Ferrari 296 GTB USA - LIFTING THE VEHICLE

View the exploded parts diagram to find the part you are looking for:
  • You can reposition the diagram by dragging it
  • You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons
  • You can click on a hotspot 1 in the parts diagram to locate the part in the table
Part Key
IN
IN STOCK
AS
ARRIVING SOON
TO
To Order
PE
PLEASE ENQUIRE

Photo Part No Description Price (each) Stock
844052 ELECTRIC PUMP $3,887.93 To Order
Photo Part No Description Price (each) Stock
749634 LIFT SYSTEM PIPE FROM PUMP TO DISCONNECTOR $57.33 To Order
Photo Part No Description Price (each) Stock
749633 LIFT SYSTEM PIPE FROM DISCONNECTOR TO UNDERBODY $75.37 To Order
840588 LIFT SYSTEM PIPE FROM DISCONNECTOR TO UNDERBODY $90.30 To Order
Photo Part No Description Price (each) Stock
965928 UNDERBODY LIFT SYSTEM PIPE $91.88 To Order
840587 UNDERBODY LIFT SYSTEM PIPE $114.66 To Order
Photo Part No Description Price (each) Stock
818435 LIFT SYSTEM PIPE FROM DISCONNECTOR TO BLOCK $58.75 To Order
Photo Part No Description Price (each) Stock
981007 LIFT SYSTEM PIPE FROM BLOCK TO RH FRONT WHEEL $84.56 To Order
Photo Part No Description Price (each) Stock
981008 LIFT SYSTEM PIPE FROM BLOCK TO LH FRONT WHEEL $84.56 To Order
Photo Part No Description Price (each) Stock
326103 LIFT SYSTEM FILLER TANK $90.30 To Order
Photo Part No Description Price (each) Stock
770523 LIFT SYSTEM FILLER HOSE $186.33 To Order
Photo Part No Description Price (each) Stock
13432070 HOSE COLLAR $0.57 To Order
Photo Part No Description Price (each) Stock
916497 LIFT SYSTEM RIGID FILLER PIPE $127.56 To Order
Photo Part No Description Price (each) Stock
259642 HOSE $20.05 To Order
Photo Part No Description Price (each) Stock
260155 GASKET $3.91 To Order
Photo Part No Description Price (each) Stock
965937 LIFT PUMP MOUNTING BRACKET $121.82 To Order
Photo Part No Description Price (each) Stock
925640 LIFTER BRACKET $30.08 To Order
Photo Part No Description Price (each) Stock
308995 BUSH $2.87 To Order
Photo Part No Description Price (each) Stock
304224 SCREW $14.68 To Order
Photo Part No Description Price (each) Stock
255047 CABLE GROMMET $3.81 To Order
Photo Part No Description Price (each) Stock
255048 GROMMET SHIM $2.84 To Order
Photo Part No Description Price (each) Stock
11568124 SCREW $0.94 To Order
Photo Part No Description Price (each) Stock
14059211 NUT $0.06 To Order
Photo Part No Description Price (each) Stock
745271 LIFT SYSTEM OIL TANK MOUNTING BRACKET $64.49 To Order
Photo Part No Description Price (each) Stock
955463 LIFT SYSTEM OIL TANK SHIELD $22.92 To Order
Photo Part No Description Price (each) Stock
292835 BUSH $1.22 To Order
Photo Part No Description Price (each) Stock
85833900 SCREW $0.36 ARRIVING SOON
Photo Part No Description Price (each) Stock
16285127 SCREW $0.58 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.31 To Order
Photo Part No Description Price (each) Stock
259508 CLIP $0.63 To Order
259508 CLIP $0.63 To Order
Photo Part No Description Price (each) Stock
266156 CLIP $0.65 To Order
Photo Part No Description Price (each) Stock
256962 CLIP $0.66 To Order
Photo Part No Description Price (each) Stock
234284 CLIP $0.63 To Order
Photo Part No Description Price (each) Stock
959208 CLIP $1.46 To Order
Photo Part No Description Price (each) Stock
234285 CLIP $0.70 To Order
Photo Part No Description Price (each) Stock
291408 CLIP $0.18 To Order
Photo Part No Description Price (each) Stock
292189 LIFT SYSTEM DISTRIBUTOR BLOCK $110.70 To Order
Photo Part No Description Price (each) Stock
793079 RH LIFT SYSTEM HOSE BRACKET $18.70 To Order
900096 RH LIFT SYSTEM HOSE BRACKET $35.82 To Order
Photo Part No Description Price (each) Stock
793080 LH LIFT SYSTEM HOSE BRACKET $22.92 To Order
900097 LH LIFT SYSTEM HOSE BRACKET $33.68 To Order
Photo Part No Description Price (each) Stock
116374 CLIP $2.51 To Order
Photo Part No Description Price (each) Stock
231619 SCREW $0.31 To Order
Photo Part No Description Price (each) Stock
303873 CLIP $1.77 To Order
View All
LIFTING THE VEHICLE of Ferrari Ferrari 296 GTB USA Diagram Tap to enlarge
# Part Details Price
(each)		 Qty on
Diagram		 Add to
Cart
0001 844052
ELECTRIC PUMP
Version with lift system - Not for Assetto Fiorano FIO2 		$3,887.93 1
0002 749634
LIFT SYSTEM PIPE FROM PUMP TO DISCONNECTOR
Version with lift system - Not for Assetto Fiorano FIO2 		$57.33 1
0003 749633
