INTERCOOLER of Ferrari Ferrari 296 GTB USA

View All

Ferrari 296 GTB USA - INTERCOOLER

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	874363	LH INTERCOOLER	Enquire	To Order
	874364	RH INTERCOOLER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	914435	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	910534	INTERCOOLER V-CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	777775	LH INTERCOOLER RIGID PIPE	Enquire	To Order
	941361	LH INTERCOOLER RIGID PIPE	Enquire	To Order
	777776	RH INTERCOOLER RIGID PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	297576	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	814993	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	777773	LH HOSE	Enquire	To Order
	941399	LH HOSE	Enquire	To Order
	777774	RH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	297572	COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	914140	LH INTERCOOLER LOWER BRACKET	Enquire	To Order
	914144	RH INTERCOOLER LOWER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	811614	LH INTERCOOLER UPPER BRACKET	Enquire	To Order
	811654	RH INTERCOOLER UPPER BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	149707	SPACER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	789073	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	844545	LH PIPE CONNECTOR BARREL	Enquire	To Order
	844546	RH PIPE CONNECTOR BARREL	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	889223	O-RING	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	835465	PRESSURE AND TEMPERATURE SENSOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	85833700	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	315495	DUMP-VALVE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	771901	LH HOSE	Enquire	To Order
	771902	RH HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296781	COLLAR 30-45MM	Enquire	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	846986	SOUND GENERATOR HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	296783	SCREW COLLAR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	310096	SOUND GENERATOR	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	314100	RIVET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	869189	SOUND GENERATOR FASTENER HOSE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	746942	SOUND GENERATOR BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	915988	LH RIGID DUMP VALVE PIPE	Enquire	To Order
	915989	RH RIGID DUMP VALVE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	178053	CLAMP	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	810962	COMPL. LH DUMP VALVE PIPE	Enquire	To Order
	810963	COMPL. RH DUMP VALVE PIPE	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	771777	LH PIPE CONNECTOR BARREL BRACKET	Enquire	To Order
	771778	RH PIPE CONNECTOR BARREL BRACKET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	797731	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	812273	CABLE GROMMET	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	917701	RUBBER PAD	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	14059290	FLANGED NUT M6	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	797724	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	797729	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	294780	SCREW	Enquire	To Order

