Ferrari 512 TR - Crankshaft - Connecting rods and pistons

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
120902 Crankshaft Enquire To Order
Photo Part No Description Price (each) Stock
100185 Dowel Enquire To Order
Photo Part No Description Price (each) Stock
14326150 CAP $0.58 To Order
Photo Part No Description Price (each) Stock
138900 Flywheel compl. Enquire To Order
Photo Part No Description Price (each) Stock
4150813 Shim for rear support Enquire To Order
Photo Part No Description Price (each) Stock
103877 BEARING $33.28 To Order
Photo Part No Description Price (each) Stock
10206520 Feather key on crankshaft $9.11 To Order
Photo Part No Description Price (each) Stock
109688 Connecting rod, and cap Enquire To Order
Photo Part No Description Price (each) Stock
100156 CONNECTING ROD TIGHTENING SCREW $19.24 To Order
Photo Part No Description Price (each) Stock
104011 CONNECTING ROD TIGHTENING NUT $62.01 To Order
Photo Part No Description Price (each) Stock
106183 CONNECTING ROD HALF BEARING $25.66 To Order
Photo Part No Description Price (each) Stock
107100 Bush for gudgeon pin $44.90 To Order
Photo Part No Description Price (each) Stock
139649 Piston, complete $321.97 To Order
Photo Part No Description Price (each) Stock
119850 AC seal ring (2nd groove) Enquire To Order
Photo Part No Description Price (each) Stock
119851 ROF scraper ring (3rd groove) Enquire To Order
Photo Part No Description Price (each) Stock
138391 Sealing ring $54.77 To Order
Photo Part No Description Price (each) Stock
119537 Gudgeon pin $110.72 To Order
Photo Part No Description Price (each) Stock
100174 Ring for gudgeon pin $5.98 To Order
Photo Part No Description Price (each) Stock
201755 Bolt Hex Head M10 x 1.25 $1.18 To Order
Photo Part No Description Price (each) Stock
108662 Safety plate $20.54 To Order
View All
Crankshaft - Connecting rods and pistons of Ferrari Ferrari 512 TR Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
- 121531
Set of segments 		$391.86 12
- 106184
1st undersize 0,254 mm. on Ø 		- - Enquire
- 106185
2nd undersize 0,508 mm on Ø 		- - Enquire
- 109738
COMPLETE CONNECTING ROD AND CAP 		$463.60 (45% off) 12
- 108604
Half bearing set -
1st undersize 0.254 mm 		- 1 Enquire
- 108605
Half bearing set -
2nd undersize 0.508 mm 		- 1 Enquire
- 113984
SHIM 1st OVERSIZE mm 0.127 		$94.04 -
- 100147
SHIM 2nd OVERSIZE mm 0.250 		$15.48 (21.8% off) -
- 108603
Half bearing set -
Standard 		$192.32 1
1 120902
Crankshaft 		- 1 Enquire
2 100185
Dowel 		- 1 Enquire
3 14326150
CAP 		$0.58 (61.3% off) 12
4 138900
Flywheel compl. 		- 1 Enquire
10 4150813
Shim for rear support 		- 2 Enquire
11 103877
BEARING 		$33.28 1
12 10206520
Feather key on crankshaft 		$9.11 2
13 109688
Connecting rod, and cap
Not as spare part / With assembly 109738 		- 12 Enquire
14 100156
CONNECTING ROD TIGHTENING SCREW
screw 		$19.24 (56.8% off) 24
15 104011
CONNECTING ROD TIGHTENING NUT
tightening screw 		$62.01 24
16 106183
CONNECTING ROD HALF BEARING 		$25.66 24
17 107100
Bush for gudgeon pin 		$44.90 12
18 139649
Piston, complete 		$321.97 12
19 119850
AC seal ring (2nd groove)
(1st and 2nd groove) / Not as spare part / With set 121531 		- 24 Enquire
20 119851
ROF scraper ring (3rd groove)
(3rd groove) / Not as spare part / With set 121531 		- 12 Enquire
21 138391
Sealing ring 		$54.77 (25.2% off) 1
22 119537
Gudgeon pin 		$110.72 (48.9% off) 12
23 100174
Ring for gudgeon pin 		$5.98 (29.6% off) 24
24 201755
Bolt Hex Head M10 x 1.25 		$1.18 (39.5% off) 8
25 108662
Safety plate 		$20.54 (72.6% off) 1