LIFT SYSTEM PIPE FROM DISCONNECTOR TO UNDERBODY
Version with lift system - Not for Assetto Fiorano FIO2; No longer supplied - Replaced by 840588 		$75.37 1
0003 840588
LIFT SYSTEM PIPE FROM DISCONNECTOR TO UNDERBODY
Version with lift system - For vehicles up to Ass.ly No. 197540 also order underbody lift system pipe 840587 Ref. 4 - Not for Assetto Fiorano FIO2 		$90.30 1
0004 965928
UNDERBODY LIFT SYSTEM PIPE
Version with lift system - Not for Assetto Fiorano FIO2; No longer supplied - Replaced by 840587 		$91.88 1
0004 840587
UNDERBODY LIFT SYSTEM PIPE
Version with lift system - For vehicles up to Ass.ly No. 197540 also order lift system pipe from disconnector to underbody 840588 Ref. 3 - Not for Assetto Fiorano FIO2 		$114.66 1
0005 818435
LIFT SYSTEM PIPE FROM DISCONNECTOR TO BLOCK
Version with lift system - Not for Assetto Fiorano FIO2 		$58.75 1
0006 981007
LIFT SYSTEM PIPE FROM BLOCK TO RH FRONT WHEEL
Version with lift system - Not for Assetto Fiorano FIO2 		$84.56 1
0007 981008
LIFT SYSTEM PIPE FROM BLOCK TO LH FRONT WHEEL
Version with lift system - Not for Assetto Fiorano FIO2 		$84.56 1
0008 326103
LIFT SYSTEM FILLER TANK
Version with lift system - Not for Assetto Fiorano FIO2 		$90.30 1
0009 770523
LIFT SYSTEM FILLER HOSE
Version with lift system - Not for Assetto Fiorano FIO2 		$186.33 1
0010 13432070
HOSE COLLAR
Version with lift system - Not for Assetto Fiorano FIO2; D. 15.7 		$0.57 (46.7% off) 2
0011 916497
LIFT SYSTEM RIGID FILLER PIPE
Version with lift system - Not for Assetto Fiorano FIO2 		$127.56 1
0012 259642
HOSE
Version with lift system - Not for Assetto Fiorano FIO2 		$20.05 1
0013 260155
GASKET
Version with lift system - Not for Assetto Fiorano FIO2 		$3.91 (2.3% off) 2
0014 965937
LIFT PUMP MOUNTING BRACKET
Version with lift system - Not for Assetto Fiorano FIO2 		$121.82 1
0015 925640
LIFTER BRACKET
Version with lift system - Not for Assetto Fiorano FIO2 		$30.08 1
0016 308995
BUSH
Version with lift system - Not for Assetto Fiorano FIO2 		$2.87 2
0017 304224
SCREW
Version with lift system - Not for Assetto Fiorano FIO2; M10 X 1.5 X 28 		$14.68 2
0018 255047
CABLE GROMMET
Version with lift system - Not for Assetto Fiorano FIO2; D13 		$3.81 2
0019 255048
GROMMET SHIM
Version with lift system - Not for Assetto Fiorano FIO2 		$2.84 2
0020 11568124
SCREW
M6 X 16 		$0.94 3
0021 14059211
NUT
Version with lift system - Not for Assetto Fiorano FIO2; M6 		$0.06 2
0022 745271
LIFT SYSTEM OIL TANK MOUNTING BRACKET
Version with lift system - Not for Assetto Fiorano FIO2 		$64.49 1
0023 955463
LIFT SYSTEM OIL TANK SHIELD
Version with lift system - Not for Assetto Fiorano FIO2 		$22.92 1
0024 292835
BUSH
Version with lift system - Not for Assetto Fiorano FIO2 		$1.22 1
0025 85833900
SCREW
M5 X 16
ARRIVING SOON 		$0.36 1
0026 16285127
SCREW
M5 X 16 		$0.58 2
0027 231619
SCREW
M6 X 18 		$0.31 2
0028 259508
CLIP
Version with lift system - Not for Assetto Fiorano FIO2; 1 compartment- 		$0.63 1
0028 259508
CLIP
1 compartment- 		$0.63 1
0029 266156
CLIP
Version with lift system - Not for Assetto Fiorano FIO2 		$0.65 1
0030 256962
CLIP
Version with lift system - Not for Assetto Fiorano FIO2; D. 4.7 X 1 		$0.66 1
0031 234284
CLIP
Version with lift system - Not for Assetto Fiorano FIO2; 1 compartment- 		$0.63 2
0032 959208
CLIP
Version with lift system - Not for Assetto Fiorano FIO2 		$1.46 1
0033 234285
CLIP
Version with lift system - Not for Assetto Fiorano FIO2; 2 compartments 		$0.70 1
0034 291408
CLIP
Version with lift system - Not for Assetto Fiorano FIO2 		$0.18 1
0035 292189
LIFT SYSTEM DISTRIBUTOR BLOCK
Version with lift system - Not for Assetto Fiorano FIO2 		$110.70 1
0036 793079
RH LIFT SYSTEM HOSE BRACKET
Version with lift system - Not for Assetto Fiorano FIO2; Applies until depletion 		$18.70 1
0036 900096
RH LIFT SYSTEM HOSE BRACKET
Version with lift system - Not for Assetto Fiorano FIO2; Applicable after depletion of 793079 		$35.82 1
0037 793080
LH LIFT SYSTEM HOSE BRACKET
Version with lift system - Not for Assetto Fiorano FIO2; Applies until depletion 		$22.92 1
0037 900097
LH LIFT SYSTEM HOSE BRACKET
Version with lift system - Not for Assetto Fiorano FIO2; Applicable after depletion of 793080 		$33.68 1
0038 116374
CLIP
Version with lift system - Not for Assetto Fiorano FIO2 		$2.51 (28.3% off) 2
0039 231619
SCREW
M6 X 20 		$0.31 2
0040 303873
CLIP
Version with lift system - Not for Assetto Fiorano FIO2; 1 compartment- 		$1.77 2