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
0001	874363	LH INTERCOOLER	874363 LH INTERCOOLER	-	1	Enquire
0001	874364	RH INTERCOOLER	874364 RH INTERCOOLER	-	1	Enquire
0002	914435	O-RING	914435 O-RING	-	2	Enquire
0003	910534	INTERCOOLER V-CLAMP	910534 INTERCOOLER V-CLAMP	-	2	Enquire
0004	777775	LH INTERCOOLER RIGID PIPE	777775 LH INTERCOOLER RIGID PIPE Applies until depletion	-	1	Enquire
0004	941361	LH INTERCOOLER RIGID PIPE	941361 LH INTERCOOLER RIGID PIPE For vehicles up to Ass.ly No. 203727, also hose 941399, ref. 7; Applicable after depletion of 777775	-	1	Enquire
0004	777776	RH INTERCOOLER RIGID PIPE	777776 RH INTERCOOLER RIGID PIPE	-	1	Enquire
0005	297576	COLLAR	297576 COLLAR	-	6	Enquire
0006	814993	COLLAR	814993 COLLAR	-	2	Enquire
0007	777773	LH HOSE	777773 LH HOSE Applies until depletion	-	1	Enquire
0007	941399	LH HOSE	941399 LH HOSE For vehicles up to Ass.ly No. 203727, also order pipe 941361 ref. 4; Applicable after depletion of 777773	-	1	Enquire
0007	777774	RH HOSE	777774 RH HOSE	-	1	Enquire
0008	297572	COLLAR	297572 COLLAR	-	2	Enquire
0009	914140	LH INTERCOOLER LOWER BRACKET	914140 LH INTERCOOLER LOWER BRACKET	-	1	Enquire
0009	914144	RH INTERCOOLER LOWER BRACKET	914144 RH INTERCOOLER LOWER BRACKET	-	1	Enquire
0010	811614	LH INTERCOOLER UPPER BRACKET	811614 LH INTERCOOLER UPPER BRACKET	-	1	Enquire
0010	811654	RH INTERCOOLER UPPER BRACKET	811654 RH INTERCOOLER UPPER BRACKET	-	1	Enquire
0011	149707	SPACER	149707 SPACER	-	8	Enquire
0012	789073	WASHER	789073 WASHER	-	18	Enquire
0013	844545	LH PIPE CONNECTOR BARREL	844545 LH PIPE CONNECTOR BARREL	-	1	Enquire
0013	844546	RH PIPE CONNECTOR BARREL	844546 RH PIPE CONNECTOR BARREL	-	1	Enquire
0014	889223	O-RING	889223 O-RING	-	2	Enquire
0015	835465	PRESSURE AND TEMPERATURE SENSOR	835465 PRESSURE AND TEMPERATURE SENSOR	-	2	Enquire
0016	85833700	SCREW	85833700 SCREW M5 X 16	-	14	Enquire
0017	315495	DUMP-VALVE	315495 DUMP-VALVE	-	2	Enquire
0018	771901	LH HOSE	771901 LH HOSE	-	1	Enquire
0018	771902	RH HOSE	771902 RH HOSE	-	1	Enquire
0019	296781	COLLAR 30-45MM ARRIVING SOON	296781 COLLAR 30-45MM ARRIVING SOON	-	1	Enquire
0020	846986	SOUND GENERATOR HOSE	846986 SOUND GENERATOR HOSE	-	1	Enquire
0021	296783	SCREW COLLAR	296783 SCREW COLLAR	-	3	Enquire
0022	310096	SOUND GENERATOR	310096 SOUND GENERATOR	-	1	Enquire
0023	314100	RIVET	314100 RIVET	-	2	Enquire
0024	869189	SOUND GENERATOR FASTENER HOSE	869189 SOUND GENERATOR FASTENER HOSE	-	1	Enquire
0025	746942	SOUND GENERATOR BRACKET	746942 SOUND GENERATOR BRACKET	-	1	Enquire
0026	915988	LH RIGID DUMP VALVE PIPE	915988 LH RIGID DUMP VALVE PIPE	-	1	Enquire
0026	915989	RH RIGID DUMP VALVE PIPE	915989 RH RIGID DUMP VALVE PIPE	-	1	Enquire
0027	178053	CLAMP	178053 CLAMP	-	4	Enquire
0028	810962	COMPL. LH DUMP VALVE PIPE	810962 COMPL. LH DUMP VALVE PIPE	-	1	Enquire
0028	810963	COMPL. RH DUMP VALVE PIPE	810963 COMPL. RH DUMP VALVE PIPE	-	1	Enquire
0029	771777	LH PIPE CONNECTOR BARREL BRACKET	771777 LH PIPE CONNECTOR BARREL BRACKET	-	1	Enquire
0029	771778	RH PIPE CONNECTOR BARREL BRACKET	771778 RH PIPE CONNECTOR BARREL BRACKET	-	1	Enquire
0030	797731	SCREW	797731 SCREW M5 X 35	-	2	Enquire
0031	812273	CABLE GROMMET	812273 CABLE GROMMET	-	10	Enquire
0032	917701	RUBBER PAD	917701 RUBBER PAD	-	2	Enquire
0033	14059290	FLANGED NUT M6	14059290 FLANGED NUT M6	-	4	Enquire
0034	797724	SCREW	797724 SCREW M5 X 14	-	2	Enquire
0035	797729	SCREW	797729 SCREW M5 X 25	-	14	Enquire
0036	294780	SCREW	294780 SCREW M5 X 16	-	2	Enquire
