INTAKE MANIFOLD COVER of Ferrari Ferrari 430 Scuderia Spider 16M

View All

Ferrari 430 Scuderia Spider 16M - INTAKE MANIFOLD COVER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	215068	ROTATING DRUM	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	222997	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	204873	SAFETY PLATE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	197761	SPRING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	205123	BUSHING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	203401	DRUM CONTROL LEVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	177613	NUT	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	217471	Gasket Inlet Manifold	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	174818	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	268878	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	128016	CONNECTOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	240262	SPACER FOR THROTTLE BODY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	190151	Clamp	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	150302	Oil Pump O-Ring	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	331005	THROTTLE BODY	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231624	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	231406	AIR FLOW METER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	900284	SCREW COLLAR	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	227396	LH CONNECTOR PIPE	Enquire	To Order
	226757	RH CONNECTOR PIPE	Enquire	To Order
	227395	RH CONNECTOR PIPE	Enquire	To Order

...and 1 more part variants. See table on right for more details.

Photo	Part No	Description	Price (each)	Stock
	218327	AESTHETIC COVER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	210157	CAP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	241533	RH BADGE	Enquire	To Order
	220354	RH BADGE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	220355	LH BADGE	Enquire	To Order
	241534	LH BADGE	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
2	215068	ROTATING DRUM	215068 ROTATING DRUM	-	1	Enquire
3	222997	SCREW	222997 SCREW	-	3	Enquire
4	204873	SAFETY PLATE	204873 SAFETY PLATE	-	1	Enquire
5	197761	SPRING	197761 SPRING	-	1	Enquire
6	205123	BUSHING	205123 BUSHING	-	1	Enquire
7	203401	DRUM CONTROL LEVER	203401 DRUM CONTROL LEVER	-	1	Enquire
8	177613	NUT	177613 NUT	-	1	Enquire
9	217471	Gasket Inlet Manifold	217471 Gasket Inlet Manifold	-	2	Enquire
10	174818	CONNECTOR	174818 CONNECTOR	-	2	Enquire
11	268878	CONNECTOR	268878 CONNECTOR	-	2	Enquire
12	128016	CONNECTOR	128016 CONNECTOR	-	2	Enquire
13	240262	SPACER FOR THROTTLE BODY	240262 SPACER FOR THROTTLE BODY	-	2	Enquire
14	190151	Clamp ARRIVING SOON	190151 Clamp ARRIVING SOON	-	2	Enquire
15	150302	Oil Pump O-Ring	150302 Oil Pump O-Ring	-	2	Enquire
16	331005	THROTTLE BODY	331005 THROTTLE BODY	-	2	Enquire
17	231624	SCREW	231624 SCREW	-	8	Enquire
18	231406	AIR FLOW METER	231406 AIR FLOW METER	-	2	Enquire
19	900284	SCREW COLLAR ARRIVING SOON	900284 SCREW COLLAR ARRIVING SOON	-	4	Enquire
20	227396	LH CONNECTOR PIPE	227396 LH CONNECTOR PIPE Applicable for USA, CDN	-	1	Enquire
20	226757	RH CONNECTOR PIPE	226757 RH CONNECTOR PIPE Not for USA, CDN	-	1	Enquire
20	227395	RH CONNECTOR PIPE	227395 RH CONNECTOR PIPE Applicable for USA, CDN	-	1	Enquire
20	226758	LH. CONNECTOR PIPE	226758 LH. CONNECTOR PIPE Not for USA, CDN	-	1	Enquire
21	218327	AESTHETIC COVER	218327 AESTHETIC COVER	-	1	Enquire
22	210157	CAP	210157 CAP	-	1	Enquire
23	241533	RH BADGE	241533 RH BADGE With pegs	-	2	Enquire
23	220354	RH BADGE	220354 RH BADGE Glued	-	2	Enquire
24	220355	LH BADGE	220355 LH BADGE Glued	-	2	Enquire
24	241534	LH BADGE	241534 LH BADGE With pegs	-	2	Enquire
