Name: Box Guide Hydraulics
Rating: 5.0 (1 reviews)

Box Guide Hydraulics of Ferrari Ferrari 458 Challenge

View All

Ferrari 458 Challenge - Box Guide Hydraulics

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	264539	STEERING BOX	$4,515.32	To Order

Photo	Part No	Description	Price (each)	Stock
	277720	SCREW	$4.00	To Order

Photo	Part No	Description	Price (each)	Stock
	102742	Nyloc Nut M10 x 1.25 x 10mm	$0.45	To Order

Photo	Part No	Description	Price (each)	Stock
	12626224	WASHER	$0.21	To Order

Photo	Part No	Description	Price (each)	Stock
	305041	PIPE FROM STEERING BOX TO RADIATOR	$158.84	To Order

Photo	Part No	Description	Price (each)	Stock
	277407	HOSE CONNECTOR	$11.38	To Order

Photo	Part No	Description	Price (each)	Stock
	10280060	WASHER COPPER D14. 20 X 1.5	$0.21	To Order

Photo	Part No	Description	Price (each)	Stock
	184727	Banjo bolt For Union M16 x 1.5	$6.03	To Order

Photo	Part No	Description	Price (each)	Stock
	11270360	GASKET	$0.34	To Order

Photo	Part No	Description	Price (each)	Stock
	13127070	COLLAR	$2.12	To Order

Photo	Part No	Description	Price (each)	Stock
	305158	DELIVERY PIPE	$301.00	To Order

Photo	Part No	Description	Price (each)	Stock
	262427	RETURN PIPE	$77.00	To Order

Photo	Part No	Description	Price (each)	Stock
	263238	PIPE MOUNTING BRACKET	$22.45	To Order

Photo	Part No	Description	Price (each)	Stock
	14058621	NUT	$0.44	To Order

Photo	Part No	Description	Price (each)	Stock
	126648	WASHER D.10.5-21 X 2	$1.91	To Order

Photo	Part No	Description	Price (each)	Stock
	267177	CLIP	$1.07	To Order

Photo	Part No	Description	Price (each)	Stock
	11625824	SCREW	$0.39	To Order

Photo	Part No	Description	Price (each)	Stock
	265686	STEERING ANGLE REDUCTION SPA	$50.15	To Order

Photo	Part No	Description	Price (each)	Stock
	271838	METAL CLAMP	$17.18	To Order

Photo	Part No	Description	Price (each)	Stock
	270317	METAL CLAMP	$4.99	To Order

Photo	Part No	Description	Price (each)	Stock
	250196	ROD END FOR STEERING BOX	$449.27	To Order

Photo	Part No	Description	Price (each)	Stock
	229521	STEERING BOX GAITER REPLACEMENT KIT	$481.36	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram
1	264539	STEERING BOX	264539 STEERING BOX	$4,515.32	1
2	277720	SCREW	277720 SCREW	$4.00	4
3	102742	Nyloc Nut M10 x 1.25 x 10mm	102742 Nyloc Nut M10 x 1.25 x 10mm	$0.45 MSRP: ~~3.25~~ (86.2% off)	2
4	12626224	WASHER	12626224 WASHER	$0.21	2
5	305041	PIPE FROM STEERING BOX TO RADIATOR	305041 PIPE FROM STEERING BOX TO RADIATOR	$158.84	1
6	277407	HOSE CONNECTOR	277407 HOSE CONNECTOR	$11.38	1
7	10280060	WASHER COPPER D14. 20 X 1.5	10280060 WASHER COPPER D14. 20 X 1.5	$0.21 MSRP: ~~1.00~~ (79% off)	2
8	184727	Banjo bolt For Union M16 x 1.5	184727 Banjo bolt For Union M16 x 1.5	$6.03	1
9	11270360	GASKET	11270360 GASKET	$0.34 MSRP: ~~0.52~~ (34.6% off)	2
10	13127070	COLLAR	13127070 COLLAR	$2.12	2
11	305158	DELIVERY PIPE	305158 DELIVERY PIPE	$301.00	1
12	262427	RETURN PIPE	262427 RETURN PIPE	$77.00	1
13	263238	PIPE MOUNTING BRACKET	263238 PIPE MOUNTING BRACKET	$22.45	1
14	14058621	NUT	14058621 NUT	$0.44	4
15	126648	WASHER D.10.5-21 X 2	126648 WASHER D.10.5-21 X 2	$1.91	4
16	267177	CLIP	267177 CLIP	$1.07	4
17	11625824	SCREW	11625824 SCREW	$0.39 MSRP: ~~1.00~~ (61% off)	2
18	265686	STEERING ANGLE REDUCTION SPA	265686 STEERING ANGLE REDUCTION SPA	$50.15	2
19	271838	METAL CLAMP	271838 METAL CLAMP	$17.18	2
20	270317	METAL CLAMP	270317 METAL CLAMP	$4.99	2
21	250196	ROD END FOR STEERING BOX	250196 ROD END FOR STEERING BOX	$449.27 MSRP: ~~613.86~~ (26.8% off)	1
22	229521	STEERING BOX GAITER REPLACEMENT KIT	229521 STEERING BOX GAITER REPLACEMENT KIT	$481.36 MSRP: ~~587.12~~ (18% off)	1
