Name: PARKING BRAKE
Rating: 4.5 (1 reviews)

PARKING BRAKE of Maserati Maserati 4200 Coupe (2002-2004) CC

View All

Maserati 4200 Coupe (2002-2004) CC - PARKING BRAKE

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

Photo	Part No	Description	Price (each)	Stock
	206732	COMPLETE HAND BRAKE LEVER	$564.57	To Order

Photo	Part No	Description	Price (each)	Stock
	147985	NUT	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	12628924	WASHER	$3.40	To Order

Photo	Part No	Description	Price (each)	Stock
	176118	MICRO-SWITCH	$84.53	To Order

Photo	Part No	Description	Price (each)	Stock
	200777	FRONT CABLE	$84.05	To Order

Photo	Part No	Description	Price (each)	Stock
	12646604	WASHER	$2.53	To Order

Photo	Part No	Description	Price (each)	Stock
	10734101	SPLIT PIN	$8.05	To Order

Photo	Part No	Description	Price (each)	Stock
	10726824	NUT	$5.79	To Order

Photo	Part No	Description	Price (each)	Stock
	185282	CABLE TIGHTENER	$39.31	To Order

Photo	Part No	Description	Price (each)	Stock
	101305	SPRING	$9.80	To Order

Photo	Part No	Description	Price (each)	Stock
	186208	BRACKET FOR SPRING	$14.93	To Order

Photo	Part No	Description	Price (each)	Stock
	10977524	SCREW	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	11199674	WASHER	$1.97	To Order

Photo	Part No	Description	Price (each)	Stock
	188588	BRAKE TRANSMISSION LEVER	$26.92	To Order

Photo	Part No	Description	Price (each)	Stock
	185278	TRANSMISSION LEVER PIN	$26.92	To Order

Photo	Part No	Description	Price (each)	Stock
	185566	SELF-LUBRICATING BUSHING	$14.09	To Order

Photo	Part No	Description	Price (each)	Stock
	10050814	PIN	$9.86	To Order

Photo	Part No	Description	Price (each)	Stock
	84653800	WASHER	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	10734301	SPLIT PIN	$1.27	To Order

Photo	Part No	Description	Price (each)	Stock
	188587	TRANSMISSION PULLEY	$19.99	To Order

Photo	Part No	Description	Price (each)	Stock
	194875	PARKING BRAKE REAR CABLE	$129.95	To Order

Photo	Part No	Description	Price (each)	Stock
	143938	CABLE SHEATH	$29.73	To Order

Photo	Part No	Description	Price (each)	Stock
	186574	SHOES SUPPORT SPACER	$88.80	To Order

Photo	Part No	Description	Price (each)	Stock
	248418	Hand Brake Shoe	$177.48	ARRIVING SOON

Photo	Part No	Description	Price (each)	Stock
	190814	BRACKET PARKING BRAKE	$93.34	To Order

Photo	Part No	Description	Price (each)	Stock
	186572	ADJUSTER FOR HANDBRAKE	$123.27	To Order

Photo	Part No	Description	Price (each)	Stock
	190782	HAND BRAKE CONTROL DEVICE	$44.36	To Order

Photo	Part No	Description	Price (each)	Stock
	105270	FORK	$81.56	To Order

Photo	Part No	Description	Price (each)	Stock
	186933	BRAKE CABLE SPRING	$2.53	To Order

Photo	Part No	Description	Price (each)	Stock
	10441290	BRACKET WITH SHEATH	$9.02	To Order

Photo	Part No	Description	Price (each)	Stock
	14039614	NUT	$1.54	To Order

Photo	Part No	Description	Price (each)	Stock
	204538	BRAKE CABLE SPRING	$5.98	To Order
	186934	BRAKE CABLE SPRING	$3.20	To Order

Photo	Part No	Description	Price (each)	Stock
	186935	BRAKE CABLE FRONT SPRING	$3.95	To Order
	204536	BRAKE CABLE FRONT SPRING	$8.54	To Order

Photo	Part No	Description	Price (each)	Stock
	186936	BRAKE CABLE REAR SPRING	$3.95	To Order
	204537	BRAKE CABLE REAR SPRING	$5.36	To Order

Photo	Part No	Description	Price (each)	Stock
	11730624	SCREW	$2.83	To Order

Photo	Part No	Description	Price (each)	Stock
	190776	Return Spring For Brake Shoes	$24.82	To Order

Photo	Part No	Description	Price (each)	Stock
	190779	Return Spring For Brake Shoes	$79.17	To Order

Photo	Part No	Description	Price (each)	Stock
	190780	Spring For Shoes	$8.06	To Order

Photo	Part No	Description	Price (each)	Stock
	250657	SCREW	Enquire	To Order

Photo	Part No	Description	Price (each)	Stock
	101282	PIN	$86.08	To Order

Photo	Part No	Description	Price (each)	Stock
	199471	SOUNDPROOFING PANEL FOR BRAKE CABLE	$1.49	To Order

Photo	Part No	Description	Price (each)	Stock
	200774	PIN	$10.98	To Order

Photo	Part No	Description	Price (each)	Stock
	204412	FRONT SPACER	$15.08	To Order

