Passenger Compartment Trims 3 of Lamborghini Lamborghini Murcielago LP670

View All

Lamborghini Murcielago LP670 - Passenger Compartment Trims 3

View the exploded parts diagram to find the part you are looking for:

You can reposition the diagram by dragging it
You can zoom in and out of the diagram by scrolling, pinching, or using the and buttons

You can click on a hotspot in the parts diagram to locate the part in the table

Part Key

IN STOCK

ARRIVING SOON

To Order

PLEASE ENQUIRE

View All

Diagram Tap to enlarge

0 Parts (0.00)

Warning: Multiple variants of the same part may be selected for item(s):

#	Part Number	Part Description	Part Details	Price (each)	Qty on Diagram	Add to Cart
001	418861461B	GLOVE BOX (ALCANTARA UPHOLSTERY - SUPPLY VIN)	418861461B GLOVE BOX (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	2	Enquire
002	429857211	TRIM (WITH 4 POINTS STICHING - ALCANTARA UPHOLSTERY - SUPPLY VIN)	429857211 TRIM (WITH 4 POINTS STICHING - ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	2	Enquire
003	418868011B	COVER (WITH 3 POINTS STICHING - ALCANTARA UPHOLSTERY - SUPPLY VIN)	418868011B COVER (WITH 3 POINTS STICHING - ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	2	Enquire
004	418867478E	RIGHT LOWER REAR ANGULAR COVERING ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	418867478E RIGHT LOWER REAR ANGULAR COVERING ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
005	418711461E	COVERING (ALCANTARA UPHOLSTERY - SUPPLY VIN)	418711461E COVERING (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
006	400804347	SPACER	400804347 SPACER	-	2	Enquire
007	WHT001190	ROUND HD. SCREW	WHT001190 ROUND HD. SCREW	-	2	Enquire
008	418867477E	LEFT LOWER REAR ANGULAR COVERING ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	418867477E LEFT LOWER REAR ANGULAR COVERING ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
009	403860283	FIRE EXTINGUISHER	403860283 FIRE EXTINGUISHER	-	1	Enquire
011	429854888	RIGHT SIDE MEMBER COVER ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	429854888 RIGHT SIDE MEMBER COVER ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
012	429854887	LEFT SIDE MEMBER COVER ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	429854887 LEFT SIDE MEMBER COVER ASSEMBLY (ALCANTARA UPHOLSTERY - SUPPLY VIN)	-	1	Enquire
013	400867397	GRID	400867397 GRID	-	2	Enquire
014	418867267	PLATE	418867267 PLATE	-	4	Enquire
015	410863939	DAMPING ELEMENT	410863939 DAMPING ELEMENT	-	4	Enquire
016	N10596302	SCREW M5X25.0	N10596302 SCREW M5X25.0	-	2	Enquire
017	400864519A	JOURNAL	400864519A JOURNAL	-	3	Enquire
018	400864179A	RUBBER RING	400864179A RUBBER RING	-	3	Enquire
019	470864994	CLIP	470864994 CLIP	-	3	Enquire
020	414864419	PLATE	414864419 PLATE	-	1	Enquire
021	N902661	SCREW	N902661 SCREW	-	3	Enquire
022	N0154487	SPEED NUT	N0154487 SPEED NUT	-	8	Enquire
023	N10656602	SCREW	N10656602 SCREW	-	8	Enquire
024	N90248401	POP RIVET	N90248401 POP RIVET	-	8	Enquire
026	414721585	ACCELERATOR COVER BOX	414721585 ACCELERATOR COVER BOX	-	1	Enquire
029	414863791A	COVERING	414863791A COVERING	-	1	Enquire
030	N10406504	OVAL HEXAGON SOCKET HEAD BOLT	N10406504 OVAL HEXAGON SOCKET HEAD BOLT	-	3	Enquire
031	N91153701	POP RIVET	N91153701 POP RIVET	-	5	Enquire
032	WHT003383	CLIP	WHT003383 CLIP	-	3	Enquire
033	N91109201	WASHER	N91109201 WASHER	-	4	Enquire
034	N10648502	SCREW M5X10	N10648502 SCREW M5X10	-	4	Enquire
035	WHT003102	SCREW 2.9X13	WHT003102 SCREW 2.9X13	-	4	Enquire
036	WHT003424	CLIP	WHT003424 CLIP	-	4	Enquire
037	WHT001190	ROUND HD. SCREW	WHT001190 ROUND HD. SCREW	-	6	Enquire
038	WHT003040	WASHER 5.3X1.5X15 (For Becker Radio System)	WHT003040 WASHER 5.3X1.5X15 (For Becker Radio System)	-	2	Enquire
039	WHT003065	SCREW (2,9X16)	WHT003065 SCREW (2,9X16)	-	3	Enquire
040	WHT003065	SCREW (2,9X16)	WHT003065 SCREW (2,9X16)	-	6	Enquire
041	WHT003114	SCREW	WHT003114 SCREW	-	8	Enquire
