletion	-	1	Enquire
2	150213	L.H. radiator -Valid after	150213 L.H. radiator -Valid after Valid till depletion	-	1	Enquire
3	147710	Electro fan set complete	147710 Electro fan set complete	-	2	Enquire
4	148620	Electric fan motor	148620 Electric fan motor	-	2	Enquire
5	137299	Fan	137299 Fan	-	2	Enquire
6	140618	Conveyor	140618 Conveyor	-	2	Enquire
7	126883	Gasket	126883 Gasket	-	2	Enquire
8	123298	SCREW	123298 SCREW	-	8	Enquire
9	140149	THREADED PLUG	140149 THREADED PLUG	-	2	Enquire
10	147708	Bracket	147708 Bracket	-	4	Enquire
11	231620	SCREW	231620 SCREW	-	4	Enquire
12	148059	Nut	148059 Nut	-	4	Enquire
13	11944111	Screw	11944111 Screw	-	4	Enquire
14	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	12	Enquire
15	12646604	WASHER	12646604 WASHER	-	8	Enquire
16	102947	VIBRATION DAMPER	102947 VIBRATION DAMPER	-	4	Enquire
17	148777	Bracket	148777 Bracket	-	2	Enquire
18	12643724	WASHER	12643724 WASHER	-	4	Enquire
19	127494	WASHER	127494 WASHER	-	4	Enquire
20	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	4	Enquire
21	149045	Rubber pipe	149045 Rubber pipe	-	2	Enquire
22	148649	Rubber pipe	148649 Rubber pipe	-	2	Enquire
23	296781	COLLAR 30-45MM ARRIVING SOON	296781 COLLAR 30-45MM ARRIVING SOON	-	13	Enquire
24	291225	P clip Bracket With Sheath	291225 P clip Bracket With Sheath	-	2	Enquire
25	12643724	WASHER	12643724 WASHER	-	8	Enquire
26	127494	WASHER	127494 WASHER	-	4	Enquire
27	10902424	SCREW	10902424 SCREW	-	4	Enquire
28	60758600	NUT	60758600 NUT	-	4	Enquire
29	137624	Vibration-damping buffer	137624 Vibration-damping buffer	-	4	Enquire
30	147846	Screw -Valid for radiator	147846 Screw -Valid for radiator 148775 and 148776	-	4	Enquire
31	147882	Washer	147882 Washer	-	4	Enquire
32	148514	Tank for radiator	148514 Tank for radiator Valid till engine / Nr. 34888	-	1	Enquire
33	137644	Plug for tank	137644 Plug for tank	-	1	Enquire
34	812273	CABLE GROMMET	812273 CABLE GROMMET	-	4	Enquire
35	149707	SPACER	149707 SPACER	-	4	Enquire
36	151348	Pipe from tank to return pipe	151348 Pipe from tank to return pipe return pipe	-	1	Enquire
37	13000490	Screw Collar	13000490 Screw Collar	-	2	Enquire
38	101239	CAP NUT	101239 CAP NUT	-	4	Enquire
39	12643724	WASHER	12643724 WASHER	-	4	Enquire
40	162347	Pipe	162347 Pipe	-	1	Enquire
41	13423379	ELASTIC COLLAR	13423379 ELASTIC COLLAR	-	1	Enquire
42	157385	PILOT SIDE SPRING	157385 PILOT SIDE SPRING	-	2	Enquire
43	122219	NOURICE ENGINE EXHAUST PIPE	122219 NOURICE ENGINE EXHAUST PIPE body	-	1	Enquire
44	262111	JUBILEE CLAMP	262111 JUBILEE CLAMP	-	2	Enquire
45	148647	Pipe on thermostat body	148647 Pipe on thermostat body	-	1	Enquire
46	148648	Rubber pipe	148648 Rubber pipe	-	1	Enquire
47	13525470	THREADED INSERT	13525470 THREADED INSERT	-	2	Enquire
48	148649	Rubber pipe	148649 Rubber pipe	-	2	Enquire
49	148780	Return pipe from R.H. radiator	148780 Return pipe from R.H. radiator	-	1	Enquire
50	148781	Return pipe from L.H. radiator	148781 Return pipe from L.H. radiator	-	1	Enquire
51	148778	Pipe from thermostat body to RH radiator	148778 Pipe from thermostat body to RH radiator to R.H. radiator	-	1	Enquire
52	148779	Pipe from thermostat body to LH radiator	148779 Pipe from thermostat body to LH radiator to L.H. radiator	-	1	Enquire
53	127557	Breather union	127557 Breather union Valid till engine / Nr. 34888	-	2	Enquire
54	106195	BRACKET WITH SHEATH	106195 BRACKET WITH SHEATH	-	4	Enquire
55	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	4	Enquire
56	158655	TEMPERATURE SWITCH	158655 TEMPERATURE SWITCH	-	1	Enquire
57	101508	Gasket	101508 Gasket	-	1	Enquire
58	140150	O.R. GASKET	140150 O.R. GASKET	-	2	Enquire
59	126293	Pipe from tank to breather union	126293 Pipe from tank to breather union breather union	-	2	Enquire
60	13432070	HOSE COLLAR	13432070 HOSE COLLAR	-	2	Enquire