Photo	Part No	Description	Price (each)	Stock
	204413	SPACER	$7.47	To Order

Photo	Part No	Description	Price (each)	Stock
	204410	REAR SPACER	$23.53	To Order

Photo	Part No	Description	Price (each)	Stock
	184519	PAD	$2.70	To Order

View All

Diagram Tap to enlarge

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
-	980138146	COMPLETE HAND BRAKE LEVER	980138146 COMPLETE HAND BRAKE LEVER	$575.13	1
1	206732	COMPLETE HAND BRAKE LEVER	206732 COMPLETE HAND BRAKE LEVER	$564.57	1
2	147985	NUT	147985 NUT	$1.97	2
3	84653800	WASHER	84653800 WASHER	-	2	Enquire
4	12628924	WASHER	12628924 WASHER	$3.40	2
5	176118	MICRO-SWITCH	176118 MICRO-SWITCH	$84.53	1
6	200777	FRONT CABLE	200777 FRONT CABLE	$84.05	1
7	12646604	WASHER	12646604 WASHER	$2.53	1
8	10734101	SPLIT PIN	10734101 SPLIT PIN	$8.05	1
9	10726824	NUT	10726824 NUT	$5.79	1
10	185282	CABLE TIGHTENER	185282 CABLE TIGHTENER	$39.31	1
11	101305	SPRING	101305 SPRING	$9.80	1
12	186208	BRACKET FOR SPRING	186208 BRACKET FOR SPRING	$14.93	1
13	10977524	SCREW	10977524 SCREW	$1.97	2
14	11199674	WASHER	11199674 WASHER	$1.97	2
15	188588	BRAKE TRANSMISSION LEVER	188588 BRAKE TRANSMISSION LEVER	$26.92	1
16	185278	TRANSMISSION LEVER PIN	185278 TRANSMISSION LEVER PIN	$26.92	1
17	185566	SELF-LUBRICATING BUSHING	185566 SELF-LUBRICATING BUSHING	$14.09	2
18	10050814	PIN	10050814 PIN	$9.86	1
19	84653800	WASHER	84653800 WASHER	-	1	Enquire
20	10734301	SPLIT PIN	10734301 SPLIT PIN	$1.27	1
21	188587	TRANSMISSION PULLEY	188587 TRANSMISSION PULLEY	$19.99	1
22	194875	PARKING BRAKE REAR CABLE	194875 PARKING BRAKE REAR CABLE	$129.95	1
23	143938	CABLE SHEATH	143938 CABLE SHEATH	$29.73	2
24	186574	SHOES SUPPORT SPACER	186574 SHOES SUPPORT SPACER	$88.80	2
25	248418	Hand Brake Shoe ARRIVING SOON	248418 Hand Brake Shoe It is recommended to replace all 4 brake shoes ARRIVING SOON	$177.48	4
26	190814	BRACKET PARKING BRAKE	190814 BRACKET PARKING BRAKE	$93.34	2
27	186572	ADJUSTER FOR HANDBRAKE	186572 ADJUSTER FOR HANDBRAKE	$123.27	2
28	190782	HAND BRAKE CONTROL DEVICE	190782 HAND BRAKE CONTROL DEVICE	$44.36	2
29	105270	FORK	105270 FORK	$81.56	2
30	186933	BRAKE CABLE SPRING	186933 BRAKE CABLE SPRING	$2.53	2
31	10441290	BRACKET WITH SHEATH	10441290 BRACKET WITH SHEATH	$9.02	1
32	14039614	NUT	14039614 NUT M6	$1.54	3
33	204538	BRAKE CABLE SPRING	204538 BRAKE CABLE SPRING Valid for cars with pads (pos. 47)	$5.98	1
33	186934	BRAKE CABLE SPRING	186934 BRAKE CABLE SPRING Not for cars with pads (pos. 47)	$3.20	1
34	186935	BRAKE CABLE FRONT SPRING	186935 BRAKE CABLE FRONT SPRING Valid for F1- -Not for cars with pads (pos. 47)	$3.95	1
34	204536	BRAKE CABLE FRONT SPRING	204536 BRAKE CABLE FRONT SPRING Valid for F1- -Valid for cars with pads (pos. 47)	$8.54	1
35	186936	BRAKE CABLE REAR SPRING	186936 BRAKE CABLE REAR SPRING Valid for F1- -Not for cars with pads (pos. 47)	$3.95	1
35	204537	BRAKE CABLE REAR SPRING	204537 BRAKE CABLE REAR SPRING Valid for F1- -Valid for cars with pads (pos. 47)	$5.36	1
36	11730624	SCREW	11730624 SCREW	$2.83	2
37	190776	Return Spring For Brake Shoes	190776 Return Spring For Brake Shoes	$24.82	2
38	190779	Return Spring For Brake Shoes	190779 Return Spring For Brake Shoes	$79.17	2
39	190780	Spring For Shoes	190780 Spring For Shoes	$8.06	4
40	250657	SCREW	250657 SCREW	-	6	Enquire
41	101282	PIN	101282 PIN	$86.08	2
42	199471	SOUNDPROOFING PANEL FOR BRAKE CABLE	199471 SOUNDPROOFING PANEL FOR BRAKE CABLE Valid for F1	$1.49	1
43	200774	PIN	200774 PIN	$10.98	1
44	204412	FRONT SPACER	204412 FRONT SPACER	$15.08	1
45	204413	SPACER	204413 SPACER	$7.47	1
46	204410	REAR SPACER	204410 REAR SPACER	$23.53	1
47	184519	PAD	184519 PAD	$2.70	4
48	204639	SOUNDPROOFING ELEMENT	204639 SOUNDPROOFING ELEMENT	$11.76	1
