View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	124342	THREADED CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	11197774	WAVY WASHER D.6.4 X 12 X 1.2	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	322509	Gasket	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	168275	PNEUMATIC ACTUATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	191230	PIN	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	184532	TERMINAL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

View All

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
1	197755	RH INTAKE MANIFOLD	197755 RH INTAKE MANIFOLD Applicable up to MY 06; Applicable up to engine No. 99607	-	1	Enquire
1	217791	RH INTAKE MANIFOLD	217791 RH INTAKE MANIFOLD Applicable from MY 06; Applicable from engine No. 99608	-	1	Enquire
2	197756	LH INTAKE MANIFOLD	197756 LH INTAKE MANIFOLD Applicable up to MY 06; Applicable up to engine No. 99607	-	1	Enquire
2	217792	LH INTAKE MANIFOLD	217792 LH INTAKE MANIFOLD Applicable from MY 06; Applicable from engine No. 99608	-	1	Enquire
3	124342	THREADED CONNECTOR	124342 THREADED CONNECTOR	-	1	Enquire
4	231620	SCREW	231620 SCREW M6 X 25	-	8	Enquire
4	231625	SCREW	231625 SCREW M6 X 40	-	4	Enquire
4	14309224	SCREW	14309224 SCREW M6 X 65	-	8	Enquire
5	11197774	WAVY WASHER D.6.4 X 12 X 1.2	11197774 WAVY WASHER D.6.4 X 12 X 1.2	-	20	Enquire
6	322509	Gasket	322509 Gasket Applicable up to MY 06; Applicable up to engine No. 99607	-	2	Enquire
7	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	16	Enquire
8	168275	PNEUMATIC ACTUATOR	168275 PNEUMATIC ACTUATOR	-	1	Enquire
9	191230	PIN	191230 PIN	-	1	Enquire
10	184532	TERMINAL	184532 TERMINAL	-	1	Enquire
11	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	1	Enquire
